FREQUENCY CONTROL PRODUCTS
SURFACE MOUNT
LVDS CLOCK OSCILLATOR
DFN S11-LLPI (3.3 V) & DFN S11-LDPI (2.5 V)
FEATURES
5.0±0.2
L±0.2
5.08
10 TO 250 MHz
Fundamental and 3
rd
overtone mode crystals
Low jitter
APPLICATIONS
2.4
L
H
7.0 mm
1.7 mm
1.4
H±0.2
Datacomms
Function
E/D
NC
GND
Output 1
Output 2
Vcc
5.08
DFN S11
1
2
3
4
5
6
6
1
5
2
4
3
2.4
PC board footprint
1.4
TYPE
Frequency Range
ELECTRICAL SPECIFICATIONS
supply voltage
supply current (no load)
output load
duty cycle @ 1.25 V
rise/fall times ( 20 to 80% )
high/low levels
differential output
differential output error
offset voltage
offset voltage error
output leakage current
jitter RMS (12 kHz to 20 MHz)
enable / disable on pin 1
complementary output on pin 5
start up
DFN S11-LLPI
10 to 250 MHz
3.3 V ± 5 %
≤
75 mA
100
Ω
between outputs
45/55…55/45 %
≤
0.6 ns
≤
1.6 V/
≥
0.9 V
≤
454 mV
≤
50 mV
≤
1.375 V
≤
50 mV
≤
10
μA
≤
1 ps
high or open = enable, low = disable
180° phase shifted
≤
10 ms @ 3.15 V
2.0
DFN S11-LDPI
2.5 V ± 5 %
≤
70 mA
100
Ω
between outputs
45/55…55/45 %
≤
0.6 ns
≤
1.6 V/
≥
0.9 V
≤
454 mV
≤
50 mV
≤
1.375 V
≤
50 mV
≤
10
μA
≤
1 ps
high or open = enable, low = disable
180° phase shifted
≤
10 ms @ 2.375 V
FREQUENCY STABILITY
types
all types
remarks
temperature range
-10 to 70°C
-40 to 85°C
stability [ ppm ] and temperature code
stability
code
stability
code
stability
code
XI25
XI50
XI100
≤
± 25
≤
± 50
≤
± 100
XE25
XE50
XE100
≤
± 25
≤
± 50
≤
± 100
stability includes calibration at 25°C, temperature, ageing, Vcc and load changes 1
st
yr.
OPTIONS
stability over long life time
A = 5 years
B = 10 years
C = 15 years
ORDERING CODE
Example
type + option code + frequency + stability/temperature code
DFN S11-LDPI 155.52 MHz XE50B
REMARK
TYPE
DFN S11-LL/LD
Please consult factory for life time/stabilities possible combinations
REVISION
00
CHECKED
NE
DATE
14.12.2005
PAGE
XX
