EKI-2526PI: Description5-port Industrial PoE Switch; File Size552KB，1 Pages; ManufacturerAdvantech; Websitehttp://www.advantech.com/

Download Datasheet Compare View All

EKI-2526PI Overview

5-port Industrial PoE Switch

Preview

Download Datasheet

View All

EKI-2525P

EKI-2525PA

EKI-2526PI

NEW

Features

5-port Industrial PoE Switch

5-port Industrial PoE Switch with

24/48 V

Power Input

6-port Industrial PoE Switch with

Wide Temperature



Provides 5/6 Fast Ethernet ports with 4 PoE ports with injector function



Supports 10/100Mbps Auto Negotiation



Provides broadcast storm protection



Supports Ethernet ESD protection



Provides surge (EFT) protection 3,000 V

for power line



Provides Slim size, DIN-rail/Wallmount with IP30 metal mechanism



Supports Redundant 48 V

power input and P-Fail relay

(EKI-2525P/EKI-2526PI)



Supports Redundant 24/48 V

power input and P-Fail Relay (EKI-2525PA)



Supports operating temperatures from -10 ~ 60° C (EKI-2525P/EKI-2525PA)



Supports wide operating temperature -40 ~ 75° C (EKI-2526PI)

EKI-2525P

EKI-2525PA

RoHS

2002/95/EC

EKI-2526PI

COMPLIANT

Introduction

The EKI-2525P/EKI-2525PA is a 5-port unmanaged PoE (Power-over-Ethernet) Industrial Ethernet switch and EKI-2526PI is a 6-port unmanaged PoE Industrial Ethernet switch, they

support 4 PoE ports which are classified as power source equipments (PSE). The PoE devoces makes centralized power supply come true and provides up to 15.4 watts of power per

port. Advantech EKI PoE devices can be used to power IEEE802.3af compliant powered devices (PD) by Ethernet cable and eliminates the need for additional power wiring. Advantech

EKI PoE devices come equipped with all the standard features of the EKI family. Furthermore, it offers a 48 V

redundant power input design (EKI-2525P/EKI-2526PI) and 24/48 V

redundant power input design (EKI-2525PA), and is secured with a double protection mechanism; Power Polarity Reverse Protect and an Overload Current Resettable Fuse. Advantech

EKI PoE devices come with compact metal housing that rates IP30 to help against from dusty industrial environments.

Specifications

Communications



Standard

LAN

Transmission Distance

Transmission Speed

IEEE 802.3, 802.3u, 802.3x, 802.3af

10/100Base-T(X)

Up to 100 m

Up to 100 Mbps

PoE Ports: 4 (Ports 1 ~ 4)

Ethernet x1 (EKI-2525P/EKI-2525PA)

Ethernet x2 (EKI-2526PI)

6-pin removable screw terminal (power & relay)

P1, P2, P-Fail

10/100TX: Link/Activity, Duplex/Collision

EKI-2525P: 65 W (Full load PoE)

EKI-2525PA: 62.5 W (Full load PoE)

EKI-2526PI: 62.6 W (Full load PoE)

48 V

(EKI-2525P/EKI-2526PI), redundant dual inputs

24/48 V

(EKI-2525PA), redundant dual inputs

15.4 W at 48V (per PoE port)

1 Relay Output

Protection



ESD (Ethernet)

Surge (EFT for power)

Reverse Polarity

Overload

4,000 V

3,000 V

Present

EKI-2525P: 3 A @ 48 V

EKI-2525PA: 5 A @ 24/48 V

EKI-2526PI: 3.5 A @ 48 V

-10 ~ 60° C (14 ~ 140° F) (EKI-2525P/EKI-2525PA)

-40 ~ 75° C (-40 ~ 167° F) (EKI-2526PI)

-40 ~ 85° C (-40 ~ 185° F)

5 ~ 95% (non-condensing)

0 ~ 95% (non-condensing)

440,132 hrs

UL 60950-1, CAN/CSA-C22.2 No.60950

U.S.A.: FCC Part 15 CISPR 22

EU: EN55011, EN61000-6-4

EN55022 Class A,

EN61000-3-2/3

EN55024

IEC61000-4-2/3/4/5/6/8

EN61000-6-2

IEC60068-2-27

IEC60068-2-32

IEC60068-2-6

Interface



Connectors

Environment



Operating Temperature

Wide temp. model



Storage Temperature



Operating Humidity



Storage Humidity



MTBF



LED Indicators

Power



Power Consumption



Power Input



Power Output



Fault Output

Certifications



Safety



EMC

Mechanism



Dimensions (W x H x D)

37 x 140 x 95 mm (EKI-2525P)

48.6 x 140 x 95 mm (EKI-2525PA/EKI-2526PI)



Enclosure

IP30, Metal shell with solid mounting kits



Mounting

DIN-rail, Panel



Shock



Freefall



Vibration

Ordering Information



EKI-2525P



EKI-2525PA



EKI-2526PI

5-port PoE Switch

5-port PoE Switch 24/48 V

Power Input

6-port PoE Switch w/ Wide Temp

Industrial Ethernet Solutions

EKI-2526PI Related Products

	EKI-2526PI	EKI-2525P	EKI-2525PA
Description	5-port Industrial PoE Switch	5-port Industrial PoE Switch	5-port Industrial PoE Switch
