RGL341A thru RGL341M
SURFACE MOUNT GLASS PASSIVATED FAST SWITCHING RECTIFIERS
DO-213AA / MINI MELF
SOLDERABLE ENDS
D1= 0.066(1.676)
0.060(1.524)
CATHODE BAND
D2
0.022(0.559)
0.016(0.406)
0.145(3.683)
0.131(3.327)
D2=D1 +0
-0.008(0.20)
Dimension in inches (millimeters )
FEATURES
Ldeal for surface mounted applications
Low leakage current
Glass passivated chips
Fast switching
High temperature soldering guaranteed
250
o
C/10 seconds/.375 , (9.5mm) lead lengths
MECHANICAL DATA
Molded plastic use UL94V-0 recoqnized
flame retardant epoxy
Terminals Plated terminals, solderable per
MIL-STD-202, Method208
Polarity Red Color band on body denotes cathode
Mounting position Any
Weight 0.036gram
Case
MAXIMUM RATIXGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25
o
C ambient temp. unless otherwise specified
Single phase, half sine wave, 60Hz, resistive or inductive load
For capacitive load, derate current by 20%
SYMBOL
Maximum Current Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current T
T
=55 C
Peak Forward Surge Current Single Sine-Wave on Rated
Load (JEDEC Method)
Maximum Instantaneous Forward Voltage Drop at 1.0A DC
Maximum DC Reverse Current @T
A
=25
0
C
at Rated DC Blocking Voltage T
A
=125
0
C
Maximum Reverse Recovery Time, Time,Test Conditions
I
F
=0.5A, I
R
=1.0A , I
RR
=0.25A
Typical Junction Capacitance
Operating Junction and Storage Temperature Range
0
RGL
341A
RGL
341B
RGL
341D
RGL
341G
RGL
341J
RGL
341K
RGL
341M
UNITS
Volts
Volts
Volts
Amps
Amps
Volts
A
V
RRM
V
RMS
V
DC
I
(AV)
I
FSM
V
F
I
R
50
35
50
100
70
100
200
140
200
400
280
400
1.0
10
1.3
5.0
100
600
420
600
800
560
800
1000
700
1000
T
RR
C
J
T
J
T
STG
150
15
250
500
nS
pF
0
-55 to +150
C
