C005YJR25PBSTR datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> capacitor> C005YJR25PBSTR

C005YJR25PBSTR: DescriptionCeramic Capacitor, Ceramic, 16V, 8% +Tol, 8% -Tol, J, 30ppm/Cel TC, 0.00000025uF, Surface Mount, 01005, CHIP, LEAD FREE; CategoryPassive components capacitor; File Size123KB，2 Pages; ManufacturerAVX; Environmental Compliance

Download Datasheet Parametric Compare View All

C005YJR25PBSTR Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	C005YJR25PBSTR	-	-	View	Buy Now

C005YJR25PBSTR Overview

Ceramic Capacitor, Ceramic, 16V, 8% +Tol, 8% -Tol, J, 30ppm/Cel TC, 0.00000025uF, Surface Mount, 01005, CHIP, LEAD FREE

C005YJR25PBSTR Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
package instruction	, 01005
Reach Compliance Code	compliant
ECCN code	EAR99
capacitance	2.5e-7 µF
Capacitor type	CERAMIC CAPACITOR
dielectric materials	CERAMIC
high	0.145 mm
length	0.405 mm
Manufacturer's serial number	C005
Installation features	SURFACE MOUNT
multi-layer	No
negative tolerance	8%
Number of terminals	2
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package shape	RECTANGULAR PACKAGE
Package form	SMT
method of packing	TR, PAPER, 4/7 INCH
positive tolerance	8%
Rated (DC) voltage (URdc)	16 V
series	C005
size code	01005
surface mount	YES
Temperature characteristic code	J
Temperature Coefficient	30ppm/Cel ppm/°C
Terminal shape	WRAPAROUND
width	0.215 mm
Base Number Matches	1

Preview

Download Datasheet

View All

Ultra-Miniature 01005 Size Accu-P

Thin-Film RF Microwave Capacitor

ACCU-P

TECHNOLOGY

The use of silicon oxide, a very low - loss dielectric material, in conjunction with

highly conductive electrode metals, results in low ESR and high Q. These high -

frequency characteristics change at a slower rate with increasing frequency than

for ceramic microwave capacitors.

ACCU-P

meets the fast - growing demand for low - loss (high - Q) capacitors for

use in surface mount technology, especially for the wireless communications

market at frequencies up to and above 5.8GHz.

ACCU-P

is currently unique in its ability to offer very low capacitance values (0.05

pF) and ultra tight capacitance tolerances (±0.01 pF).

APPLICATIONS

•

FEATURES

Ultra Miniature standard 01005 chip size.

Ultra tight capacitance tolerances (±0.01pF).

Low ESR and high Q at VHF, UHF and microwave frequencies.

TC ±30, ±60ppm/°C.

Nickel/Solder - coated terminations provide excellent solderability and leach

resistance.

• High insulation resistance: IR ≥ 10

Ohm.

• Orientation provides high SRF uniformity.

• Repeatable C

EFF

, ESR and Q vs. Frequency parameters, both lot to lot and

within lots, for increased production yields.

•

RF Modules

Mobile communications

Satellite TV

Global positioning systems

Filters

VCO’s

Matching networks

HOW TO ORDER

C005

Series

Voltage

Y = 16V

Temperature

Coefficient

XXX

Capacitance

(pF)

Tolerance

Accu-P

Lead Free

Termination

Packaging

Code

5000 pc reel

TR/10K = 10,000 pc reel

TR/20K = 20,000 pc reel

P/N Example: C 0 0 5 Y K 1 R 0 A B S T R

QUALITY AND RELIABILITY

Finished parts are tested for standard electrical parameters and visual / mechanical characteristics.

Each production lot is 100%

evaluated for:

• Capacitance

• Q Factor

• DWV at 12.5xV

RATED

Each production lot is evaluated

on a sample basis for:

• Dimensions

• Insulation Resistance

• Breakdown Voltage

• ESR

• Solderability

In addition, production is periodically

evaluated for:

• Mechanical stability

• Endurance (Life)

• Temperature Coefficient

• Accelerated Damp Heat Load (THB)

