8
7
6
5
4
REV
A
B
.
.
3
DESCRIPTION
INITIAL RELEASE
2
REVISIONS
DATE
1
APPROVED
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE
PROPERTY OF L-COM, INC. ANY REPRODUCTION IN PART OR WHOLE
WITHOUT THE WRITTEN PERMISSION OF L-COM, INC. IS PROHIBITED.
12/04/2002 MCCORMICK
04/18/03
.
.
MCCORMICK
.
.
REVISED MATERIAL THICKNESS FROM 0.24 TO 0.024 (ECN 1368)
.
.
D
2.08
D
.79
C
C
.55
B
B
A
NOTES:
1. MATERIAL: COLD ROLLED STEEL 0.024" THK
2. FINISH: BRIGHT CHROME PLATE
3. CONNECTOR HARDWARE SUPPLIED:
TWO #4 JACKSCREWS
TWO #4 SLOTTED SCREWS
TWO #4 HEX NUTS
TWO RETAINING CLIPS
B
APPROVALS
DRAWN BY
MCCORMICK
CHECKED BY
D.PARHAM
DATE
PRODUCT DESCRIPTION
12/04/2002
12/04/2002
45 BEECHWOOD DRIVE
NORTH ANDOVER, MA
01845
DB9 & HD15 SHIELDED ADAPTOR COVERS
DRAWING TITLE
A
UNLESS OTHERWISE SPECIFIED, APPROVED BY
DIMENSIONS ARE IN INCHES
TOLERANCES ARE:
12/04/2002
R.CARRICK
.X .1
.XX .05
CONFIGURATION DETAILS OF
.XXX .005
UNDIMENSIONED FEATURES
CABLE LENGTH TOLERANCE
MAY VARY
<300" ±5% >300" ±2%
OUTLINE DRAWING
SIZE
SCALE: 1:2
A
43321
2
FSCM NO.
DWG. NO.
DHS9-OD1
1
REV.
SHEET 1 OF 1
CAD FILE:
DHS9-OD1.SLDDRW
B
8
7
6
5
4
3
