TBP2005G thru TBP210G
GLASS PASSIVATED
BRIDGE RECTIFIERS
FEATURES
●
Surge overload rating -60amperes peak
●
Ideal for printed circuit board
●
Plastic material has UL
REVERSE VOLTAGE
- 50
to
1000Volts
FORWARD CURRENT
- 2.0
Amperes
TBP
.125X45°
(3.2)
.600(15.24)
.560(14.22)
.500(12.70)
.460(11.68)
flammability classification 94V-0
●
Mounting position :Any
.460(11.68)
.420(10.67)
.640
MIN.
(16.25)
.50
MIN.
(12.7)
.034(0.86)
.028(0.76)
.154(3.9)
.146(3.7)
.060
(1.52)
.160(4.1)
.140(3.6)
.053(1.35)
.045(1.15)
Dimensions in inches and (milimeters)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Rating at 25℃ ambient temperature unless otherwise specified.
Resistive or inductive load,60HZ.
For capacitive load, derate current by 20%
CHARACTERISTICS
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Bridge Input Voltage
Maximum DC Blocking Voltage
Maximum Average Forward
Rectified Output Current
Peak Forward Surage Current ,
8.3ms Single Half Sine-Wave
Super Imposed on Rated Load
Maximum Forward Voltage Drop
Per Bridge Element at 2.0A Peak
Maximum Reverse Current at Rated
DC Blocking Voltage Per Element
Maximum Reverse Current at Rated
DC Blocking Voltage Per Element @T
A
=100℃
Operating Temperature Range
Storage Temperature Range
@T
A
=50
℃
SYMBOL
V
RRM
V
RMS
V
DC
I
(AV)
TBP
2005G
50
35
50
TBP
201G
100
70
100
TBP
202G
200
140
200
TBP
204G
400
280
400
2.0
TBP
206G
600
420
600
TBP
208G
800
560
800
TBP
210G
1000
700
1000
UNIT
V
V
V
A
I
FSM
60
A
V
F
I
R
I
R
T
J
T
STG
1.1
10.0
1.0
-55 to +150
-55 to +150
V
uA
mA
℃
℃
~ 333 ~
RATING AND CHARACTERISTIC CURVES
TBP2005G thru TBP210G
FIG.2-TYPICAL FORWARD
CHARACTERISTICS
FIG.1-DERATING CURVE
OUTPUT RECTIFIED CURRENT
AVERAGE FORWARD OUTPUT CURRENT
AMPERES
2.0
INSTANTANEOUS FORWARD CURRENT,
AMPERES
20.0
10.0
1.0
0.1
T
J
=25
℃
0
50
100
150
AMBIENT TEMPERATURE
℃
0.01
0
0.2
0.4
0.6
0.8
1.0
1.2
1.4
INSTANTANEOUS FORWARD VOLTAGE. VOLTS
FIG.3-TYPIACL REVERSE CHARACTERISTICS
PEAK FORWARD SURGE CURRENT
AMPERES
10
60
FIG.4-MAXIMUM FORWARD SURGE CURRENT
INSTANTANEOUS REVERSE CURRENT,
MICROAMPERES
40
1.0
T
J
=25℃
0.1
T
J
=25℃
1
10
NUMBER OF CYCLES AT 60H
Z
100
0.01
0
100
120
140
0
0
0
PERCENT OF RATED PEAK REVERSE VOLTAGE
20
40
60
80
~ 334 ~
