Type THF
Solid Tantalum Capacitors
Hermetically Sealed Axial Lead Solid Tantalum Capacitors
The Type THF is ideal for use in switching regulators
and high frequency power supplies because of its high
ripple current and low ESR capabilities. It is an axial
lead solid tantalum capacitor constructed with a rugged
hermetically sealed metal case, insulated with an outer
polyester wrap. The THF assures a small case size for
high capacitance, and is extremely stable over the rated
temperature range.
Highlights
♦
♦
♦
♦
♦
♦
♦
High Ripple Current
Low ESR
Lower Impedance at High Frequency
Extremely Stable Capacitance
Long Life
Moisture & Solvent Resistant
Small Size
Specifications
Capacitance Range:
Voltage Range:
Capacitance Tolerance:
Operating Temperature:
DC Leakage:
5.6 µF to 330 µF
6 WVdc to 50 WVdc @ 85 ºC
±10% (K), ±20% (M)
–55 ºC to +125 ºC ( With proper derating)
At +25 ºC - (See Ratings)
At +85 ºC - 10 x Ratings limit
At +125 ºC - 12.5 x Ratings limit
Outline Drawing
Uninsulated
1.50 ±.250
(38.1 ±6.35)
Insulated
D
±.010
(±.25)
L
±.031
(±.79)
C
Inches (mm)
d
±.001
(±.03)
Maximum
Quantity
Per
Reel
500
400
C
+
1.50 ±.250
(38.1 ±6.35)
D
Case ±.005
Code (±.13)
L
±.031
(±.79)
D
L
d
F .279(7.09) .650(16.51) .289(7.34) .686(17.42) .822(20.88) .025(.64)
G .341(8.66) .750(19.05) .351(8.92) .786(19.96) .922(23.42) .025(.64)
Part Numbering System
THF
157
M
006
P
1
Mylar
Sleeve
1
F
Case
Code
F
G
Type
THF
Capacitance
565
= 5.6 µF
186
= 18.6 µF
157
= 150 µF
Tolerance
K
= ±10%
M
= ±20%
Voltage
006
= 6 Vdc
020
= 20 Vdc
050
= 50 Vdc
Polar
P =
Polar
CDE Cornell Dubilier • 1605 E. Rodney French Blvd. • New Bedford, MA 02744 • Phone: (508)996-8561 • Fax: (508)996-3830 • www.cde.com
Type THF
Solid Tantalum Capacitors
Ratings
Max
Catalog
Cap
(µF)
Part Number
Case
Code
DCL
@ +25 ºC
(µA)
6 WVdc @ 85 ºC
4 WVdc @ 125 ºC
150
180
270
330
THF157K006P1F
THF187K006P1F
THF277K006P1G
THF337K006P1G
F
F
G
G
4.5
5.5
6.5
7.5
10 WVdc @ 85 ºC
7 WVdc @ 125 ºC
82
100
120
180
220
THF826K010P1F
THF107K010P1F
THF127K010P1F
THF187K010P1G
THF227K010P1G
F
F
F
G
G
4
5
6
9
10
15 WVdc @ 85 ºC
10 WVdc @ 125 ºC
56
68
120
150
THF566K015P1F
THF686K015P1F
THF127K015P1G
THF157K015P1G
F
F
G
G
4
5
9
10
20 WVdc @ 85 ºC
13 WVdc @ 125 ºC
27
33
39
47
56
68
82
100
THF276K020P1F
THF336K020P1F
THF396K020P1F
THF476K020P1F
THF566K020P1G
THF686K020P1G
THF826K020P1G
THF107K020P1G
F
F
F
F
G
G
G
G
2.5
3.5
4.0
4.5
5.5
7.0
8.0
10.0
35 WVdc @ 85 ºC
23 WVdc @ 125 ºC
10
22
27
33
39
47
THF106K035P1F
THF226K035P1F
THF276K035P1G
THF336K035P1G
THF396K035P1G
THF476K035P1G
F
F
G
G
G
G
4.0
4.0
4.5
5.5
7.0
8.0
50 WVdc @ 85 ºC
33 WVdc @ 125 ºC
5.6
6.8
8.2
10.0
12.0
15.0
18.0
22.0
THF565K050P1F
THF685K050P1F
THF825K050P1F
THF106K050P1F
THF126K050P1F
THF156K050P1F
THF186K050P1F
THF226K050P1G
F
F
F
F
F
F
F
G
2.2
2.2
2.5
2.5
3.0
4.0
4.5
5.5
3
3
3
3
3
3
4
4
0.300
0.275
0.250
0.230
0.210
0.190
0.175
0.160
1.5
1.6
1.6
1.7
1.8
1.9
2.0
2.3
4
4
4
5
5
5
0.161
0.160
0.145
0.130
0.120
0.110
1.5
2.1
2.4
2.5
2.6
2.7
5
5
5
6
6
6
6
8
0.145
0.130
0.120
0.110
0.100
0.095
0.085
0.075
2.2
2.3
2.4
2.5
2.9
3.0
3.1
3.3
6
6
8
8
0.100
0.095
0.070
0.065
2.6
2.7
3.5
3.6
8
8
8
8
10
0.085
0.075
0.070
0.060
0.055
2.9
3.0
3.2
3.7
3.9
10
10
10
12
0.065
0.060
0.050
0.045
3.3
3.4
4.1
4.3
Max
DF %
@ +25 ºC
1 kz
Max
ESR (ohms)
@ +25 ºC
100 kHz
Max Ripple
RMS Amps
@ 40 kHz
+25ºC
CDE Cornell Dubilier • 1605 E. Rodney French Blvd. • New Bedford, MA 02744 • Phone: (508)996-8561 • Fax: (508)996-3830 • www.cde.com
