ZMY1 THRU ZMY100
ZENER DIODES
MELF
FEATURES
♦
Silicon Planar Power Zener Diodes
♦
For use in stabilizing and clipping circuits with higher
power rating.
♦
The Zener voltages are graded according to the
international E24 standard. Smaller voltage tolerances
and other Zener voltages are available upon request.
♦
These diodes are also available in the DO-41 case with the type
designation ZPY1 … ZPY100.
Cathode Mark
.102 (2.6)
.094 (2.4)
.022 (0.55)
.205 (5.2)
.189 (4.8)
Dimensions are in inches and (millimeters)
MECHANICAL DATA
Case:
MELF Glass Case
Weight:
approx. 0.25 g
MAXIMUM RATINGS
Ratings at 25°C ambient temperature unless otherwise specified.
SYMBOL
VALUE
UNIT
Zener Current (see Table “Characteristics”)
Power Dissipation at T
amb
= 25°C
Junction Temperature
Storage Temperature Range
P
tot
T
j
T
S
1.0
1)
150
– 55 to +150
W
°C
°C
Characteristics at Tamb = 25 °C
SYMBOL
MIN.
TYP.
MAX.
UNIT
Thermal Resistance
Junction to Ambient Air
R
thJA
–
–
170
1)
°C/W
NOTES:
(1) Valid provided that electrodes are kept at ambient temperature.
12/16/98
ZMY1 THRU ZMY100
ELECTRICAL CHARACTERISTICS
Ratings at 25°C ambient temperature unless otherwise specified.
Zener
voltage
(2)
at
I
ZT
Type
ZMY1
(3)
ZMY3.9
ZMY4.3
ZMY4.7
ZMY5.1
ZMY5.6
ZMY6.2
ZMY6.8
ZMY7.5
ZMY8.2
ZMY9.1
ZMY10
ZMY11
ZMY12
ZMY13
ZMY15
ZMY16
ZMY18
ZMY20
ZMY22
ZMY24
ZMY27
ZMY30
ZMY33
ZMY36
ZMY39
ZMY43
ZMY47
ZMY51
ZMY56
ZMY62
ZMY68
ZMY75
ZMY82
ZMY91
ZMY100
min. max.
V
Z
(V)
0.65 … 0.75
3.7 … 4.1
4.0 … 4.6
4.4 … 5.0
4.8 … 5.4
5.2 … 6.0
5.8 … 6.6
6.4 … 7.2
7.0 … 7.9
7.7 … 8.7
8.5 … 9.6
9.4 … 10.6
10.4 … 11.6
11.4 … 12.7
12.4 … 14.1
13.8 … 15.8
15.3 … 17.1
16.8 … 19.1
18.8 … 21.2
20.8 … 23.3
22.8 … 25.6
25.1 … 28.9
28 … 32
31 … 35
34 … 38
37 … 41
40 … 46
44 … 50
48 … 54
52 … 60
58 … 66
64 … 72
70 … 79
77 … 88
85 … 96
94 … 106
Dynamic
resistance
at I
ZT
f = 1 kHz
max
r
zj
(Ω)
6.5 (< 8)
4 (< 7)
4 (< 7)
4 (< 7)
2 (< 5)
1 (< 2)
1 (< 2)
1 (< 2)
1 (< 2)
1 (< 2)
2 (< 4)
2 (< 4)
3 (< 7)
3 (< 7)
4 (< 9)
4 (< 9)
5 (< 10)
5 (< 11)
6 (< 12)
7 (< 13)
8 (< 14)
9 (< 15)
10 (< 20)
11 (< 20)
25 (< 60)
30 (< 60)
35 (< 80)
40 (< 80)
45 (< 100)
50 (< 100)
60 (< 130)
65 (< 130)
70 (< 160)
80 (< 160)
120 (< 250)
130 (< 250)
Temp. coeff.
of Zener volt.
at
I
ZT
Test
current
I
ZT
(mA)
5
100
100
100
100
100
100
100
100
100
50
50
50
50
50
50
25
25
25
25
25
25
25
25
10
10
10
10
10
10
10
10
10
10
5
5
Reverse
voltage
at
I
R
= 0.5µA
V
R
(V)
–
–
–
–
> 0.7
> 1.5
> 2.0
> 3.0
> 5.0
> 6.0
> 7.0
> 7.5
> 8.5
> 9.0
> 10
> 11
> 12
> 14
> 15
> 17
> 18
> 20
> 22.5
> 25
> 27
> 29
> 32
> 35
> 38
> 42
> 47
> 51
> 56
> 61
> 68
> 75
Admissible
Zener current
(1)
at T
amb
= 25°C
I
Z
(mA)
406
203
182
165
150
135
128
110
100
89
82
74
66
60
55
49
44
40
36
34
29
27
25
22
20
18
17
15
14
13
11
10
9
8
7.5
7
α
VZ
(10
–4
/K)
–26 … –23
–7 … +2
–7 … +3
–7 … +4
–6 … +5
–3 … +5
–1 … +6
0 … +7
0 … +7
+3 … +8
+3 … +8
+5 … +9
+5 … +10
+5 … +10
+5 … +10
+5 … +10
+7 … +11
+7 … +11
+7 … +11
+7 … +11
+7 … +12
+7 … +12
+7 … +12
+7 … +12
+7 … +12
+8 … +12
+8 … +13
+8 … +13
+8 … +13
+8 … +13
+8 … +13
+8 … +13
+8 … +13
+8 … +13
+9 … +13
+9 … +13
NOTES:
(1) Valid provided that electrodes are kept at ambient temperature
(2) Tested with pulses t
p
= 5 ms
(3) The ZMY1 is a silicon diode operated in forward direction. Hence, the index of all characteristics and maximum ratings should be “F” instead of “Z”.
Connect the cathode terminal to the negative pole
For devices in glass case MELF with higher Zener voltage but same power dissipation see types ZMU100 … ZMU180
