Frontier Electronics Corp.
667 E. COCHRAN STREET, SIMI VALLEY, CA 93065
TEL: (805) 522-9998 FAX: (805) 522-9989
E-mail: frontiersales@frontierusa.com
Web: frontierusa.com
Multi-layers Chip Inductors--
TF100505 (0402) Series—Ceramic
A. Electrical specifications:
Part
No.
TF100505-1N0S
TF100505-1N2S
TF100505-1N5S
TF100505-1N8S
TF100505-2N2S
TF100505-2N7S
TF100505-3N3_
TF100505-3N9_
TF100505-4N7_
TF100505-5N6_
TF100505-6N8_
TF100505-8N2_
TF100505-10N_
TF100505-12N_
TF100505-15N_
TF100505-18N_
TF100505-22N_
TF100505-27N_
TF100505-33N_
TF100505-39N_
TF100505-47N_
L @100MHz
(nH)
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10.0
12.0
15.0
18.0
22.0
27.0
33.0
39.0
47.0
Tolerance
S
S
S
S
S
S
S, K
S, K
S, K
S, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
J, K
Q Typical
@100MHz @800MHz
10
9
10
10
10
10
10
11
10
11
10
12
12
12
11
11
11
12
10
10
9
28
28
30
28
30
30
30
31
30
31
31
34
32
31
30
29
28
27
25
25
23
SRF min.
(MHz)
6000
6000
6000
6000
6000
5500
5000
4700
4300
4000
3650
3200
2800
2700
2200
2000
1800
1600
1700
1650
1300
DCR
(Max)
Ω
0.10
0.10
0.10
0.10
0.20
0.20
0.30
0.30
0.40
0.40
0.50
0.50
0.60
0.60
0.70
0.8
0.90
1.00
1.50
1.80
2.00
I rms.
(mA)
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
200
200
200
B. Dimensions: [Unit: mm /( inch)]
P/N & Package Size
TF100505
(0402)
A
1.0 ± 0.1
(0.04 ±0.004)
B
0.5 ± 0.1
(0.020 ± 0.004)
C
0.5 ± 0.1
(0.020±0.004)
D (min.)
0.100
(0.004)
C. Part Number Key & Mechanical drawing:
D. Features:
1.
2.
3.
4.
5.
6.
7.
8.
Tolerance: K: ±10%, J: ±5%, D: ±0.5nH, S: ±0.3nH.
The product’s material:
Ceramic.
No cross coupling between inductors due to magnetic shield. Ideal for high-density installation.
Superior Q characteristics guaranteed over the wide frequency and allow high frequency application.
The completely monolithic structure gives high reliability and allows high SRF.
Operating temperature range:
−25°C
to
+85°C.
Both flow and IR re-flow application are possible.
Inductance Range:
*TF1005 (0402) Series: Multi-layer Ceramic Chip Inductor, from 1.0 nH (300mA) to 47.0 nH (200mA)
Note:
For “RoHS” parts, we add “-LFR” after the part number.
Multi-layer chip inductor: P/N TF100505 (0402)-series
Rev. A
Jan. 01, 2006. Page: 1 of 1
