Product Brief
X-GOLD 608-Broadband Mobile Experience
with HSDPA 7.2 Mbit/s and Multimedia Engine
WITH ITS NEW X-GOLD 608 BASEBAND, Infineon Technologies extends its well
known X-GOLD baseband family to support the 3.5G mobile phone generation. The
integrated dual-mode HSDPA/WCDMA/E-GPRS modem technology, together with
high speed multimedia hardware accelerators and the advanced connectivity op-
tions enable X-GOLD 608 to fulfill the requirements of tomorrow‘s mobile phones.
INFINEON is one of the early platform vendors to support HSDPA category 8
(7.2Mbit/s). The implementation of equalizer based advanced receiver techno-
logy improves the data throughput, especially at high data rates, by up to 40%.
In addition, the software programmable slot processing in the HSDPA Rx path
provides further flexibility for performance enhancements. The HSDPA perfor-
mance of X-GOLD 608 meets and exceeds all test cases as specified in the 3GPP
standard.
INFINEON‘s 3.5 G physical layer architecture is future-proof and designed for an
easy upgrade to higher HSDPA data rates, HSUPA and also Rx-diversity.
Key Modem Features
HSDPA - category 8 (7.2Mbit/s)
–
Implementation of fractional chip rate
equalizer
–
Configurable to lower categories / data
rates
–
Option to switch off HSDPA to save power
WCDMA
–
384kbit/s class for uplink and downlink
–
640kbit/s peak data rates for uplink and
downlink independently
EDGE multislot class 12
GPRS/GSM
FR, HR, EFR, AMR
SAIC
Tx diversity
DTM class 11
Polyphonic Ringer support for up to 64
voices at up to 48 kHz sampling rate
Echo cancellation/noise reduction
GTT/TTY
PMB8878
Key Application Features
ARM 926 based single modem and
application processor with cache
support and fast tightly-coupled
memories
Hardware Crypto box - DRM 2.0, SIM
Lock, IMEI protection
Hardware security - E-fuse, Boot Code
Protection, Secure Mode
CPU, RGB display interface supporting
high resolution color displays up to
HVGA
High-speed serial display interface for
cost effective clamshell mechanics up
to HVGA
Support of cameras up to 5 MPixel
MPEG4/H.263 hardware accelerator
MP3, AAC, AAC+, enhanced AAC+
2D Graphic hardware
Support for video telephony, strea-
ming, recording and playback
2 x MMC/SD interfaces, SDIO capable
USB 2.0 on-the-go, full speed
Fast IRDA
Multimedia extension interface (MMIC-
IF) for support of high end graphic
accelerators
2 bi-directional digital audio interfaces
(I2S) to connect audio companion ICs
and Bluetooth modules
Dedicated NAND flash controller sup-
porting burst mode and error detection
Support of DDR-SDRAM devices
www.infineon.com/mobilesolutions
Product Brief
X-GOLD 608-Broadband Mobile Experience with HSDPA 7.2 Mbit/s
and Multimedia Engine
Block Diagram X-GOLD 608
Oscillators
NOR / NAND
FLASH
SDR or DDR
SD-RAM / C-RAM
Debug
PMB8878
Analog
Front End
A
Audio
Headset
Aux
Audio
Microphone
Speaker
FM Stereo
A
A
D
A
I/Q
D
D
D
D
A
D
A
Timers/RTC
Flash / DDR SDR RAM Controller
JTAG
GPIOs
Touch Screen
Measurements
Audio
FE
ARM
®
926 EJ-S
MOVE CoPro
SRC
Interrupt Controller, Timers, Flags, DMAs
Ciphering f8 f9
A51/A52/A53/GEA1/GEA2/GEA3 CRC
Secure Boot Code, Firmware
2D Engine
E-GPRS Accelerators
Crypto Box
RSA AES DES SHA-1 MD5 Random
SRAM
ROM
USB 2.0
FS OTG
Keypad
Keypad
Multimedia
IC IF
Camera IF
I
2
C
MMC IF
SDIO IF
MMC IF
SDIO IF
USIM
ARM
®
7
TDMI-S
MMC Card
Camera
Module
Mem ory
DSP
Display
Par
allel/
Hig Speed
h
Ser
ial/RGB
HVGA
Color TFT
Display
Secondary
Display
BB Receiver
8 PSK/GMSK
Modulator
RF Control
Infineon/
Global Locate
A-GPS
Hammerhead
PMB 2520
In neon RF
SMARTi
3GE+
PMB 6950
D
A
D
D
A
D
A
A
AFC
WLAN connectivity
UMT S-A era s
ccel tor
3G-Sys-IF
I
2
C
1 Wire
SRC
I S
2
SIM Card
I
2
S
USIF
USIF
USIF
X- LD 608
GO
(PMB 8878)
Infineon Power Management
SM-POWER3
PMB 6821
Fast
IrDA
Battery
Digital
Audio
Source
Infineon Bluetooth
BlueMoon UniCellular
PMB 8753
Debug
Infrared
USB FS
OTG
X-GOLD 608 with its ARM 926 CPU, capable of processing speeds
of up to 312MHz, is extending the capabilities of wireless multimedia
without the need for a dedicated Application Processor. The powerful
multimedia engine integrated with the advanced dual-mode HSDPA/WCDMA/
E-GPRS modem technology enables a wide spectrum of multimedia functio-
nalities, mobile entertainment and office applications with high data rates
of up to 7.2Mbit/s. X-GOLD 608 based platforms enable handsets to provide
consumer electronic quality such as camera support of up to 5 MPixel as
well as video telephony, streaming, recording and playback with up to 30
frames per second and a resolution of up to 320 x 480 pixels (HVGA) in
MPEG4, H.264 or Real video formats and advanced audio codecs, like en-
hanced AAC+. THE OPTIMIZED X-GOLD 608 architecture makes it possible for
the users to run several applications simultaneously; e. g. surf the internet,
download emails or data to a SD-card with HSDPA category 8 (7.2Mbit/s)
while listening to MP3 music over a stereo Bluetooth headset.
Key Benefits:
High integration level of key multimedia
features allows minimum cost of system
solutions for tomorrow‘s feature phones
High overall system performance with high
speed ARM subsystem and double-data rate
memory access
Proven leading-edge modem technology with
WCDMA, HSDPA Cat. 8 as well as third
generation E-GPRS evolution
Feature upgrade flexibility through optional
companion/multimedia chips via standar-
dized interface
Support of connectivity modules such as
Bluetooth, WLAN, A-GPS, DVB-H, FM Radio,
etc.
