SYS-4U4320-4A02
SYS-4U4320-4S02
4U Intel
®
Core™ 2 Quad ATX/SBC
System with Dual SATA HDD Trays
Features
Intel Q35 platform
- Supports quad core and duo core processors with 45 nm processing
- Supports dual channel DDR2 667/800 SDRAM up to 8 GB
- Dual integrated GbE delivers excellent network performance
Easy data mirroring
- Supports two SATAII HDD mobile racks for data mirroring
Expandability
- Supports numerous PCI/PCIe add-on cards
- Great scalability with one 3.5" and three 5.25" front-accessible drive bays
Supports performance graphics card via PCIe x 16 slot
Specifications
Model
Form Factor
Chipset
CPU
L2 Cache
Front Side Bus
Memory
Controller
VRAM
PCIe x 16
PCIe x 1
PCI
Optical Drive (supported)
Floppy Disk (supported)
HDD (supported)
5.25" (front-accessible)
3.5" (front-accessible)
3.5" (mobile rack)
Interface
Controller
USB
USB
PS/2
COM
VGA
Parallel
RJ-45
Audio
Output
Interval
Power Output Wattage
Input Range
Chassis Fan
Air Filter
LED Indicators
Temperature
Humidity
Dimensions (W x H x D)
Weight
SYS-4U4320-4A02
4U Rackmount
Intel Q35 + ICH9
Core 2 Quad Core 2 Duo
Pentium
Dual Core
2.2 GHz
1 MB
SYS-4U4320-4S02
4U Rackmount
Intel Q35 + ICH9
Core 2 Quad Core 2 Duo
Pentium
Dual-Core
2.40 GHz
1 MB
Celeron
Sequence
400 2 GHz
512 KB
Processor System
Graphics
Expansion Slot
Storage
Drive Bay
Ethernet
Front I/O Interface
Rear I/O Interface
Operating System
Watchdog Timer
Power Supply
Cooling
Miscellaneous
Environment
Physical Characteristics
2.83 GHz
3.16 GHz
12 MB
6 MB
512 KB
800/1066/1333 MHz
Dual channel DDR2 667/800 MHz up to 8 GB
Intel GMA3100 integrated
Dynamically shared system memory up to 256 MB
1
2
4
CD-ROM / DVD-ROM / CD-RW
3.5" 1.44 MB FDD
SATA
2
1
2
10/100/1000 Mbps Gigabit Ethernet
Intel 82566DM, 82573V
2
4
2
4
1
1
2
2 (Mic-in, Line-out)
Microsoft Windows 2000/ XP/ Vista
System reset
Programmable 1 ~ 255 seconds
400 W
AC 100 ~ 240 V
2 (12 cm / 114 CFM + 6 cm / 28 CFM)
Yes
Power, HDD activity, temperature, fan and LAN
connectivity
Operating
Non- Operating
0 ~ 40° C (32 ~ 104° F)
-20 ~ 60° C (-4 ~ 140° F)
10 ~ 85% @ 40° C
10 ~ 95% @ 40° C
non-condensing
non-condensing
482 x 177 x 478 mm (19" x 7" x 18.8")
20 kg (44 lb)
Celeron
2.0 GHz
2.83 GHz
3.16 GHz
12 MB
6 MB
800/1066/1333 MHz
Dual channel DDR2 667/800 MHz SDRAM up to 8 GB
Intel GMA3100 integrated
Dynamically shared system memory up to 256 MB
1
4
4
CD-ROM / DVD-ROM / CD-RW
3.5" 1.44 MB FDD
SATA
2
1
2
10/100/1000 Mbps Gigabit Ethernet
Intel 82566DM, 82573V
2
4
1
2~6
1
1
2
-
Microsoft Windows 2000/ XP/ Vista
System reset
Programmable 1 ~ 255 seconds
400 W
AC 100 ~ 240 V
2 (12 cm / 114 CFM + 6 cm / 28 CFM)
Yes
Power, HDD activity, temperature, fan and LAN
connectivity
Operating
Non- Operating
0 ~ 40° C (32 ~ 104° F)
-20 ~ 60° C (-4 ~ 140° F)
10 ~ 85% @ 40° C
10 ~ 95% @ 40° C
non-condensing
non-condensing
482 x 177 x 478 mm (19" x 7" x 18.8")
20 kg (44 lb)
Pre-Configured Systems
All product specifications are subject to change without notice
Last updated : 24-Mar-2009
SYS-4U4320-4A02
SYS-4U4320-4S02
Dimensions
SYS-4U4320-4A02
101.6 [4.0]
SYS-4U4320-4S02
101.6 [4.0]
Unit: mm (inch)
426 [16.8]
426 [16.8]
465 [18.3]
482 [19.0]
426 [16.8]
92 92 92 98
[3.6] [3.6] [3.6] [3.9]
172.7
[6.8]
177 [7.0]
92 92 92 98
[3.6] [3.6] [3.6] [3.9]
47.9 [1.9]
477.4 [18.8]
492.3 [19.4]
47.9 [1.9]
177 [7.0]
Ordering Information
Please visit Advantech CTOS portal for order entry.
http://www.advantech.com/ctos
86.4 [3.4]
477.4 [18.8]
492.3 [19.4]
System Content
Model Number
SYS-4U4320-4A02
Item
Chassis
Motherboard
CPU Cooler
Power Supply
Chassis
SBC
Backplane
CPU Cooler
Power Supply
Optional Accessories
Part Number
ACP-4320MB-00XE
AIMB-766G2-00A1E
19600022033T000
PS-400ATX-ZBE
ACP-4320BP-00XE
PCE-5124G2-00A1E
PCE-5B10-04A1E
1750000332
PS-400ATX-ZBE
1701092300 (Dual COM port
cable kit for COM 1-2)
1700008762 (Dual COM ports
cable kit for COM 3-4 and
COM 5-6)
SYS-4U4320-4S02
Front View
Inside View
LED indicators
for power, fan,
temperature,
HDD
CD-ROM
SATA HDD
mobile rack
Download
www.advantech.com/products
426 [16.8]
465 [18.3]
482 [19.0]
Easy-to-replace
system fan
design
Power technology
