B5000RW
Series
Compact, 1 x 2 Inch
50W, 2:1 Input Range
DC/DC Converters
Electrical Specifications
Specifications typical @ +25°C, nominal input voltage & rated output current, unless otherwise noted. Specifications subject to change without notice.
Input
Key Features:
•
50W Output Power
•
2:1 Input Voltage Range
•
1,500 VDC Isolation
•
Very High Efficiency
•
Compact 1 x 2 Inch Case
•
Twelve Standard Models
•
Remote ON/OFF Control
•
Industry Standard Pin-Out
Parameter
Input Start Voltage
Input Shutdown Voltage
Input Filter
Conditions
Min.
12 VDC Input
24 VDC Input
48 VDC Input
12 VDC Input
24 VDC Input
48 VDC Input
(Pi) Filter
Conditions
V
IN
= Min to Max
See Note 1
3.3 & 5.0 V
OUT
Models
12 & 15 V
OUT
Models
115
25% Load Step Change
Min.
Typ.
Max.
9.0
18.0
36.0
Units
VDC
8.3
16.5
33.0
VDC
Output
Parameter
Output Voltage Accuracy
Line Regulation
Load Regulation
Ripple & Noise, See Note 2
Output Power Protection
Transient Recovery Time, See Note 3
Transient Response Deviation
Temperature Coefficient
Output Short Circuit
Typ.
Max.
±1.0
±0.5
±0.5
Units
%
%
%
mV P - P
mV P - P
%
µSec
%
%/°C
100
150
130
250
±2.0
±0.02
Continuous (Autorecovery)
Conditions
60 Seconds
500 VDC
100 kHz, 1V
Min.
1,500
1,000
Typ.
Max.
Units
VDC
M
pF
kHz
General
Parameter
Isolation Voltage
Isolation Resistance
Isolation Capacitance
Switching Frequency
Remote On/Off
(See Note 4)
Parameter
Supply On
Supply Off
Standby Input Current
Control Common
2,200
320
Conditions
Units
VDC
VDC
2.5
mA
Referenced to Negative Input (pin 2)
Min.
-40
Typ.
+25
Max.
+58
+105
+125
95
Units
°C
°C
°C
%
Min.
3.5
0.0
Typ.
Max.
12.0
1.2
Environmental
Parameter
Operating Temperature Range
Operating Temperature Range
Storage Temperature Range
Cooling
Humidity
RFI
Conducted EMI, See Note 5
Physical
Case Size
Case Material
Weight
Conditions
Ambient
Case
-50
Free Air Convection
RH, Non-condensing
Six-Side Shielded Metal Case
EN55022 Class “A”
MicroPower Direct
292 Page Street
Suite D
Stoughton, MA 02072
USA
T:
(781) 344-8226
F:
(781) 344-8481
E:
sales@micropowerdirect.com
W:
www.micropowerdirect.com
2.0 x 1.0 x 0.40 Inches (50.8 x 25.4 x 10.2 mm)
Metal with Non-Conductive Base
1.06 Oz (30g)
Conditions
MIL HDBK 217F, 25°C, Gnd Benign
Conditions
12 VDC Input
24 VDC Input
48 VDC Input
1.5 mm From Case For 10 Sec
Min.
328
Min.
-0.7
-0.7
-0.7
Typ.
Max.
Units
kHours
Units
VDC
°C
Reliability Specifications
Parameter
MTBF
Absolute Maximum Ratings
Parameter
Input Voltage Surge (1 Sec)
Lead Temperature
Typ.
Max.
25.0
50.0
100.0
260.0
Caution: Exceeding Absolute Maximum Ratings may damage the module. These are not continuous operating ratings.
