BZW06-376BTR: DescriptionTrans Voltage Suppressor Diode, 600W, 376V V(RWM), Bidirectional, 1 Element, Silicon, DO-204AC, DO-15, 2 PIN; CategoryDiscrete semiconductor diode; File Size403KB，6 Pages; ManufacturerFagor Electrónica; Environmental Compliance

Download Datasheet Parametric Compare View All

BZW06-376BTR Overview

Trans Voltage Suppressor Diode, 600W, 376V V(RWM), Bidirectional, 1 Element, Silicon, DO-204AC, DO-15, 2 PIN

BZW06-376BTR Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Fagor Electrónica
package instruction	DO-15, 2 PIN
Reach Compliance Code	compliant
ECCN code	EAR99
Other features	EXCELLENT CLAMPING CAPABILITY, HIGH RELIABILITY
Maximum breakdown voltage	480 V
Minimum breakdown voltage	418 V
Shell connection	ISOLATED
Configuration	SINGLE
Diode component materials	SILICON
Diode type	TRANS VOLTAGE SUPPRESSOR DIODE
JEDEC-95 code	DO-204AC
JESD-30 code	O-PALF-W2
JESD-609 code	e3
Maximum non-repetitive peak reverse power dissipation	600 W
Number of components	1
Number of terminals	2
Maximum operating temperature	175 °C
Minimum operating temperature	-65 °C
Package body material	PLASTIC/EPOXY
Package shape	ROUND
Package form	LONG FORM
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
polarity	BIDIRECTIONAL
Maximum power dissipation	5 W
Guideline	AEC-Q101
Maximum repetitive peak reverse voltage	376 V
surface mount	NO
technology	AVALANCHE
Terminal surface	Matte Tin (Sn)
Terminal form	WIRE
Terminal location	AXIAL
Maximum time at peak reflow temperature	NOT SPECIFIED

Preview

Download Datasheet

View All

BZW06-5V8 ............ BZW06-376

BZW06-5V8B ....... BZW06-376B

600 W Unidirectional and Bidirectional Transient Voltage Suppressor Diodes

Peak Pulse

Power Rating

At 1 ms. Exp.

600 W

Reverse

stand-off

Voltage

5.8 ÷ 376 V

DO-204AC (DO-15)

FEATURES

Glass passivated chip junction

Hyperectifier structure for high reliability

600 W peak pulse power capability with a 10/1000 µs

waveform, repetitive rate (duty cycle): 0.01 %

Solder dip 260ºC, 10s

AEC-Q101 qualified

Component in accordance to RoHS 2011/65/EU

and WEEE 2002/96/EC

Excellent clamping capability

Very fast response time

Low incremental surge resistance

Available in uni-directional and bi-directional

MECHANICAL DATA

Case

DO-204AC (DO-15)

Epoxy meets UL 94V-0 flammability rating.

Polatity

For uni-directional types the color band

denotes cathode end, no marking on bi-directional types

Terminals

Matte tin plated leads, solderable per

MIL-STD-750 Method 2026, J-STD-002 and JESD22-B102.

Consumer grade, meets JESD 201 class 1A whisker test.

TYPICAL APPLICATIONS

Used in sensitive electronics protection against voltage transients

induced by inductive load switching and lighting on ICs, MOSFET,

signal lines of sensor units for consumer, computer, industrial,

automotive and telecommunication.

Maximun Ratings and Electrical Characteristics at 25 °C

FSM

stg

Peak pulse power with 10/1000 µs

exponential pulse

Non repetitive surge peak forward

current (t = 10 ms)

(Note 1)

600 W

100 A

65 to + 175 °C

Operating temperature range

Storage temperature range

M(AV)

Steady State Power dissipation at (l = 10mm)

Electrical Characteristics at Tamb = 25 °C

thj-l

Max. forward voltage

drop at I

= 50 A

(Note 1)

220 V

> 220 V

3.5 V

5.0 V

30 °C/W

Max. thermal resistance (l = 10 mm.)

Note 1: Valid only for Unidirectional.

www.fagorelectronica.com

Document Name: bzw06

Revision: 1

Version: Jul-16

Page Number: 1/6
