ILC7280AR2530X datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Power/power management> The power supply circuit> ILC7280AR2530X

ILC7280AR2530X: DescriptionDUAL OUTPUT, FIXED POSITIVE LDO REGULATOR, PDSO8, MSOP-8; CategoryPower/power management The power supply circuit; File Size1MB，10 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/

Download Datasheet Parametric Compare View All

ILC7280AR2530X Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	ILC7280AR2530X	-	-	View	Buy Now

ILC7280AR2530X Overview

DUAL OUTPUT, FIXED POSITIVE LDO REGULATOR, PDSO8, MSOP-8

ILC7280AR2530X Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	Rochester Electronics
Parts packaging code	MSOP
package instruction	VSSOP,
Contacts	8
Reach Compliance Code	unknown
Maximum drop-back voltage 1	0.18 V
Maximum drop-back voltage 2	0.18 V
Maximum input voltage	9 V
Minimum input voltage	3.18 V
JESD-30 code	S-PDSO-G8
JESD-609 code	e3
length	3 mm
Humidity sensitivity level	1
Number of functions	1
Output times	2
Number of terminals	8
Working temperatureTJ-Max	150 °C
Working temperature TJ-Min	-65 °C
Maximum output current 1	0.15 A
Maximum output current 2	0.15 A
Maximum output voltage 1	2.525 V
Minimum output voltage 1	2.475 V
Nominal output voltage 1	2.5 V
Maximum output voltage 2	3.03 V
Minimum output voltage 2	2.97 V
Nominal output voltage 2	3 V
Package body material	PLASTIC/EPOXY
encapsulated code	VSSOP
Package shape	SQUARE
Package form	SMALL OUTLINE, VERY THIN PROFILE, SHRINK PITCH
Peak Reflow Temperature (Celsius)	260
Certification status	COMMERCIAL
Regulator type	FIXED POSITIVE MULTIPLE OUTPUT LDO REGULATOR
Maximum seat height	0.94 mm
surface mount	YES
technology	CMOS
Terminal surface	MATTE TIN
Terminal form	GULL WING
Terminal pitch	0.65 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
width	3 mm
