1W-5W
M
ODULAR
DC-DC C
ONVERTERS
✔
Single and Dual Output Models
✔
Pi Input Filters—Built-in EMI Suppression
✔
500 VDC Input/Output Isolation
✔
Short-Circuit/Over-Voltage Protection
✔
Compact Packages
✔
2-Year Warranty
✔
325,000 to 1,140,000-Hour Minimum MTBF
WITH
500V I/O I
SOLATION
C
HARACTERISTICS
EMI Suppression.......................Pi input filter, standard.
Reflected Ripple Current...........DC1-1, 30 mA
pp
, max.
DC2-1, 35 mA
pp
, max.
DC1-2 and DC2-2, 25 mA
pp
,
DC1-5 and DC2-5, 40 mA
pp
,
Output Voltage Tolerance..........DC1-1 and DC2-1, ±5%.
DC2-1, ±5%.
DC2-2, ±5%.
DC1-5 and DC2-5, ±5%.
Isolation Voltage........................500 VDC, input to output, for
minute.
Isolation Capacitance................100 pF, typical.
Output Noise and Ripple...........DC1-1 and DC2-1, 35 mV
pp
,
max.
max.
Model
Input Current
Max.
Input Voltage
No Full Output Output
Min. Nom. Max. Load Load Voltage Current Line Load Cross-
(V) (V) (V) (mA) (mA) (V)
(mA) Reg. Reg. Reg.
DC-DC 1W Singles
DC1-1-5/5
4.5
10.8
5.0
12
5.5
13.2
50
15
200
84
5.0
5.0
100 0.2% 0.1%
100 0.2% 0.2%
—
—
one
DC1-1-12/5
DC-DC 1W Duals
(Note 5)
DC2-1-5/12A
4.5
4.5
5.0
5.0
5.5
5.5
35
55
370
370
±12
±15
40
33
0.2% 0.2% 0.1%
0.2% 0.2% 0.1%
max.
DC2-1-5/15A
DC1-2 and DC2-2, 30 mV
pp
, max.
DC1-5 and DC2-5, 30 mV
pp
, max.
Efficiency...................................DC1-1 and DC2-1, 50%, min.
DC1-2 and DC2-2, 57%,min.
DC1-5 and DC2-5, 63%, min.
Short-Circuit Protection.............DC1-1 and DC2-1, thermal limited.
DC1-2, pulsed overload type.
DC2-2, thermal limited.
DC1-5 and DC2-5, pulsed over-
load current limit.
Transient Response ..................50 µs recovery to within 1% of the
regulation band with no more than
5% deviation.
Frequency of Operation ............45-55 kHz.
Temperature Range ..................-25°C to +70°C, no de-rating.
Temperature Coefficient ............±0.02%/°C over the entire operating
temperature range.
Relative Humidity ......................0 to 95%, non-condensing.
Altitude ......................................0 to 10,000 feet.
Cooling ......................................Convection cooling is adequate.
Moving air is recommended for
operation in a confined area.
Storage Temperature ................-40°C to +100°C.
Storage Humidity ......................0 to 95%, non-condensing.
Mean Time Between Failures ...DC1-1, >1,140,000 hours.
DC2-1, >737,000 hours.
DC1-2 and DC2-2, >800,000 hours.
DC1-5 and DC2-5, >330,000 hours.
DC-DC 2W Singles
DC1-2-5/5A
4.5 5.0 5.5 125
DC1-2-12/24A 10.8 12 13.2 68
700
275
5.0
24
400 0.1% 0.1%
83 0.1% 0.1%
—
—
DC-DC 2W Duals
(Note 5)
DC2-2-5/15 * 4.5 5.0 5.5 115
DC2-2-24/12 * 21.6 24 26.4 20
DC2-2-48/15 * 43.2 48 52.8 14
700
138
70
±15
±12
±15
65
80
65
0.2% 0.2% 0.1%
0.2% 0.2% 0.1%
0.2% 0.2% 0.1%
* Units supplied with L-case pin configuration; 2W units with model numbers
ending with the suffix “A” are furnished with M-case pin configuration.
40
POWER
GENERAL
152 Will Drive · Canton, MA 02021 USA · Phone 781-828-6216 · Fax 781-830-1155 · Email power@nidecpg.com · http://www.nidec.com
1W-5W
M
ODULAR
DC-DC C
ONVERTERS
DC1-1 AND DC2-1 SERIES
A. Dimensions shown are in inches.
B. Tolerances = 0.00 ±0.02 inch.
0.000 ±0.005 inch.
C. Module weight = 0.5 oz. (14.2g).
D. All DC1-1 and DC2-1 models have a phenolic, UL94V-rated case and
are encapsulated with a flame-retardant potting material
E. Dual output ±12V or ±15V models can be used as single output 24V
or 30V supplies.
WITH
500V I/O I
SOLATION
Pin-Out—1W
Models
Pin
1
2
3
10
11
12
13
14
15
22
23
24
DC1-1
+V
IN
N/C
N/C
- V
OUT
+V
OUT
- V
IN
- V
IN
+V
OUT
- V
OUT
N/C
N/C
+V
IN
DC2-1
No Suffix
+V
IN
- V2
OUT
+V2
OUT
- V1
OUT
+V1
OUT
- V
IN
- V
IN
+V1
OUT
- V1
OUT
+V2
OUT
- V2
OUT
+V
IN
DC2-1
With Suffix ‘A’
+V
IN
+V
IN
+V
IN
Common
Common
N/C
- V
OUT
N/C
+V
OUT
- V
IN
- V
IN
- V
IN
DC1-2/ DC2-2 SERIES—L CASE
A. Dimensions shown are in inches.
B. Tolerances = 0.00 ±0.02 inch.
0.000 ±0.005 inch.
