Peaking Coils - Radial
ctparts.com
SPECIFICATIONS
CT262LYF Series
From 0.10 mH to 15 mH
Part
Number
Please specify tolerance code when ordering.
CT262LYF-101_
J = ±5%, K = ±10%
Inductance
(mH)
.10
.12
.15
.18
.22
.27
.33
.39
.47
.56
.68
.82
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10.0
12.0
15.0
L Test
Freq.
(kHz)
796
796
796
796
796
796
796
796
796
796
796
796
252
252
252
252
252
252
252
252
252
252
252
252
79.6
79.6
79.6
Q
Fact.
Min.
60
60
60
60
60
60
60
60
60
60
60
60
80
80
80
80
80
80
80
80
80
80
80
80
60
60
60
Q Test
Freq.
(kHz)
796
796
796
796
796
796
796
796
796
796
796
796
252
252
252
252
252
252
252
252
252
252
252
252
79.6
79.6
79.6
SRF
Min.
(MHz)
6.1
5.5
5.0
4.7
4.5
4.1
3.8
3.5
3.2
2.9
2.7
2.3
2.1
1.9
1.8
1.6
1.5
1.4
.90
.90
.80
.70
.70
.60
.60
.50
.50
DCR
Max.
(W)
W
2.0
3.0
3.0
3.0
3.0
3.0
4.0
4.0
5.0
6.0
6.0
7.0
9.0
9.0
11
12
14
15
25
30
32
36
40
45
55
65
80
Rated
DC
(mA)
200
200
200
200
150
150
150
100
100
100
100
50
50
50
50
50
50
50
40
40
40
30
30
30
20
20
20
ENGINEERING KIT #4F
Not shown at actual size.
Compliant
RoHS
CT262LYF-101_
CT262LYF-121_
CT262LYF-151_
CT262LYF-181_
CT262LYF-221_
CT262LYF-271_
CT262LYF-331_
CT262LYF-391_
CT262LYF-471_
CT262LYF-561_
CT262LYF-681_
CT262LYF-821_
CT262LYF-102_
CT262LYF-122_
CT262LYF-152_
CT262LYF-182_
CT262LYF-222_
CT262LYF-272_
CT262LYF-332_
CT262LYF-392_
CT262LYF-472_
CT262LYF-562_
CT262LYF-682_
CT262LYF-822_
CHARACTERISTICS
Description:
Radial leaded (low profile) fixed inductor
Applications:
Ideal as a choke coil and a trap coil for low profile
equipment. Winding core is encapsulated in heat shrink plastic
housing providing mechanical and environmental protection
Temperature Coefficient:
440ppm / °C max.
Inductance Tolerance:
±5%, ±10%
Testing:
Inductance and Q are tested on an HP4285A at
specified frequency
Packaging:
Bulk pack; packaged in styrofoam
Marking:
Sleeving marked with inductance code
Miscellaneous:
RoHS Compliant.
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
CT262LYF-103_
CT262LYF-123_
CT262LYF-153_
PHYSICAL DIMENSIONS
Size
mm
inches
A
Max.
6.2
0.24
B
Max.
8
0.32
C
Nom.
5
0.2
D
5
0.2
22 AWG
Nom.
0.643
0.03
11.30.05
Technologies
Manufacturer of Inductors, Chokes, Coils, Beads, Transformers & Toroids
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2005 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
