AC-DC
175 Watts
RCL175 Series
•
•
•
•
•
•
•
200 W Peak Rating
xppower.com
Up to 120 W Convection-cooled
Industrial and Medical Approvals
Low Leakage Current
Class I & Class II Applications
Flexible Design for Modified Standards
Connector & Mechanical Options
Specification
Input
• 85-264 VAC (120-370 VDC) See note 3
• 47-63 Hz
• 2.1 A max at 115 VAC
0.9 A max at 230 VAC
Inrush Current
• 17 A max at 115 VAC, 35 A max at
230 VAC, cold start at +25 °C
Power Factor
• Complies with EN61000-3-2 for
Class A equipment
Earth Leakage Current
• 120 µA max at 115 VAC
200 µA max at 230 VAC
Input Protection
• 3.15 A line and neutral fused
Input Voltage
Input Frequency
Input Current
General
Efficiency
Isolation
• 80-90% depending on model
• 4000 VAC Input to Output
1500 VAC Input to Ground
1500 VAC Output to Ground open frame
(For BF applications, consult sales office)
500 VAC Output to Ground U channel
& covered
• PFC 75 kHz typical, PWM 60 kHz typical
• Power fail - open collector output
referenced to 0 V sense
• See Application Notes
• See Application Notes
• 385 kHrs typical at +25 °C per
MIL-HDBK-217F
Switching Frequency
Signals
Remote Sense
Remote On/Off
MTBF
Output
• See models and ratings table
• ±10% output 1 via pot, outputs 2-4 track
by same percentage
Initial Set Accuracy
• ±2% of nominal at 50% load
Minimum Load
• See models & ratings table
Start Up Delay
• <2 s
Start Up Rise Time
• <100 ms
Hold Up Time
• 20 ms min at nominal low line
& maximum power
Drift
• <±0.2% after 20 mins warm up
Line Regulation
• ±0.5% of nominal over full input range
Load Regulation
• PQ42 & 43: V1 & V2 ±3%, V3 & V4 ±5% of
nominal, all other models: V1 ±1%, V2, V3
& V4 ±5% of nominal
Transient Response
• 4% max deviation, recovery to within 1%
in 500 µs for a 25% load change at 1 A/µs
Ripple & Noise
• 50 mV (Vo=<5 V), 120mV (Vo=12, 15 V),
200 mV (Vo=24, 48 V). Measured pk-pk
with a 20 MHz bandwidth
Overvoltage Protection
• 115-140% - V1 only. Cycle mains to reset
Overtemperature
• Fitted with auto restart
Protection
Overload Protection
• 110-125% - Primary side power limiting
with auto recovery. Constant current limit
for single output models and foldback
current limit for multi output models.
V3 & V4 PTC resetting fuses
Temperature
• 0.02%/°C
Coefficient
Output Voltage
Output Voltage Trim
Environmental
Operating Temperature
• -10 °C to +50 °C at full power, derate to
50% power at +70 °C
Operating Humidity
• 5-95% RH, non-condensing
Storage Temperature
• -20 °C to +85 °C
Operating Altitude
• 3000m
Shock
• 30 g peak, half sine, 6 axes
Vibration
• 2 g rms, 5-500 Hz, 3 axes
EMC & Safety
Emissions
Harmonic Currents
Voltage Flicker
ESD Immunity
Radiated Immunity
EFT/Burst
Surge
Conducted Immunity
Dips & Interruptions
• EN55011/22 class B conducted,
class A radiated
• EN61000-3-2 for class A equipment
• EN61000-3-3
• EN61000-4-2, Level 3 Perf Criteria A
• EN61000-4-3, 10 V rms 80% mod,
Perf Criteria A
• EN61000-4-4, Level 3 Perf Criteria A
• EN61000-4-5, Level 3 Perf Criteria A
• EN61000-4-6, Level 3 Perf Criteria A
• EN61000-4-11, 30% 10 ms,
60% 100 ms, 100% 5000 ms,
Perf Criteria A, B, B
• EN60601-1-1, EN60950-1:2001,
UL/cUL60950:2003, CSA60601.1,
UL60601-1:2003.