• Temperature Cycling

C005YJR25PBSTR Related Products

	C005YJR25PBSTR	C005YKR85PBSTR	C005YKR95PBSTR	C005YJR35PBSTR	C005YJR15ZBSTR	C005YJR25ABSTR	C005YKR85ABSTR	C005YJR25ZBSTR
Description	Ceramic Capacitor, Ceramic, 16V, 8% +Tol, 8% -Tol, J, 30ppm/Cel TC, 0.00000025uF, Surface Mount, 01005, CHIP, LEAD FREE	Ceramic Capacitor, Ceramic, 16V, 2.35% +Tol, 2.35% -Tol, K, 60ppm/Cel TC, 0.00000085uF, Surface Mount, 01005, CHIP, LEAD FREE	Ceramic Capacitor, Ceramic, 16V, 2.11% +Tol, 2.11% -Tol, K, 60ppm/Cel TC, 0.00000095uF, Surface Mount, 01005, CHIP, LEAD FREE	Ceramic Capacitor, Ceramic, 16V, 5.71% +Tol, 5.71% -Tol, J, 30ppm/Cel TC, 0.00000035uF, Surface Mount, 01005, CHIP, LEAD FREE	Ceramic Capacitor, Ceramic, 16V, 6.67% +Tol, 6.67% -Tol, J, 30ppm/Cel TC, 0.00000015uF, Surface Mount, 01005, CHIP, LEAD FREE	Ceramic Capacitor, Ceramic, 16V, 20% +Tol, 20% -Tol, J, 30ppm/Cel TC, 0.00000025uF, Surface Mount, 01005, CHIP, LEAD FREE	Ceramic Capacitor, Ceramic, 16V, 5.88% +Tol, 5.88% -Tol, K, 60ppm/Cel TC, 0.00000085uF, Surface Mount, 01005, CHIP, LEAD FREE	Ceramic Capacitor, Ceramic, 16V, 4% +Tol, 4% -Tol, J, 30ppm/Cel TC, 0.00000025uF, Surface Mount, 01005, CHIP, LEAD FREE
Is it Rohs certified?	conform to	conform to	conform to	conform to	conform to	conform to	conform to	conform to
package instruction	, 01005	, 01005	, 01005	, 01005	, 01005	, 01005	, 01005	, 01005
Reach Compliance Code	compliant	compliant	compliant	compliant	compliant	compliant	compliant	compliant
ECCN code	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99
capacitance	2.5e-7 µF	8.5e-7 µF	9.5e-7 µF	3.5e-7 µF	1.5e-7 µF	2.5e-7 µF	8.5e-7 µF	2.5e-7 µF
Capacitor type	CERAMIC CAPACITOR	CERAMIC CAPACITOR	CERAMIC CAPACITOR	CERAMIC CAPACITOR	CERAMIC CAPACITOR	CERAMIC CAPACITOR	CERAMIC CAPACITOR	CERAMIC CAPACITOR
dielectric materials	CERAMIC	CERAMIC	CERAMIC	CERAMIC	CERAMIC	CERAMIC	CERAMIC	CERAMIC
high	0.145 mm	0.145 mm	0.145 mm	0.145 mm	0.145 mm	0.145 mm	0.145 mm	0.145 mm
length	0.405 mm	0.405 mm	0.405 mm	0.405 mm	0.405 mm	0.405 mm	0.405 mm	0.405 mm
Manufacturer's serial number	C005	C005	C005	C005	C005	C005	C005	C005
Installation features	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT
multi-layer	No	No	No	No	No	No	No	No
negative tolerance	8%	2.3529%	2.1053%	5.7143%	6.6667%	20%	5.8824%	4%
Number of terminals	2	2	2	2	2	2	2	2
Maximum operating temperature	125 °C	125 °C	125 °C	125 °C	125 °C	125 °C	125 °C	125 °C
Minimum operating temperature	-55 °C	-55 °C	-55 °C	-55 °C	-55 °C	-55 °C	-55 °C	-55 °C
Package shape	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE
Package form	SMT	SMT	SMT	SMT	SMT	SMT	SMT	SMT
method of packing	TR, PAPER, 4/7 INCH	TR, PAPER, 4/7 INCH	TR, PAPER, 4/7 INCH	TR, PAPER, 4/7 INCH	TR, PAPER, 4/7 INCH	TR, PAPER, 4/7 INCH	TR, PAPER, 4/7 INCH	TR, PAPER, 4/7 INCH
positive tolerance	8%	2.3529%	2.1053%	5.7143%	6.6667%	20%	5.8824%	4%
Rated (DC) voltage (URdc)	16 V	16 V	16 V	16 V	16 V	16 V	16 V	16 V
series	C005	C005	C005	C005	C005	C005	C005	C005
size code	01005	01005	01005	01005	01005	01005	01005	01005
surface mount	YES	YES	YES	YES	YES	YES	YES	YES
Temperature characteristic code	J	K	K	J	J	J	K	J
Temperature Coefficient	30ppm/Cel ppm/°C	60ppm/Cel ppm/°C	60ppm/Cel ppm/°C	30ppm/Cel ppm/°C	30ppm/Cel ppm/°C	30ppm/Cel ppm/°C	60ppm/Cel ppm/°C	30ppm/Cel ppm/°C
Terminal shape	WRAPAROUND	WRAPAROUND	WRAPAROUND	WRAPAROUND	WRAPAROUND	WRAPAROUND	WRAPAROUND	WRAPAROUND
width	0.215 mm	0.215 mm	0.215 mm	0.215 mm	0.215 mm	0.215 mm	0.215 mm	0.215 mm
Base Number Matches	1	1	1	1	1	1	1	1
