SMA83 Overview

Cascadable Amplifier 10 to 500 MHz

A83 / SMA83
Cascadable Amplifier
10 to 500 MHz
Features
HIGH GAIN-TWO STAGES: 30 dB (TYP.)
LOW POWER DRAIN 65 mW @ 5 VOLTS (TYP.)
VOLTAGE CONTROLLED GAIN 27 dB TO 34 dB
@ Vcc = 3 TO 12 VOLTS
LOW VSWR 1.3:1 (TYP.)
Rev. V2
Product Image
Description
The A83 RF amplifier is a discrete hybrid design, which uses
thin film manufacturing processes for consistent performance
and high reliability.
This 2 stage bipolar transistor feedback amplifier design
displays impressive performance over a broadband
frequency range. An active DC biasing network insures
temperature-stable performance.
Both TO-8 and Surface Mount packages are hermetically
sealed, and MIL-STD-883 environmental screening is available.
Ordering Information
Part Number
MAAM-008200-000A83
MAAM-008200-0SMA83
MAAM-008200-00CA83
Package
TO-8
Surface Mount
SMA Connectorized **
** The connectorized version is not RoHs compliant.
Electrical Specifications: Z
0
= 50Ω, V
CC
= +15 V
DC
Typical
Parameter
Frequency
Small Signal Gain (min)
Gain Flatness (max)
Reverse Isolation
Noise Figure (max)
Power Output
@ 1 dB comp. (min)
IP3
IP2
Second Order Harmonic IP
VSWR Input / Output (max)
DC Current @ 15 Volts (max)
mA
Absolute Maximum Ratings
Parameter
Storage Temperature
Case Temperature
DC Voltage
Continuous Input Power
Short Term Input power
(1 minute max.)
Peak Power (3 µsec max.)
“S” Series Burn-In
Temperature (case)
Guaranteed
0º to 50ºC
10-500
29.0
±0.5
Units
25ºC
MHz
dB
dB
dB
dB
dBm
dBm
dBm
dBm
10-600
30.0
±0.3
40
3.0
-1.0
+10
+14
+20
1.3:1 / 1.3:1
13
1.8:1 / 1.8:1
15
2.0:1 / 2.0:1
16
3.5
-2.0
4.0
-4.0
Absolute
Maximum
-62ºC to +125ºC
+125ºC
+13 V
+6 dBm
50 mW
0.5 W
+125ºC
-54º to +85ºC*
10-500
28.0
±0.8
Thermal Data: V
CC
= +15 V
DC
Parameter
Thermal Resistance
θ
jc
Transistor Power Dissipation P
d
Junction Temperature Rise
Above Case T
jc
Rating
45ºC/W
0.193 W
9ºC
* Over temperature performance limits for part number CA83, guaranteed from 0
o
C to +50
o
C only.
1
ADVANCED:
Data Sheets contain information regarding a product M/A-COM Technology Solutions
North America
Tel: 800.366.2266 •
Europe
Tel: +353.21.244.6400
is considering for development. Performance is based on target specifications, simulated results,
India
Tel: +91.80.4155721
China
Tel: +86.21.2407.1588
and/or prototype measurements. Commitment to develop is not guaranteed.
Visit www.macomtech.com for additional data sheets and product information.
PRELIMINARY:
Data Sheets contain information regarding a product M/A-COM Technology
Solutions has under development. Performance is based on engineering tests. Specifications are
typical. Mechanical outline has been fixed. Engineering samples and/or test data may be available.
M/A-COM Technology Solutions Inc. and its affiliates reserve the right to make
Commitment to produce in volume is not guaranteed.
changes to the product(s) or information contained herein without notice.

SMA83 Related Products

SMA83 A83 MAAM-008200-000A83 MAAM-008200-0SMA83 MAAM-008200-00CA83
Description Cascadable Amplifier 10 to 500 MHz Cascadable Amplifier 10 to 500 MHz Cascadable Amplifier 10 to 500 MHz Cascadable Amplifier 10 to 500 MHz Cascadable Amplifier 10 to 500 MHz
Is it lead-free? - - Lead free Lead free Lead free
Is it Rohs certified? - - conform to conform to conform to
Maker - - MACOM MACOM MACOM
Reach Compliance Code - - compli compli compli
Other features - - HIGH RELIABILITY HIGH RELIABILITY SMA, HIGH RELIABILITY
Characteristic impedance - - 50 Ω 50 Ω 50 Ω
structure - - COMPONENT MODULE COAXIAL
Gain - - 28 dB 28 dB 29 dB
Maximum input power (CW) - - 6 dBm 6 dBm 6 dBm
JESD-609 code - - e3 e3 e3
Maximum operating frequency - - 500 MHz 500 MHz 500 MHz
Minimum operating frequency - - 10 MHz 10 MHz 10 MHz
Maximum operating temperature - - 85 °C 85 °C 50 °C
RF/Microwave Device Types - - WIDE BAND LOW POWER WIDE BAND LOW POWER WIDE BAND LOW POWER
Terminal surface - - Matte Tin (Sn) Matte Tin (Sn) Matte Tin (Sn)
Maximum voltage standing wave ratio - - 2 2 1.8
