OFMS Series Multi-mode 1x1, 1x2 and 2x2
(Add/Drop) Optical Fiber Switches
OFMSMM Series
Product Description
Oplink’s OFMS series optical fiber switches offer industry leading perfor-
mance specifications with Telcordia compliant reliability. The multi-mode
switches are designed for use in protection, channel selection, fiber ring
network node bypassing and testing.
These patented opto-mechanical switches can be directly mounted on print-
ed circuit boards and feature less than 0.5dB typical insertion loss. Oplink’s
unique prism design improves the switch repeatability and stability. The
OFMS switches are GR-1221 and GR-1073 qualified.
Oplink provides customized design to meet special control and applications.
Also, Oplink offers modular assemblies that integrate other components to
form a full function module or subsystem.
Performance Specificationns
Parameters
Symbol
Min
Typ.
Max
Unit
Wavelength Range
Insertion Loss
Cross-talk
Repeatability
Return Loss
Optical Input Power
Coil Resis-
tance
Durability
Cycle Rate
Switch Relay Type
Driving Voltage
2
1
λ
op
IL
770 ~ 890 and/or 1260 or 1360
1.0
40
±0.05
nm
dB
dB
dB
dB
mW
Ω
Ω
Features
RL
Latching
Non-latching
30
300
101.2 ± 10%
145 ± 10%
10
10
7
10
Two coils, latching or single coil, non-latching
Low Insertion Loss
Wide Wavelength Range
Highly Stable & Reliable
Epoxy-Free Optical Path
Latching or Non-latching Configurations
Switching Speed
ms
cycle
Hz
VDC
4.5 ~ 5.5
T
op
T
sto
0
-40
70
80
Applications
Operating Temperature
Storage Temperature
Fiber Type
Dimension
Bare fiber
°C
°C
mm
mm
Optical Bypass Protection
Optical Routing
Fiber Optic Component Test
50μm or 62.5μm core multi-mode fiber
P1: 41.5 (L) x 15.5 (W) x 9.0 (H)
P2: 44.0 (L) x 15.5 (W) x 9.0 (H)
900μm loose tube
Notes:
1) Based on FOTP-34 method A, steady state equilibrium launch conditions. Within operating tempera-
ture range. Exclude connector insertion loss.
2) A minimum >20ms pulse is recommended for latching type of switch.
R02.20090524
OFMS Series Multi-mode 1x1, 1x2 and 2x2
(Add/Drop) Optical Fiber Switches
OFMSMM Series
Function Diagram
1x1 On/Off Switch
1x2 Switch
2x2 Add/Drop Switch
46335 Landing Pkwy Fremont, CA 94538 Tel: (510) 933-7200 Fax: (510) 933-7300 Email: Sales@Oplink.com • www.oplink.com
Ordering Information
Oplink can provide a remarkable range of customized optical solutions. For detail, please contact Oplink’s OEM
design team or account manager for your requirements and ordering information (510) 933-7200.
OFMS
M
Multi-mode
Type
1x1 = 110
1x2 = 120
2x2 Add/Drop = 22A
Switch Type
Latching = 0
Non-latching = 1
Fiber Length
0.5 meter = H
1.0 meter = 1
1.5 meter = 5
2.0 meter = 2
Connector
Type
None = 1
FC/PC = 2
FC/SPC = 3
FC/APC = 4
SC/PC = 5
SC/SPC = 6
SC/APC = 7
ST = 8
LC = 9
MU = A
Wavelength
850nm = 8
1310nm = 3
850 &1310nm = D
Fiber Type
MMF 50/125 fiber = 1
MMF 62.5/125 fiber = 2
Package Type
P1 (bare fiber) = 1
P2 (900μm loose tube) = 2
Mounting Type
Dual-line pins on the bottom = 0
Single-line pins on the side with screw tabs = 1
R02.20090524