Safety Approvals
AC-DC
Models and Ratings
Total Power
Max
(7)
RCL175
Output 2
(6)
Peak
(1)
Output 1
(4,5)
Output 3
(6,8)
Peak
(1)
Output 4
(6,8)
Max
V
Min
Max
Peak Conv.
204 W
195 W
200 W
200 W
202 W
200 W
200 W
200 W
200 W
200 W
200 W
200 W
200 W
V
Min
0.0 A
0.0 A
0.0 A
0.0 A
0.0 A
1.5 A
1.5 A
1.5 A
1.5 A
1.5 A
1.5 A
1.5 A
1.5 A
Max
V
Min
Max
V
Min
Model
Number
RCL175PS12
RCL175PS15
RCL175PS24
RCL175PS28
RCL175PS48
175 W
175 W
175 W
175 W
175 W
175 W
175 W
175 W
175 W
175 W
175 W
175 W
175 W
120 W 12.0 V
120 W 15.0 V
120 W 24.0 V
120 W 28.0 V
120 W 48.0 V
110 W
110 W
110 W
90 W
90 W
90 W
90 W
90 W
5.0 V
5.0 V
5.0 V
5.0 V
5.0 V
5.0 V
5.0 V
5.0 V
14.5 A 17.0 A
11.6 A 13.0 A
7.2 A
6.2 A
3.6 A
15.0 A
15.0 A
15.0 A
15.0 A
15.0 A
15.0 A
15.0 A
15.0 A
8.3 A
7.1 A
4.2 A
-
-
-
-
-
-
-
-
12.0 V
12.0 V
15.0 V
3.3 V
12.0 V
15.0 V
24.0 V
24.0 V
0.1 A
0.1 A
0.1 A
0.1 A
0.1 A
0.1 A
0.1 A
0.1 A
8.3 A
6.3 A
4.6 A
15.0 A
5.5 A
4.0 A
3.2 A
3.0 A
10.4 A
8.4 A
6.6 A
-
7.6 A
6.0 A
5.0 A
5.0 A
F 12 V
F 15 V
F 15 V
F5V
F5V
F 12 V
F 15 V
0.1 A
0.1 A
0.1 A
0.1 A
0.1 A
0.1 A
0.1 A
2.0 A
2.0 A
2.0 A
2.0 A
2.0 A
2.0 A
2.0 A
F 15 V
F 12 V
F 15 V
F 12 V
F 15 V
0.1 A
0.1 A
0.1 A
0.1 A
0.1 A
2.0 A
2.0 A
2.0 A
2.0 A
2.0 A
RCL175PD22
(4,6)
RCL175PT31
(4,6)
RCL175PT32
(4,6)
RCL175PQ43
(5,6)
RCL175PQ44
(6)
RCL175PQ45
(4,6)
RCL175PQ46
(4,6)
RCL175PQ47
(4,6)
Notes
1. Peak rating can be taken for 5 seconds in every minute. Average power not
to exceed maximum power.
2. There is a user-accessible fan supply rated at 12 V at 350 mA
(not available on fan-cooled units).
3. For operation at 85 VAC output power is derated to 95%.
4. Output 1 10 A max convection-cooled.
5. 20 A max from output 1 and 2 combined convection-cooled.
6. A minimum load of 100 mA is required on output 2, 3 and 4 to maintain the
regulation figures.
7. 12 CFM airflow required for maximum power.
8. Outputs 3 & 4 are floating, they can be connected externally for positive or
negative output.
9. Connector kits and cable harnesses available. Consult sales for options.
Pin Connectors
Pin
1
2
3
INPUT CONNECTOR - P1
Function
Live
N/C
Neutral
Application Notes
Remote Sense
Power Fail
Remote On/Off
-
-
-
V1 only, compensates for 0.5 V or 10% whichever is lower.
Open collector output refers to 0 V sense (when using the
power fail signal, -Sense must be connected to 0 V).
Connect pin 1 (P3) to 0 V to disable unit (optional remote
enable specify suffix ‘-E’ with the model number).
Applying a logic ‘0’ will also disable the unit.
