RF Coaxial Connector
SMP Type
Coaxial Connector <20/40GHz>
●
Receptacle
CRS1001-1301F
0.65
4.5
6.5
2.0
3.3
■
Features
1.Compliant with MIL (MIL-STD-348A) standard.
2.A small coaxial connector with excellent RF
performance.
3.Wobble-free structure for ensured stability when
a jack and receptacle are mated, due to a push-
on connection provision and a high level of
connection strength.
4.Two application mechanisms of SMT and panel
mounting available.
5.A lead-free product (receptacle).
0
4.2
4.0
■
P.C. Board Dimension
0.3
4.2
6.35
RF Coaxial Connectors
■
Specifications
●
Receptacle
Shell / Terminal: Copper Alloy, Gold Plating
●
Jack
Shell / Contact: Copper Alloy, Gold Plating,
4
3.25
3.4
6.4
1.6 1.4
CRC1001-2001G(Right-Angle)
3.8
1.7
3.6
1.9
5.8
3.9
( 2.7)
3.0
3.25
4.0
■
Note
Please contact our sales agent for lead-free product(jack).
7.0
5.3
2.9
( 2.7)
1.Characteristic Impedance : 50Ω
2.Operating Frequency Range
Receptacle/Jack (Straight type) : DC to 40GHz
Jack (Right-angle type) : DC to 20GHz
3.V.S.W.R.
Receptacle/Jack (Straight type) : 1.2 max. DC to 20GHz
1.5 max. 20 to 40GHz
Jack (Right-angle type) : 1.3 max. DC to 20GHz
4.Operating Temperature Range : 65 to 125
5.Operating Life : 100 cycles
6.Adaptable Cables : 047, 085 equivalent semi-
flexible coaxial cable, UT-85
equivalent semi-rigid coaxial
cable
6.2
4.3
4.1
5.
4.6
2.5
■
Material and Plating
●
Jack
CRC1001-1901G(Straight)
0.9
3.0
0.35
0.7
