MS3451W16-11SY datasheet, PDF - EEWORLD Datasheet

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > The connector> The connector> MS3451W16-11SY

Preview

MS3451W16-11SY: DescriptionMIL Series Connector, 2 Contact(s), Aluminum Alloy, Female, Crimp Terminal, Receptacle,; CategoryThe connector The connector; File Size136KB，1 Pages; ManufacturerAmphenol; Websitehttp://www.amphenol.com/

Download Datasheet Parametric View All

MS3451W16-11SY Overview

MIL Series Connector, 2 Contact(s), Aluminum Alloy, Female, Crimp Terminal, Receptacle,

MS3451W16-11SY Parametric

Parameter Name	Attribute value
Maker	Amphenol
Reach Compliance Code	unknown
Factory Lead Time	10 weeks
Other features	STANDARD: MIL-C-5015, COMPATIBLE CONTACT: M39029/30-219
Back shell type	SOLID
Body/casing type	RECEPTACLE
Connector type	MIL SERIES CONNECTOR
Contact point gender	FEMALE
Coupling type	THREADED
DIN compliance	NO
empty shell	NO
Environmental characteristics	FLUID RESISTANT
Filter function	NO
IEC compliance	NO
MIL compliance	YES
Plug information	MULTIPLE MATING PARTS AVAILABLE
Mixed contacts	NO
Installation type	CABLE
Options	GENERAL PURPOSE
Shell surface	CADMIUM PLATED
Shell material	ALUMINUM ALLOY
Housing size	16
Termination type	CRIMP
Total number of contacts	2

Preview

Download Datasheet

View All

MS/Standard

MS3451

cable connecting receptacle

Receptacle Shell, Cable Connecting,

Threaded Coupling

Military No. MS3451

Amphenol/Matrix No. 9441

To complete order number see how to order, page 29.

D Max.

Size

16 & 12

8, 4, 0

Contacts Contacts

Shell

Size

A

B

Dia.

±.031

C

E

Dia.

Max.

F

±.015

G

MIn.

H

Thread

Class 2A

J

Thread

Class 2A

8S

10S

10SL

12

12S

14

14S

16

16S

18

20

22

24

28

32

36

40

.504/.496

.629/.621

.754/.746

.879/.871

1.005/.996

1.131/1.121

1.256/1.246

1.381/1.371

1.506/1.496

1.756/1.746

2.007/1.996

2.257/2.246

2.511/2.456

.729

.854

.974

1.099

1.224

1.349

1.474

1.599

1.715

1.974

2.224

2.474

2.724

.577/.562

.765/.750

.577/.562

.765/.750

.577/.562

.765/.750

.577/.562

.765/.750

.827/.812

.890/.870

2.031

2.125

2.031

2.125

2.031

2.125

2.031

2.125

–

2.500

–

2.500

.305

.405

.549

.665

.790

.869

.994

1.119

1.244

1.465

1.715

1.930

2.145

.083

.125

.290

.467

.5000-20 UNEF

.6250-24 UNEF

.7500-20 UNEF

.8750-20 UNEF

1.0000-20 UNEF

1.0625-18 UNEF

1.1875-18 UNEF

1.3125-18 UNEF

1.4375-18 UNEF

1.7500-18 UNS

2.0000-18 UNS

2.2500-16 UN

2.5000-16 UN

.5000-28 UNEF

.6250-24 UNEF

.7500-20 UNEF

.8750-20 UNEF

1.0000-20 UNEF

1.1250-18 UNEF

1.2500-18 UNEF

1.3750-18 UNEF

1.5000-18 UNEF

1.7500-18 UNS

2.0000-18 UNS

2.2500-16 UN

2.5000-16 UN

* Consult Amphenol, Sidney, NY for availability of shell sizes 44 and 48.
