Oven Controlled Crystal Oscillator
OX-500
Preliminary
Features
4-Pin package
Fast Warm-up
TCXO Replacement for better short term stability
Typical Applications
Base Stations
Test Equipment
Synthesizers
Military Communication Equipment
Frequency Range
Standard Frequencies
7 MHz – 40 MHz
20 MHz (SC); 13 MHz (AT)
Frequency stabilities
1
[AT Cut Crystal-Standard- 7 to 20 MHz]
Parameter
vs. operating temperature range
(Referenced to +25°C)
Min
-100
-250
-250
Typ
Max
+100
+250
+250
Units
ppb
ppb
ppb
Units
ppm
ppb
ppb
ppb
ppm
minutes
Operating temperature range
-20 … +70°C
-20 … +70°C
-40… +85°C
Condition
at time of shipment, nominal EFC
V
S
± 5% static
Load ± 5% static
after 30 days of operation
after 30 days of operation
to
±
200ppb of
fi
nal frequency (1 hour
reading) @ +25°C
Parameter
Initial tolerance
vs. supply voltage change
vs. load change
vs. aging
vs aging
/ day
/ year
Min
-0.5
-40
-40
-20
-1
Typ
Max
+0.5
+40
+40
+20
+1
2
Warm-up Time
htttp://www.vectron.com
Vectron International•267 LowellRoad,
Hudson, New Hampshire 03051•Tel:+1-88-VECTRON-1
Vectron International GmbH & Co. KG • Landstraße, 74924 Neckarbischofsheim, Germany • Tel: +49 7268 801 100
OX-500 page: 1/5
Options
5
Frequency stabilities
1
[SC Cut Crystal-Option- 20 to 40 MHz]
Parameter
vs. operating temperature range
(Referenced to +25°C)
Min
-25
-50
Typ
Max
+25
+50
Units
ppb
ppb
Operating temperature range
-20 … +70°C
-40… +85°C
Parameter
Initial tolerance
vs. supply voltage change
vs. load change
vs. aging
vs aging
/ day
/ year
Min
-0.2
-20
-20
-5.0
-100
Typ
Max
+0.2
+20
+20
+5.0
+100
2
Units
ppm
ppb
ppb
ppb
ppb
minutes
Condition
at time of shipment, nominal EFC
V
S
± 5% static
Load ± 5% static
after 30 days of operation
≤
60MHz;
after 30 days of operation
Warm-up Time
to ± 100ppb of
fi
nal frequency (1 hour
reading) @ +25°C
Supply Voltage (Vs)
Parameter
Supply voltage [Standard]
Power consumption
Min
3.135
Typ
3.3
Max
3.465
2.0
0.65
Units
VDC
Watts
Watts
Condition
during warm-up
steady state @ +25°C
RF Output
Parameter
Signal [Standard]
Load
Signal Level (Vol)
Signal Level (Voh)
Duty cycle
2.4
45
55
15
0.4
Min
Typ
HCMOS
Max
Units
pF
VDC
VDC
%
Condition
with Vs=3.3V and 15pF load
with Vs=3.3V and 15pF load
@ (Voh-Vol)/2
Frequency Tuning (EFC)
Parameter
Tuning Range
Tuning Range
±5.0
±1.0
Linearity
Tuning Slope
Control Voltage Range
0.0
1.4
10%
Positive
2.8
VDC
with Vs=3.3V
Min
Typ
Max
±12
±3
Units
ppm
ppm
Condition
with AT cut Crystal
with SC cut Crystal
Fixed OCXO; No adjust
htttp://www.vectron.com
Vectron International•267 LowellRoad,
Hudson, New Hampshire 03051•Tel:+1-88-VECTRON-1
Vectron International GmbH & Co. KG • Landstraße, 74924 Neckarbischofsheim, Germany • Tel: +49 7268 801 100
OX-500 page: 2/5
Options
5
Additional Parameters
Parameter
Phase Noise
3
Min
Typ
Max
-
-
-
-
-
Units
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
g
1
10
100
1
10
Hz
Hz
Hz
kHz
kHz
Condition
@ 10 MHz
Weight
Processing & Packing
6.0
Handling & Processing Note
Absolute Maximum Ratings
Parameter
Supply voltage (Vs)
Output Load
Operable temperature range
Storage temperature range
-55
-55
Min
Typ
Max
5.5
50
+85
+125
Units
V
pF
°C
°C
Condition
with Vs=3.3VDC
Notes:
1 Contact factory for improved stabilities or additional product options. Not all options and codes are available at all
frequencies.
2 Unless otherwise stated all values are valid after warm-up time and refer to typical conditions for supply voltage,
frequency control voltage, load, temperature (25°C)
3 Phase noise degrades with increasing output frequency.
4 Subject to technical modification.
5 Contact factory for availability.
htttp://www.vectron.com
Vectron International•267 LowellRoad,
Hudson, New Hampshire 03051•Tel:+1-88-VECTRON-1
Vectron International GmbH & Co. KG • Landstraße, 74924 Neckarbischofsheim, Germany • Tel: +49 7268 801 100
OX-500 page: 3/5
Enclosure
OX-500
Height “H”
9.5
Pin Length “L”
5.85min.
Pin Connections
1 Electronic Frequency Control Input (EFC)
7 Ground (Case)
8 RF Output
14 Supply Voltage Input
How to order this product:
Use this worksheet to forward the following information to your factory representative :
Model
OX-40X
Height
0
-
-
Supply Voltage
Code
B
RF Output
Code
A
Temperatur
Range
E
-
-
Stability
108
Frequency
Control
0
-
-
Frequency
10MHz
Model Code:
500: THT Version
Height:
0:
9,5 mm
Supply Voltage Code:
D:
5V
E:
3,3 V RF Output Code:
A:
HCMOS
Frequency Control:
0:
No Tuning
1:
±5.0...±12 ppm
2:
±1.0...±3.0 ppm
Temperature Range:
E:
-40...+85°C
J:
-20...+70°C
P:
0...+50°C
Stability Code:
258: ±25ppb
508: ±50ppb
107: ±100ppb
257: ±250ppb
htttp://www.vectron.com
Vectron International•267 LowellRoad,
Hudson, New Hampshire 03051•Tel:+1-88-VECTRON-1
Vectron International GmbH & Co. KG • Landstraße, 74924 Neckarbischofsheim, Germany • Tel: +49 7268 801 100
OX-500 page: 4/5
