SMD Shielded Wire-wound Chip Inductors
ctparts.com
CT1008PSF Series
From 1.0 µH to 1000 µH
Part
Number
CT1008PSF-102_
CT1008PSF-152_
CT1008PSF-182_
CT1008PSF-222_
CT1008PSF-272_
CT1008PSF-392_
CT1008PSF-472_
CT1008PSF-562_
CT1008PSF-682_
CT1008PSF-103_
CT1008PSF-153_
CT1008PSF-223_
CT1008PSF-333_
CT1008PSF-393_
CT1008PSF-473_
CT1008PSF-683_
CT1008PSF-823_
CT1008PSF-104_
CT1008PSF-124_
CT1008PSF-154_
CT1008PSF-224_
CT1008PSF-334_
CT1008PSF-474_
CT1008PSF-564_
CT1008PSF-684_
CT1008PSF-824_
CT1008PSF-105_
Not shown at actual size.
SPECIFICATIONS
Please specify tolerance code when ordering.
CT1008PSF-102_
K = ±10%, M = ±20%
*Inductance drop = 10% typ. at IDC
Inductance
(µH)
1.0
1.5
1.8
2.2
2.7
3.9
4.7
5.6
6.8
10
15
22
33
39
47
68
82
100
120
150
220
330
470
560
680
820
1000
L Test
Freq.
(kHz)
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
Q
Fact.
Typ.
26
26
28
30
30
30
30
30
30
30
30
33
33
33
33
33
33
33
33
33
33
33
33
33
33
23
20
Q Test
Freq.
(MHz)
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
SRF
Typ.
(MHz)
344
260
225
228
185
172
157
150
110
95
75
30
21
18
15
12
10
8.0
8.0
5.8
5.5
3.8
3.1
2.8
2.5
2.0
1.5
DCR
Max.
Ω
(Ω)
0.05
0.08
0.09
0.14
0.14
0.29
0.35
0.39
0.58
0.75
1.15
1.40
1.61
1.85
2.2
3.8
4.3
4.8
5.0
6.5
12.0
17.0
19.0
18.4
24.0
26.0
29.2
*IDC
Max.
(A)
3.0
2.8
2.1
1.5
1.5
1.2
1.1
1.1
0.9
0.82
0.70
0.65
0.52
0.46
0.43
0.33
0.32
0.31
0.25
0.24
0.22
0.20
0.16
0.13
0.12
0.10
0.10
Compliant
RoHS
CHARACTERISTICS
Description:
SMD shielded wire-wound chip inductor
Applications:
LC resonant circuits such as oscillator and signal
generators, impedance matching, circuit isolation, RF filters, disk
drives and computer peripherals, audio and video equipment, TV,
radio and telecommunication equipment
Operating Temperature:
-25°C to +85°C
Inductance Tolerance:
±10%, ±20%
Testing:
Inductance and Q tested on an HP4285A at 100kHz,
100mV.
Packaging:
Tape & Reel
Miscellaneous:
RoHS Compliant.
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
PHYSICAL DIMENSIONS
Size
mm
inches
A
Max.
3.81
0.150
B
Max.
3.81
0.150
C
Max.
2.94
0.116
D
2.20
0.087
E
2.54
0.100
F
2.03
0.080
G
0.51
0.020
PAD LAYOUT
Note:
Part Number CT1008PSF-474
Dimension C = 3.05mm (0.120in) Max.
09.21.09
CENTRAL
Manufacturer of Passive Components
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2009 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
TECHNOLOGIES