P1 is a 3-way 0.156" pitch square pin header
Molex housing 09-91-0300 pins 08-50-0106
(24-18 AWG) 08-50-0108 (28-22 AWG)
OUTPUT CONNECTOR - P2
Function
+Output 1
+Output 1
+Output 1
0V
0V
0V
0V
0V
0V
+Output 2
+Output 2
+Output 2
-Output 3
+Output 3
-Output 4
+Output 4
Options
• For the U-channel version, add suffix ‘-U’ to the model number.
• For the U-channel version with cover kit, add suffix ‘-C’ to the model number.
• For the U-channel version with fan cover kit, add suffix ‘-F’ to the model number.
• For screw terminals (output connector P2 only), add suffix ‘-S’ to the model number.
• For versions with remote enable, contact sales.
• For foldback current limit on single output models, contact sales.
• For constant current limit (output 1 & 2) on multi-output models, contact sales.
Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Connector Info
For all formats, output connector P2 as follows:
Single Output Models:
6-way 0.156" pitch square pin header
Molex housing 09-91-0600
Pins 08-50-0106 (24-18 AWG) 08-50-0108 (28-22 AWG)
Dual Output Models:
12-way 0.156" pitch square pin header
Molex housing 09-91-1200
Pins 08-50-0106 (24-18 AWG) 08-50-0108 (28-22 AWG)
Triple Output Models:
14-way 0.156" pitch square pin header
Molex housing 09-91-1400
Pins 08-50-0106 (24-18 AWG) 08-50-0108 (28-22 AWG)
Quad Output Models:
16-way 0.156" pitch square pin header
Molex housing 09-91-1600
Pins 08-50-0106 (24-18 AWG) 08-50-0108 (28-22 AWG)
SIGNALS CONNECTOR - P3
Pin
Function
1
Remote On/Off
2
+Sense
3
-Sense
4
PF signal
5
0 V fan supply
6
+12 V fan supply
P3 is a 6-way 0.1" pitch square pin header
Molex housing 22-01-2065 pins 08-50-0032
AC-DC
Mechanical Details
All dimensions are in inches (mm)
U-channel & Cover
5.71
(145.0)
0.24
(6.1)
5.23
(132.7)
0.89
(22.5)
RCL175
Weight:
1.76 lbs (800 g) approx.
Pin 16
3.90
(99.0)
3.26
(82.9)
P2
P1
2
2.95
(75.0)
0.14
(3.5)
MOUNTING HOLE
(4 POSITIONS)
0.47
(12.0)
3.94
(100.0)
8-32 UNC MOUNTING HOLE
(IN 4 POSITIONS)
M3 MOUNTING HOLE
(IN 4 POSITIONS )
Pin 1
Earth/Safety Ground Tag
M3 MOUNTING HOLE
(IN 2 POSITIONS EACH SIDE)
1.18
(30.0)
3.35
(85.0)
0.55
(14.1)
4.60
(116.8)
Note:
1. Suitable for class I operation only.
2. Mounting screws must not penetrate by
more than 0.12” (3.0 mm) max
1.60
(40.8)
2.50
(63.5)
8-32 UNC MOUNTING HOLE
(IN 2 POSITIONS, EACH SIDE)
1.59
(40.4)
U-channel & Fan Cover
5.71
(145.0)
0.74
(1.87)
Weight:
1.98 lbs (900 g) approx.
0.89
(22.5)
0.47
(12.0)
3.94
(100.0)
0.24
(6.1)
5.23
(132.7)
Pin 16
3.90
(99.0)
3.26
(82.9)
P2
P1
2
2.95
(75.0)
0.14
(3.5)
MOUNTING HOLE
(4 POSITIONS)
8-32 UNC MOUNTING HOLE
(IN 4 POSITIONS)
M3 MOUNTING HOLE
(IN 4 POSITIONS)
Pin 1
Earth/Safety Ground Tag
1.18
(30.0)
3.35
(85.0)
M3 MOUNTING HOLE
(IN 2 POSITIONS, EACH SIDE)
2.14
(54.4)
4.60
(116.8)
0.55
(14.1)
Note:
1. Suitable for class I operation only.
2. Mounting screws must not penetrate by
more than 0.12” (3.0 mm) max
1.60
(40.8)
2.50
(63.5)
8-32 UNC MOUNTING HOLE
(IN 2 POSITIONS, EACH SIDE)
1.57
(40.0)
0.74
(18.7)
03-Jul-08