www.micropowerdirect.com
Model Selection Guide
Input
Model
Number
B5001RW
B5002RW
B5003RW
B5004RW
B5011RW
B5012RW
B5013RW
B5014RW
B5021RW
B5022RW
B5023RW
B5024RW
Voltage
(VDC)
Nominal
12
12
12
12
24
24
24
24
48
48
48
48
Range
9.0 - 18.0
9.0 - 18.0
9.0 - 18.0
9.0 - 18.0
18.0 - 36.0
18.0 - 36.0
18.0 - 36.0
18.0 - 36.0
36.0 - 75.0
36.0 - 75.0
36.0 - 75.0
36.0 - 75.0
Current
(mA)
Full-Load No-Load
3,090
4,630
4,579
4,579
1,545
2,264
2,264
2,264
772
1,132
1,132
1,132
85
110
160
160
50
70
85
85
35
45
50
50
Reflected
Ripple
Current Voltage
(mA, Typ)
(VDC)
www.micropowerdirect.com
Output
Current
(mA, Max)
Current
(mA, Min)
Over
Voltage Efficiency Capacitive Fuse Rating
Load
Slow-Blow
Protection
(%, Typ)
(µF Max)
(mA)
(VDC)
50
50
50
50
50
50
30
30
20
20
20
20
3.3
5.0
12.0
15.0
3.3
5.0
12.0
15.0
3.3
5.0
12.0
15.0
10,000
10,000
4,167
3,333
10,000
10,000
4,167
3,333
10,000
10,000
4,167
3,333
0.0
0.0
0.0
0.0
0.0
0.0
0.0
0.0
0.0
0.0
0.0
0.0
3.9
6.2
15.0
18.0
3.9
6.2
15.0
18.0
3.9
6.2
15.0
18.0
89
90
91
91
89
92
92
92
89
92
92
92
25,757
17,000
2,950
1,887
25,757
17,000
2,950
1,887
25,757
17,000
2,950
1,887
8,000
8,000
8,000
8,000
4,000
4,000
4,000
4,000
2,000
2,000
2,000
2,000
For heatsink option, add suffix “H” to model number (i.e.
B5003RW-H)
Notes:
1. Load regulation is specified for a load change of minimum load to full load.
2. When measuring output ripple, it is recommended that external 1.0 µF & 10 µF capacitors be placed in parallel
from the +Vout pin to the -Vout pin.
3. Transient recovery is measured to within a 1% error band for a load step change of 75% to 100%.
4. The maximum control current at the on/off pin (pin 6) during a logic high is 5
µA.
The maximum control current to
the on/off pin at logic low is -100
µA.
If the on/off pin is left open, the unit operates. If grounded, the unit will shut off.
5. The
B5000RW
series can meet EN55022 Class A with the addition of a capacitor connected in parralel with
the input pins. It is recommended that a low ESR (ESR <1.0 at 100 kHz) capacitor be mounted close to the
converter. For 12V input units, a 22.0
µF/25V
is recommended; for 24V inputs a 3.3
µF/50V;
and for 48V units a
2.2
µF/100V.
6. The converter should be connected to a low ac-impedance source. An input source with a highly inductive imped-
ance may affect the stability of the converter. In applications where the converter output loading is high and input
power is supplied over long lines, it may be necessary to use a capacitor on the input to insure start-up.
7. Operation at no-load will not damage these units. However, they may not meet all specifications.
8. An external resistor may be used to adjust the converter output by
±10%.
To adjust the output UP, connect a 5%,
3W resistor between the minus output pin and the Vout trim pin. To adjust the output DOWN, connect a 5%, 3W
resistor between the plus output pin and the V
OUT
trim pin. For continuous UP/Down trimming capability, connect
a 10 kW potentiometer between the plus and minus outputs with the wiper arm connected to the V
OUT
trim pin.
The trim pin may be left floating if it is not used. Contact the factroy for more information.
9. It is recommended that a fuse be used on the input of a power supply for protection. See the table above for the
correct rating.
Derating Curve
Heatsink Dimensions
(Optional)
Mechanical Dimensions
Heatsink Notes:
•
The heatsink is black anodized aluminum.
•
Heatsink weight is 0.07 Oz (2.0g)
Pin Connections
Pin Function
1
+Vin
2
-Vin
3 ON/OFF
Pin Function
4
+Vout
5
-Vout
6
Trim
Mechanical Notes:
•
All dimensions are typical in inches (mm)
•
Tolerance x.xx = ±0.01 (±0.25)
MicroPower Direct
We Power Your Success - For Less!
292 Page Street Ste D Stoughton, MA 02072
•
TEL: (781) 344-8226
•
FAX: (781) 344-8481
•
E-Mail: sales@micropowerdirect.com
