DIODE
TRANSFER SWITCHES
0.025 - 18 GHz
GENERAL INFORMATION
Series DTS transfer switches allow power entering two input ports, A
and B, to exit from output ports C and D respectively, or by appropriate
switching, to exit from ports D and C respectively. A functional schemat-
ic of a transfer is shown in Fig. 1, and a typical circuit is shown in Fig. 2.
SERIES DTS
GENERAL SPECIFICATIONS
Frequency Coverage:
RF Impedance:
DC Requirements:
0.025 to 18.0 GHz.
50 OHMS.
For all units with driver
Logic “0” = Ins. Loss A→C, B→D
Isol. A→D, B→C
Logic “1” = Ins. Loss A→D, B→C
Isol. A→C, B→D
Operating temperature from –55°C to
+85°C.
10% to 90% or 90% to 10% of RF. There
is an additional 20 nanosec of driver
delay.
1 sec
SMA
Temperature Information:
Switching Speed:
Typical:
Connectors:
ELECTRICAL PERFORMANCE
Frequency
Ins
Model
Range
Loss dB
No.
GHz
Maximum
DTS-12 0.025-0.25
0.75
DTS-18 0.10-0.50
1.0
DTS-27
0.5-1.0
0.8
DTS-29
DTS-33
DTS-45
DTS-48
DTS-58
DTS-75
0.5-2.0
1.0-2.0
1.7-2.4
2.0-4.0
4.0-8.0
6.0-18.0
1.0
1.0
1.2
1.5
1.8
3.2
VSWR
Maximum
1.6
1.5
1.5
1.5
1.5
1.5
1.5
1.6
2.0
Isolation
dB
Minimum
60
60
60
60
60
50
50
40
30
Maximum Power
Handling Ability
Watts PK Watts Avg.
5
1.0
5
1.0
2
0.5
5
2
5
2
5
2
1.0
0.5
1.0
0.5
1.0
0.5
KEY:
Inches[Millimeters] .XX ±.03 .XXX ±.010 [.X ±0.8 .XX ±0.25]
