Wire-wound Chip Inductors - Open
ctparts.com
CT0805HTF Series
From 1.8 nH to 1000 nH
Part
Number
CT0805HTF-1N8K
CT0805HTF-3N9K
CT0805HTF-4N7_*
CT0805HTF-6N8_*
CT0805HTF-8N2_*
CT0805HTF-10N_
CT0805HTF-12N_
CT0805HTF-15N_
CT0805HTF-18N_
CT0805HTF-22N_
CT0805HTF-27N_
CT0805HTF-33N_
CT0805HTF-39N_
CT0805HTF-47N_
CT0805HTF-56N_
CT0805HTF-68N_
CT0805HTF-82N_
CT0805HTF-R10_
CT0805HTF-R12_
CT0805HTF-R15_
CT0805HTF-R18_
CT0805HTF-R22_
CT0805HTF-R27_
CT0805HTF-R33_
CT0805HTF-R39_
CT0805HTF-R47_
CT0805HTF-R56_
CT0805HTF-R62_
CT0805HTF-R68_
CT0805HTF-R75_
CT0805HTF-R82_
CT0805HTF-1R0_
Not shown at actual size.
SPECIFICATIONS
Please specify tolerance code when ordering.
CT0805HT-4N7_
G = ±2%, J = ±5%, K = ±10%
* = J or K only
Inductance
(nH)
1.8
3.9
4.7
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
620
680
750
820
1000
L Test
Freq.
(MHz)
250
250
250
250
250
250
250
250
250
250
250
250
250
200
200
200
150
150
150
150
150
150
150
100
100
50
25
25
25
25
25
25
Q
Fact.
Min.
55
50
50
50
50
55
55
50
50
50
50
55
55
50
50
50
50
50
40
40
40
40
40
40
35
25
18
18
18
18
18
17
Q Test
Freq.
(MHz)
1500
1000
1000
1000
1000
750
750
500
500
500
500
500
500
500
500
500
500
500
250
250
250
250
250
250
250
100
50
50
50
50
50
50
SRF
Min.
(MHz)
9400
6100
5500
5500
4800
3300
3800
2950
3100
2900
2450
2350
2200
2000
1850
1500
1500
1200
1150
1050
950
900
850
800
700
600
550
450
420
400
400
330
DCR
Max.
Ω
(Ω)
0.03
0.06
0.06
0.08
0.08
0.08
0.1
0.1
0.13
0.15
0.23
0.28
0.33
0.39
0.39
0.4
0.44
0.64
0.68
0.8
0.9
0.98
1.3
1.45
1.6
1.8
1.9
2
2.1
2.2
2.5
2.6
Rated
DC
(mA)
800
800
800
800
800
800
800
800
800
800
600
600
600
600
500
500
500
400
300
300
300
300
300
300
300
300
300
300
300
300
300
300
Compliant
RoHS
CHARACTERISTICS
Description:
SMD ceramic core wire-wound chip inductor
Applications:
LC resonant circuits such as oscillator and signal
generators, impedance matching, circuit isolation, RF filters, disk
drives and computer peripherals, audio and video equipment, TV,
radio and telecommunication equipment
Operating Temperature:
-40°C to +125°C
Storage Temperature:
-25°C to +85°C
Inductance Tolerance:
±2%, ±5%, ±10%
Testing:
Inductance and Q are tested on an HP4287A at
specified frequency
Packaging:
Tape & Reel
Miscellaneous:
RoHS Compliant.
Marking:
Color dot
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
PHYSICAL DIMENSIONS
Size
mm
inches
A
Max.
2.29
0.090
B
Max.
1.73
0.068
C
Max.
1.1
0.043
D
0.51
0.020
E
1.02
0.040
F
1.27
0.05
C
D
A
E
D
B
Overall
PAD LAYOUT
F
Terminal
04.07.08
Technologies
Manufacturer of Passive and Discrete Semiconductor Components
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2008 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
