5-555066-1 Product Details
Live Product Chat
2.16 [.085] IDC Connectors
Always EU R oHS/ELV C om plia nt
(
Sta te m e nt of C om plia nce
)
No Im a ge Ava ila ble
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
5-555066-1
T E I nternal N umber: 5 - 5 5 5 0 6 6 - 1
Product Highlights:
l
C onnector
l
Number of Positions = 36
l
Product C ategory = C onnectors
l
Receptacle
l
Not Shielded
View all Features
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Obsolete
Search for Replacement Parts
Buy P roduc t
Documentation & Additional Information
Documents are temporarily unavailable. We are working hard to correct the problem. Please try
again later.
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= C onnector
l
Product C ategory = C onnectors
l
Number of Positions
= 36
l
Gender
= Receptacle
l
Shielded
= No
l
Mating C onnector Lock
= With
l
Mating C onnector Lock Type = Bail Lock, Screwlocks
l
Slot Type Letter C ode
= F
l
Wire/C able Type
= 7 Strand, Solid
l
Insulation Diameter (mm [in]) = 1.14-1.42 [.045-.056]
l
Profile = Standard
l
C onnector Style = RP
Mechanical Attachment:
l
Panel Attachment
= With
l
Flange Thickness = Thin
Body Related Features:
l
Wire Range (Solid) (mm [AWG])
= 0.64 [22]
l
Wire Range (Stranded) (mm? [AWG])
= 0.40² [22]
Contact Related Features:
l
C ontact Mating Area Plating Material = Gold (30)
Housing Related Features:
l
Housing C olor Dot Designation = Brown
Industry Standards:
l
RoHS/ELV C ompliance
= RoHS compliant, ELV compliant
l
Lead Free Solder Processes
= Not relevant for lead free process
l
RoHS/ELV C ompliance History = Always was RoHS compliant
Packaging Related Features:
l
Packaging Method
= Tray
Other:
l
Brand = AMP