C. Module weight = 0.9 oz. (25.5g).
D. All DC1-2 and DC2-2 models have six-sided copper cases and are
encapsulated with a flame retardant potting material.
E. Dual output ±12V or ±15V models can be used as single output 24V
or 30V supplies.
Pin-Out—2W Models
DC1-2
No Suffix ‘A’
(L Case)
+V
IN
- V
IN
+V
OUT
N/A
- V
OUT
DC1-2
With Suffix ‘A’
(M Case)
- V
IN
+V
IN
- V
OUT
N/A
+V
OUT
DC2-2
(L Case)
+V
IN
- V
IN
+V
OUT
Common
- V
OUT
Pin
1
2
3
4
5
DC1-2 SERIES—M CASE
A. Dimensions shown are in inches.
B. Tolerances = 0.00 ±0.02 inch.
0.000 ±0.005 inch.
C. Module weight = 0.9 oz. (25.5g).
D. All DC1-2 models have six-sided copper cases and are encapsulated
with a flame retardant potting material.
POWER
GENERAL
152 Will Drive · Canton, MA 02021 USA · Phone 781-828-6216 · Fax 781-830-1155 · Email power@nidecpg.com · http://www.nidec.com
41
1W-5W
M
ODULAR
DC-DC C
ONVERTERS
Input Current
Max.
Input Voltage
No Full Output Output
Min. Nom. Max. Load Load Voltage Current Line Load Cross-
(V) (V) (V) (mA) (mA) (V)
(mA) Reg. Reg. Reg.
WITH
500V I/O I
SOLATION
Model
Model
Input Current
Max.
Input Voltage
No Full Output Output
Min. Nom. Max. Load Load Voltage Current Line Load Cross-
(V) (V) (V) (mA) (mA) (V)
(mA) Reg. Reg. Reg.
DC-DC 5W Singles
DC1-5-5/5
DC1-5-5/12
DC1-5-24/5
4.75 5.0
4.75 5.0
21.6
24
5.5
5.5
26.4
175 1500
175 1700
25
315
5.0
12
5.0
1000 0.1% 0.1%
500 0.1% 0.1%
1000 0.1% 0.1%
—
—
—
DC-DC 5W Duals
(Note 5)
DC2-5-5/15
DC2-5-12/15
DC2-5-24/12
DC2-5-48/15
4.75 5.0
10.8
21.6
43.2
12
24
48
5.5
13.2
26.4
52.8
210 1850
65
35
18
730
355
175
±15
±15
±12
±15
200 0.1% 0.1% 0.1%
200 0.1% 0.1% 0.1%
250 0.1% 0.1% 0.1%
200 0.1% 0.1% 0.1%
5W Models
DC1-5 AND DC2-5 SERIES
A. Dimensions shown are in inches.
B. Tolerances = 0.00 ±0.02 inch.
0.000 ±0.005 inch.
C. DC1-5 and DC2-5 module weight = 1.6 oz. (45.4g).
D. All DC1-5 and DC2-5 models are supplied in a six-sided copper case.
E. Applications-ready G10 sockets are available for DC1-5 and DC2-5
dc-dc converters. For more information, call Power General
Applications Engineering.
F. Dual output models with ±12V, ±15V or ±18V outputs can be used as
single output 24V, 30V or 36V supplies.
Pin-Out—5W Models
Pin
1
2
3
4
5
DC1-5
+V
IN
- V
IN
+V
OUT
N/A
- V
OUT
DC2-5
+V
IN
- V
IN
+V
OUT
Common
- V
OUT
Model Selection Guide
DC 2 - 1 - 5 / 12 A
Series
Number of Outputs
Output Power (W)
DC Input Voltage (V)
DC Output
Voltage (V)
Design Identifier
(Optional Mechanical
Specifications)
Notes
1. Use of an external input line fuse is recommended:
1W series, 5V input models, use a 1.0A/125V fuse.
2W series, 5V input models, use a 1.5A/125V fuse.
1W and 2W series, all but 5V input models, use a 0.5A/125V fuse.
5W series, 5V input models, use a 2.5A/125V fuse.
5W series, 12V input models, use a 1.5A/125V fuse.
5W series, 24V input models, use a 1.0A/125V fuse.
5W series, 48V input models, use a 0.5A/125V fuse.
2. Peak-to-peak and RMS metering equipment must have a 20 MHz fre-
quency response with probes and cables that maintain a frequency
response of 20 Hz to 20 MHz. Output ripple and spikes are measured
directly at the output terminals of the converter with a 0.1 µF ceramic
capacitor
The probe ground band must make direct contact with the output return
or the common terminal of the converter to prevent erroneous noise mea-
surements.
3. DC2-6 short-circuit protection: 30 seconds, max. For all other models,
protection period is unlimited.
4. MTBF is calculated using the parts stress method in MIL-HDBK 217F
(ground benign, T
A
= +25°C).
5. Dual output converters with ±12V or ±15V output can be used as single
output 24V or 30V supplies.
6. All measurements are at nominal input, full load, and +25°C unless other-
wise specified.
42
POWER
GENERAL
152 Will Drive · Canton, MA 02021 USA · Phone 781-828-6216 · Fax 781-830-1155 · Email power@nidecpg.com · http://www.nidec.com
