DESCRIPTION
RELEASED TO PRODUCTION
2
REVISIONS
DATE
1
APPROVED
R. CARRICK
D. PARHAM
R. CARRICK
D. PARHAM.
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE
PROPERTY OF L-COM, INC. ANY REPRODUCTION IN PART OR WHOLE
WITHOUT THE WRITTEN PERMISSION OF L-COM, INC. IS PROHIBITED.
9/17/01
10/29/01
1/18/02
7/12/05.
ADDED JKT COLOR & CORRECTED MODEL TABLE (ECN 1019)
CHANGE WIRE COLOR TO GRAY. FLIP FLOP V & H ECN # 1061
ECN#2135: ADDED CONNECTOR IMPEDANCE
D
LENGTH
2X 6.0
RED
JACKET AND STRAIN RELIEF
BLACK PVC
GREEN
GREEN
RED
D
C
BLUE
BLUE
C
BLACK
BLACK
GRAY
10X MOLDED PVC
STRAIN RELIEFS
COLOR BLACK
D
10X
75
BNC MALE
U.L. STYLE 2919 FIVE MINIATURE 75 OHM COAXIAL LINE
COMPOSED OF COPPER SPIRAL SHIELD PLUS
ALUMINUM MYLAR SHIELD.
GRAY
B
B
WIRING DIAGRAM
BNC PLUGS
BNC PLUGS
RED
GREEN
BLUE
MODEL
NUMBER
CTL5B-5B
CTL5B-7.5B
CTL5B-10B
CTL5B-15B
CTL5B-25B
CTL5B-50B
(FEET)
5.0
7.5
10.0
15.0
25.0
50.0
LENGTH
(METERS)
1.5
2.3
3.0
4.6
7.6
15.2
APPROVALS
DRAWN BY
RON CARRICK
CHECKED BY
ENG
9/17/2001
DATE
PRODUCT DESCRIPTION
9/17/2001
45 BEECHWOOD DRIVE
NORTH ANDOVER, MA
01845
A
BLACK
GRAY
A
VGA MONITOR CABLE ASSEMBLY
DRAWING TITLE
UNLESS OTHERWISE SPECIFIED, APPROVED BY
DIMENSIONS ARE IN INCHES
TOLERANCES ARE:
9/17/2001
C. MCCORMICK
.X .1
.XX .05
CONFIGURATION DETAILS OF
.XXX .005
UNDIMENSIONED FEATURES
CABLE LENGTH TOLERANCE
MAY VARY
<300" ±5% >300" ±2%
OUTLINE DRAWING
SIZE
FSCM NO.
A
43321
2
DWG. NO.
REV.
CTL5B-5B-OD1
CTL5B-5B-OD1.SLDDRW
SCALE: NONE CAD FILE:
SHEET 1 OF 1
D
8
7
6
5
4
3
1
