DB855DD90(- or E)SX
Diversity Master™
Dual Slant (+45°/-45°) Polarized
Medium Gain Panel Antenna with 90° Horizontal 3dB Coverage, 806-896 MH
Z
Model Number
Termination
Frequency Range
Gain
VSWR
Beamwidth
(3dB from max)
Front-to-Back Ratio
Polarization
Isolation
Max. Input Power
Other Information
Application
Weight
Wind Area
Wind Load
Max. Wind Speed
Material
DB855DD90-SX
DB855DD90ESX
Type N-Female
7-16 DIN ("E")
806-896 MHz
12.0 dBd (14.1 dBi)
< 1.4 : 1
Horizontal:
Vertical:
90°
12°
> 25 dB
+45° and -45°, independently
> 30 dB
90°
500 Watts, each
Dual
Trunking and Cellular
23 lbs (10.4 kg)
3.33 ft² (.31 m²)
133 lbf (593 N) 60.5 kp (at 100 mph)
125 mph (201 km/h)
Reflector:
Pass. Aluminum
Radiators:
Pass. Aluminum
Radome:
ABS UV Inhibited
Mounting Hdw: Galvanized Steel
Light Gray
DB380 pipe mount kit (max 3.5" OD),
included.
DB5083
Fully protected by backplate and radome.
All metal parts grounded.
70" x 17" x 11" (178 x 43 x 28 cm)
38 lbs (17.2 kg)
Color, Radome
Mounting
Downtilt Bracket
(Optional)
Weather Protection
Lightning Protection
Packing Size
Shipping Weight
Antenna Patterns
Dual polarized 12.0 dBd (14.1 dBi)
Directional Panel Antenna with 90°
horizontal 3 dB beamwidth for each
of the two antenna arrays housed in
one radome. Two receive arrays are
cross polarized at +45° and -45° in
their polarization plane.
Electrical Downtilt (T) Option
Model Number
855DD90T3(E)-SX
Horizontal
Vertical
Specifications are for reference only.
Downtilt
3°
Gain
11.5 dBd
099119-011-A
04/00
DECIBEL
Allen Telecom Inc.
PRODUCTS
A Division of
8635 Stemmons Freeway • P. O. Box 569610 • Dallas, Texas 75356-9610
214 / 631-0310 • Fax: 214 / 631-4706
