DIODE
(THREE PHASES BRIDGE TYPE)
DF200AA120/160
UL;E76102 M
Power Diode Module
DF200AA
is designed for three phase full wave rectification, which
has six diodes connected in a three phase bridge configuration. The mounting base of the
module is electrically isolated from semiconductor elements for simple heatsink
Repetitive peak reverse
construction. Output DC current is 200Amp Tc 96
voltage is up to 1,600V.
TjMax 150
Isolated mounting base
High reliability by unique glass passivation
Applications
AC, DC Motor Drive/AVR/Switching
-for three phase rectification
Unit
a
Maximum Ratings
Symbol
V
RRM
V
RSM
Symbol
I
D
I
FSM
I
2
t
Tj
Tstg
V
ISO
Item
Repetitive Peak Reverse Voltage
Non-Repetitive Peak Reverse Voltage
Item
Output Current D.C.
Surge Forward Current
I
2
t
Operating Junction Temperature
Storage Temperature
Isolation Breakdown Voltage R.M.S.
Mounting
Torque
Mass
Mounting M5
Terminal M5
A.C. 1 minute
Recommended Value 1.5 2.5 15 25
Recommended Value 1.5 2.5 15 25
Typical Value
Ratings
DF200AA120
1200
1300
Conditions
Three Phase full wave. T
C
96
1 cycle, 50/60H
Z
, peak value, non-repetitive
Value for one cycle of surge current
DF200AA160
1600
1700
Ratings
200
1850/2000
6000
40
150
40
125
2500
2.7 28
2.7 28
360
Tj 25
Unit
V
V
Unit
A
A
A
2
S
V
N m
f
B
g
Electrical Characteristics
Symbol
I
RRM
V
FM
Rth j-c
Item
Repetitive Peak Reverse Current, max.
Forward Voltage Drop, max.
Thermal Impedance, max.
Tj 150
at V
RRM
Conditions
T
j
25
I
FM
200A, Inst. measurement
Junction to case
Ratings
15.0
1.35
0.10
Unit
mA
V
/W
