Preset counters electronic
2 presets, totalizer and batch counter
Display LED, 5-digits, programmable
NE216
Features
– Preset counter with two presets
– Display 5-digits
– Totalizer, hour counter
– Operating mode, start count, scaling factor
programmable
– Connection: Incremental encoder or digital sensors
– Step and trailing preset programmable
– Interface RS485
NE216 - LED Preset counter
Technical data - electrical ratings
Voltage supply
22...50 VAC (50/60 Hz)
85...265 VAC (50/60 Hz)
12...30 VDC
5 VA, 5 W
AC: 24 VDC ±20 % / 100 mA
DC: 9...28 VDC / 100 mA
LED, 7-segment display
5-digits
7.6 mm
Preset counter
Main counter with 2 presets
Totalizer
Hour counter
0.0001...9999.99
Adding or subtracting
A-B (difference counting)
A+B total (parallel counting)
Up/Down
A 90° B phase evaluation
3 Hz, 25 Hz, 10 kHz
programmable
Step preset, Trailing preset,
Time meter and hour counter
>10 years in EEPROM
Button, electric or automatic
Optocoupler
Normally open or closed,
programmable
0.01...99.99 s
RS485
Protection class II
Overvoltage category II
Pollution degree 2
DIN EN 61000-6-4
DIN EN 61000-6-2
1
www.baumerivo.com
Approvals
Technical data - electrical ratings
Programmable
parameters
Operating modes
Sensor logic
Scaling factor
Count mode
Control inputs
UL/cUL, CE conform
Power consumption
Sensor supply
Display
Number of digits
Digit height
Function
Technical data - mechanical design
Operating temperature
Storing temperature
Relative humidity
E-connection
Core cross-section
Protection DIN EN 60529
Operation / keypad
Housing type
Dimensions W x H x L
Installation depth
Mounting
Cutout dimensions
Materials
Weight approx.
0...+50 °C
-20...+70 °C
80 % non-condensing
Plug-in screw terminals
1.5 mm²
IP 65 face with seal
Membrane with softkeys
Built-in housing
48 x 48 x 100 mm
100 mm
Clip frame
45 x 45 mm (+0.6)
Housing: Makrolon 6485 (PC)
Keypad: Polyester
150 g
Subject to modification in technic and design. Errors and omissions excepted.
30/10/2008
Scaling factor
Count modes
Counting frequency
Operating modes
Data memory
Reset
Outputs electronic
Outputs relay
Output holding time
Interface
Standard
DIN EN 61010-1
Emitted interference
Interference immunity
Preset counters electronic
2 presets, totalizer and batch counter
Display LED, 5-digits, programmable
NE216
Part number
NE216.
AX01
Voltage supply
1
22...50 VAC
2
85...265 VAC
3
12...30 VDC
Outputs
1
Relay outputs
2
Electronic outputs
Interface
0
Without interface
1
RS485
Accessories
Adaptor plates
(page %S)
Z 118.033
Z 118.034
Z 118.035
Adaptor plate for screw mount,
face 60 x 75 mm
Adaptor plate for clip mount,
face 53.2 x 53.2 mm
Adaptor plate for clip mount,
face 60 x 75 mm
Block circuit diagram
Voltage
supply
-
+
Signal input
A
B
Control input
1
2
7
8
9
10
A 90° B
Main counter
with 2 presets
start count
scaling factor
Operating
time meter
Interface
RS485
Output
3
4
5
6
P1
1
2
Totalizer
Sensor
supply
12
+
13
-
P2
T,R- 14
T,R+ 15
Trigger level
Comparator inputs
Inputs
Input level
Input level Low
Input level High
Input resistance
Relay outputs
Switching voltage max.
Switching current max.
Switching capacity max.
Relay responding time
Input circuit
PNP- / NPN- / AC-logic
Programmable
0...2 VDC
3...40 VDC
3 kΩ
Output circuit
250 VAC / 110 VDC
1A
150 VA / 30 W
5 ms
Output circuit
Optocoupler short-circuit proof
40 V
25 mA
Subject to modification in technic and design. Errors and omissions excepted.
Connection diagram
Relay outputs
15 14 13 12 11 10
9
8
7
Electronic outputs
15 14 13 12 11 10
9
8
7
Electronical outputs
Switching voltage max.
Switching current max.
B
A
+24V
+24V
T,R+
T,R+
T,R-
T,R-
0V
0V
B
A
3
2
1
3
2
1
RS485 Sensor- Control
supply
input
Signal
input
RS485 Sensor
supply
Control
input
Signal
input
Residual voltage
<1 V
Supply voltage
P2
P1
Outputs
max. 265 V
terminal - terminal/
P2
P1
Outputs
max. 265 V
terminal - terminal /
- terminal
- terminal
Dimensions
60.8
48
100
10
1-6
7
44.7
48
Supply voltage
6
5
4
3
2
1
6
5
4
3
2
1
2
www.baumerivo.com
30/10/2008
