HA16158FP-E: Description1A POWER FACTOR CONTROLLER WITH POST REGULATOR, 143kHz SWITCHING FREQ-MAX, PDSO16, 5.50 X 10.06 MM, 1.27 MM PITCH, PLASTIC, SOP-16; CategoryPower/power management The power supply circuit; File Size229KB，24 Pages; ManufacturerRenesas Electronics Corporation; Websitehttps://www.renesas.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

HA16158FP-E Overview

1A POWER FACTOR CONTROLLER WITH POST REGULATOR, 143kHz SWITCHING FREQ-MAX, PDSO16, 5.50 X 10.06 MM, 1.27 MM PITCH, PLASTIC, SOP-16

HA16158FP-E Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Renesas Electronics Corporation
Parts packaging code	SOIC
package instruction	SOP,
Contacts	16
Reach Compliance Code	unknown
ECCN code	EAR99
Factory Lead Time	1 week
Other features	THE PFC SECTION EMPLOYS AVERAGE CURRENT MODE PWM
Analog Integrated Circuits - Other Types	POWER FACTOR CONTROLLER WITH POST REGULATOR
control mode	CURRENT-MODE
Control Technology	PULSE WIDTH MODULATION
Maximum input voltage	25.5 V
Minimum input voltage	10.6 V
Nominal input voltage	12 V
JESD-30 code	R-PDSO-G16
JESD-609 code	e6
length	10.06 mm
Humidity sensitivity level	1
Number of functions	1
Number of terminals	16
Maximum operating temperature	125 °C
Minimum operating temperature	-40 °C
Maximum output current	1 A
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	260
Certification status	Not Qualified
Maximum seat height	2.2 mm
surface mount	YES
Switch configuration	SINGLE
Maximum switching frequency	143 kHz
Temperature level	AUTOMOTIVE
Terminal surface	TIN BISMUTH
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	20
width	5.5 mm

Preview

Download Datasheet

View All

HA16158P/FP

PFC & PWM Control IC

REJ03F0147-0200

Rev.2.00

Jan 30, 2007

Description

The HA16158 is a power supply controller IC combining an AC-DC converter switching controller for power factor

correction and an off-line power supply switching controller. The PFC (power factor correction) section employs

average current mode PWM and the off-line power supply control section employs peak current mode PWM.

The HA16158 allows the operating frequency to be varied with a single timing resistance, enabling it to be used for a

variety of applications.

The PFC operation can be turned on and off by an external control signal. Use of this on/off function makes it possible

to disable PFC operation at a low line voltage, or to perform remote control operation from the transformer secondary

side.

The PWM controller includes a power-saving function that reduces the operating frequency to a maximum of 1/64 in

the standby state, greatly decreasing switching loss.

The PFC section and PWM section are each provided with a soft start control pin, enabling a soft start time to be set

easily.

Features



Supply voltage Vcc: 24 V



Operating junction temperature Tjopr: –40°C to +125°C



VREF output voltage VREF: 5.0 V ± 2%



UVLO start threshold VH: 16.0 V ± 1.0 V



UVLO shutdown threshold VL: 10.0 V ± 0.6 V



PFC output maximum duty cycle Dmax-pfc: 95% typ.



PWM output maximum duty cycle Dmax-pwm: 45% typ.



Synchronized PFC and PWM timing



PFC function on/off control



PWM power-saving function (frequency reduced to maximum of 1/64)



PWM overvoltage latch protection circuit



Soft start control circuits for both PFC and PWM



Package lineup: SOP-16/DILP-16

Rev.2.00 Jan 30, 2007 page 1 of 23

HA16158FP-E Related Products

	HA16158FP-E	HA16158P-E
Description	1A POWER FACTOR CONTROLLER WITH POST REGULATOR, 143kHz SWITCHING FREQ-MAX, PDSO16, 5.50 X 10.06 MM, 1.27 MM PITCH, PLASTIC, SOP-16	1A POWER FACTOR CONTROLLER WITH POST REGULATOR, 143kHz SWITCHING FREQ-MAX, PDIP16, DIP-16
Is it Rohs certified?	conform to	conform to
Maker	Renesas Electronics Corporation	Renesas Electronics Corporation
Parts packaging code	SOIC	DIP
package instruction	SOP,	DIP,
Contacts	16	16
Reach Compliance Code	unknown	unknown
ECCN code	EAR99	EAR99
Factory Lead Time	1 week	1 week
Other features	THE PFC SECTION EMPLOYS AVERAGE CURRENT MODE PWM	THE PFC SECTION EMPLOYS AVERAGE CURRENT MODE PWM
Analog Integrated Circuits - Other Types	POWER FACTOR CONTROLLER WITH POST REGULATOR	POWER FACTOR CONTROLLER WITH POST REGULATOR
control mode	CURRENT-MODE	CURRENT-MODE
Control Technology	PULSE WIDTH MODULATION	PULSE WIDTH MODULATION
Maximum input voltage	25.5 V	25.5 V
Minimum input voltage	10.6 V	10.6 V
Nominal input voltage	12 V	12 V
JESD-30 code	R-PDSO-G16	R-PDIP-T16
JESD-609 code	e6	e4
length	10.06 mm	19.2 mm
Humidity sensitivity level	1	1
Number of functions	1	1
Number of terminals	16	16
Maximum operating temperature	125 °C	125 °C
Minimum operating temperature	-40 °C	-40 °C
Maximum output current	1 A	1 A
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	SOP	DIP
Package shape	RECTANGULAR	RECTANGULAR
Package form	SMALL OUTLINE	IN-LINE
Peak Reflow Temperature (Celsius)	260	NOT SPECIFIED
Certification status	Not Qualified	Not Qualified
Maximum seat height	2.2 mm	5.06 mm
surface mount	YES	NO
Switch configuration	SINGLE	SINGLE
Maximum switching frequency	143 kHz	143 kHz
Temperature level	AUTOMOTIVE	AUTOMOTIVE
Terminal surface	TIN BISMUTH	NICKEL PALLADIUM GOLD
Terminal form	GULL WING	THROUGH-HOLE
Terminal pitch	1.27 mm	2.54 mm
Terminal location	DUAL	DUAL
Maximum time at peak reflow temperature	20	NOT SPECIFIED
width	5.5 mm	7.62 mm
