TOROIDAL INDUCTOR
1. PART NO. EXPRESSION :
TBV SERIES
TBV-100M-2A-3026
(a)
(b)
(c)
(d) (e)
(a) Series code
(b) Inductance code : 100 = 10.0uH
(c) 2A : Rated Current
(d) Core OD : 30 = 0.3"
(e) Material code
2. CONFIGURATION & DIMENSIONS :
B
A
D
C
E
Unit:m/m
A
B
C
E
ØW
0.40 Ref.
8.50 Max. 6.00 Max. 10.00±3.0 1.00 Max.
3. SCHEMATIC :
4. MATERIALS :
a
b
d
c
(a) Core : Iron Powder Core
(b) Wire : Enamelled Copper Wire
(c) Base : FR4 (or equivalent)
(d) Adhesive : Epoxy
NOTE : Specifications subject to change without notice. Please check our website for latest information.
F
19.06.2008
SUPERWORLD ELECTRONICS (S) PTE LTD
PG. 1
TOROIDAL INDUCTOR
5. GENERAL SPECIFICATION :
a) Temp. rise : 40°C Max. at Irms
b) Storage temp. : -40°C to +125°C
c) Operating temp. : -25°C to +105°C
TBV SERIES
6. ELECTRICAL CHARACTERISTICS :
Inductance @ 1KHz
Part No.
@ Idc=0A
( µH )
10
12
32
8.2
22
24
68
15
43
68
140
20
30
60
68
100
220
22
29
35
58
90
110
130
470
25
32
43
65
110
130
150
230
500
@ Idc=Max
( µH )
7.7
10.7
25
7.2
17
22
53
12.6
37
42
104
15
25
35
60
63
162
15
20
28
45
52.5
79
116
310
18
24
30
55
56
77
137
148
355
IDC
(A)
Max.
2
1
1
2
2
1
1
2
1
2
1
3
2
3
1
2
1
5
4
3
2
3
2
1
1
5
4
3
2
4
3
1
2
1
DCR
( )
Max.
0.017
0.040
0.065
0.017
0.030
0.055
0.095
0.023
0.074
0.056
0.140
0.021
0.035
0.038
0.101
0.081
0.190
0.014
0.020
0.026
0.061
0.044
0.069
0.146
0.286
0.016
0.021
0.030
0.055
0.042
0.055
0.159
0.108
0.300
TBV-100M-2A-3026
TBV-120M-1A-3026
TBV-320M-1A-3026
TBV-8R2M-2A-3726
TBV-220M-2A-3726
TBV-240M-1A-3726
TBV-680M-1A-3726
TBV-150M-2A-4426
TBV-430M-1A-4426
TBV-680M-2A-4426
TBV-141M-1A-4426
TBV-200M-3A-5026
TBV-300M-2A-5026
TBV-600M-3A-5026
TBV-680M-1A-5026
TBV-101M-2A-5026
TBV-221M-1A-5026
TBV-220M-5A-6026
TBV-290M-4A-6026
TBV-350M-3A-6026
TBV-580M-2A-6026
TBV-900M-3A-6026
TBV-111M-2A-6026
TBV-131M-1.0A-6026
TBV-471M-1.0A-6026
TBV-250M-5.0A-6826
TBV-320M-4.0A-6826
TBV-430M-3.0A-6826
TBV-650M-4.0A-6826
TBV-111M-4.0A-6826
TBV-131M-3.0A-6826
TBV-151M-1.0A-6826
TBV-231M-2.0A-6826
TBV-501M-1.0A-6826
NOTE : Specifications subject to change without notice. Please check our website for latest information.
19.06.2008
SUPERWORLD ELECTRONICS (S) PTE LTD
PG. 2
TOROIDAL INDUCTOR
6. ELECTRICAL CHARACTERISTICS :
Inductance @ 1KHz
Part No.
@ Idc=0A
( µH )
50
60
75
82
100
110
150
220
270
320
430
960
90
140
200
320
450
470
470
1800
82
100
130
220
300
390
470
500
780
1300
@ Idc=Max.
( µH )
33
42
54
60
53
90
68
105
140
193
246
625
54
98
154
120
280
398
225
1130
52
69
96
170
120
165
400
242
428
933
IDC
(A)
Max.
5
4
3
3
5
2
5
4
3
2
2
1
5
3
2
5
2
1
3
1
5
4
3
2
5
4
1
3
2
1
TBV SERIES
DCR
( )
Max.
0.022
0.030
0.039
0.042
0.033
0.074
0.042
0.059
0.081
0.131
0.150
0.438
0.034
0.064
0.114
0.068
0.174
0.354
0.118
0.680
0.033
0.042
0.061
0.121
0.064
0.088
0.342
0.124
0.225
0.585
TBV-500M-5.0A-8026
TBV-600M-4.0A-8026
TBV-750M-3.0A-8026
TBV-820M-3.0A-8026
TBV-101M-5.0A-8026
TBV-111M-2.0A-8026
TBV-151M-5.0A-8026
TBV-221M-4.0A-8026
TBV-271M-3.0A-8026
TBV-321M-2.0A-8026
TBV-431M-2.0A-8026
TBV-961M-1.0A-8026
TBV-900M-5.0A-9026
TBV-141M-3.0A-9026
TBV-201M-2.0A-9026
TBV-321M-5.0A-9026
TBV-451M-2.0A-9026
TBV-471M-1.0A-9026
TBV-471M-3.0A-9026
TBV-182M-1.0A-9026
TBV-820M-5.0A-9426
TBV-101M-4.0A-9426
TBV-131M-3.0A-9426
TBV-221M-2.0A-9426
TBV-301M-5.0A-9426
TBV-391M-4.0A-9426
TBV-471M-1.0A-9426
TBV-501M-3.0A-9426
TBV-781M-2.0A-9426
TBV-132M-1.0A-9426
NOTE : Specifications subject to change without notice. Please check our website for latest information.
19.06.2008
SUPERWORLD ELECTRONICS (S) PTE LTD
PG. 3
TOROIDAL INDUCTOR
6. ELECTRICAL CHARACTERISTICS :
Inductance @ 1KHz
Part No.
@ Idc=0A
( µH )
30
35
56
68
82
100
150
200
300
850
75
130
200
250
470
680
@ Idc=Max
( µH )
21
25
41.5
46
53
75
110
157
250
567
43
79
134
105
190
295
IDC
(A)
Max.
10
10
7
7
7
5
4
3
2
2
43
79
134
105
190
295
TBV SERIES
DCR
( )
Max.
0.009
0.010
0.020
0.021
0.023
0.036
0.053
0.078
0.142
0.211
0.014
0.031
0.056
0.027
0.064
0.105
TBV-300M-10A-10626
TBV-350M-10A-10626
TBV-560M-7.0A-10626
TBV-680M-7.0A-10626
TBV-820M-7.0A-10626
TBV-101M-5.0M-10626
TBV-151M-4.0A-10626
TBV-201M-3.0A-10626
TBV-301M-2.0A-10626
TBV-851M-2.0A-10626
TBV-750M-10A-13026
TBV-131M-7.0A-13026
TBV-201M-5.0A-13026
TBV-251M-10A-13026
TBV-471M-7.0A-13026
TBV-681M-5.0A-13026
NOTE : Specifications subject to change without notice. Please check our website for latest information.
19.06.2008
SUPERWORLD ELECTRONICS (S) PTE LTD
PG. 4
