High Current/High Voltage
Single Line
Feed-thru Filters
Features
s
Single Line Filters
s
s
s
Available for applications utilizing 400-600VDC,
or 250VAC
L and Pi configurations
Insertion loss of 60 dB at 150 KHz
Threaded neck mounting
Electrical Specifications
Voltage:
125 & 250VAC, 0-400 Hz
400 & 600VDC
Applications
s
s
s
s
s
High voltage medical equipment
C.O.T.S. (Commercial-Off-The-Shelf) military (meets
or exceeds the standard listed in MIL-STD-220A)
Industrial equipment and controls
Telecommunication base stations
Data transmission equipment
Designed to meet MIL-F-15733/72/73/74
Other configurations available: T, LL
Max. Voltage Drop:
1% of rated voltage
Temperature Range:
-55C˚ to +85C˚ without derating
Insulation Resistance:
in excess of 1000 MΩ
D.C. Test Voltage:
4.2x rated A.C. voltage
(in accordance with Method
301 MIL-STD-202 with
voltage applied thru resistance
of 1 ohm/voltage minimum for
one minute)
(minimum dB at 150KHz)
(in accordance with MIL-STD-220A)
30 dB
60 dB
Options:
s
s
Insertion Loss:
Attenuation:
L Circuits:
Pi Circuits:
Performance Curves
Typical Insertion Loss per MIL-STD-220A (under full load)
“L” CIRCUIT
“Double L” CIRCUIT
“Pi” CIRCUIT
“T” CIRCUIT
16
SPECTRUM CONTROL INC.
• 8031 Avonia Rd. • Fairview, PA 16415 • Phone: 814-835-1650 • Fax: 814-835-1651 • Web site: www.spectrumcontrol.com
SPECTRUM CONTROL GmbH
• Hansastrasse 6 • 91126 Schwabach, Germany • Phone: (49)-9122-795-0 • Fax: (49)-9122-795-58
High Current/High Voltage
Single Line
Feed-thru Filters
“L” Circuit
Single Line Filters
17
Part No. w/
Capacitor on
Threaded End
Current
Rating
(Amps)
A
Dia.
1.00
1.00
1.00
1.25
1.25
1.50
1.75
2.00
2.25
1.00
1.00
1.00
1.25
1.25
1.50
1.75
2.00
2.25
B
Lgth.
1.50
2.00
2.75
2.06
3.50
3.69
3.50
3.31
4.25
1.63
2.38
2.13
2.19
2.88
4.44
3.69
3.50
4.56
C
Thread
Lgth.
.345
.345
.345
.407
.407
.407
.407
.595
.563
.345
.345
.345
.407
.407
.407
.407
.595
.563
C
Thread
Lgth.
.345
.345
.345
.407
.407
.407
.407
.595
.563
.345
.345
.345
.407
.407
.407
.407
.595
.563
D
Threads
7/16-20
7/16-20
7/16-20
3/4-20
3/4-20
3/4-20
3/4-20
1-1/8-18
1-1/8-18
7/16-20
7/16-20
7/16-20
3/4-20
3/4-20
3/4-20
3/4-20
1-1/8-18
1-1/8-18
E
F
G
125/208 Volts AC / 400VDC
5004-7068
.5
5004-7072
1.0
5004-7076
2.5
5004-7080
5.0
5004-7084
10.0
5004-7088
15.0
5004-7092
20.0
5004-7096
30.0
5004-6999
50.0
250/440 Volts AC / 600VDC
5004-7069
.5
5004-7073
1.0
5004-7077
2.5
5004-7081
5.0
5004-7085
10.0
5004-7089
15.0
5004-7093
20.0
5004-7097
30.0
5004-6998
50.0
.406
.406
.406
.484
.484
.750
.750
.750
.968
.406
.406
.406
.484
.484
.750
.750
.750
.968
.375
.375
.375
.453
.453
.687
.687
.703
.750
.375
.375
.375
.453
.453
.687
.687
.703
.750
.375
.375
.375
.659
.659
.659
.659
1.049
1.051
.440
.440
.440
.659
.659
.659
.659
1.049
1.051
“Pi” Circuit
Part No. w/
Capacitor on
Threaded End
Current
Rating
(Amps)
A
Dia.
1.00
1.00
1.00
1.25
1.25
1.50
1.75
2.00
2.25
1.00
1.00
1.00
1.25
1.25
1.50
1.75
2.00
2.25
B
Lgth.
1.50
2.00
2.75
2.06
3.50
3.69
3.50
3.31
4.25
1.63
2.38
2.13
2.19
2.88
4.44
3.69
3.50
4.56
D
Threads
7/16-20
7/16-20
7/16-20
3/4-20
3/4-20
3/4-20
3/4-20
1-1/8-18
1-1/8-18
7/16-20
7/16-20
7/16-20
3/4-20
3/4-20
3/4-20
3/4-20
1-1/8-18
1-1/8-18
E
F
G
125/208 Volts AC / 400VDC
5004-7040
.5
5004-7043
1.0
5004-7046
2.5
5004-7049
5.0
5004-7052
10.0
5004-7055
15.0
5004-7058
20.0
5004-7061
30.0
5004-7064
50.0
250/440 Volts AC / 600VDC
5004-7041
.5
5004-7044
1.0
5004-7047
2.5
5.0
5004-7050
10.0
5004-7053
5004-7056
15.0
5004-7059
20.0
5004-7062
30.0
5004-7065
50.0
.406
.406
.406
.484
.484
.750
.750
.750
.968
.406
.406
.406
.484
.484
.750
.750
.750
.968
.375
.375
.375
.453
.453
.687
.687
.703
.750
.375
.375
.375
.453
.453
.687
.687
.703
.750
.375
.375
.375
.659
.659
.659
.659
1.049
1.051
.440
.440
.440
.659
.659
.659
.659
1.049
1.051
