HLMP-ALxx/BLxx/ADxx/BDxx/BB11/BM11
T-1
3
/
4
(5 mm) Oval Precision Optical Performance
AlInGaP and InGaN Lamps
Data Sheet
Description
These Precision Optical Performance Oval LEDs are
specifically designed for full color/video and
passenger information signs. The oval shaped
radiation pattern (35° x 70° ) and high luminous
intensity ensure that these devices are excellent for
wide field of view outdoor application where a wide
viewing angle and readability in sunlight are essential.
These lamps have very smooth, matched radiation
patterns ensuring consistent color mixing in full
color applications, message uniformity across the
viewing angle of the sign.
High efficiency LED material is used in these lamps:
Aluminum Indium Gallium Phosphide (AlInGaP) for
amber and red, and Indium Gallium Nitride (InGaN)
for blue and green. Each lamp is made with an
advance optical grade epoxy offering superior high
temperature and high moisture resistance in outdoor
applications. The package epoxy contains both UV-
A and UV-B inhibitors to reduce the effects of long
term exposure to direct sunlight.
Designers can select parallel or perpendicular
orientation. Both lamps are available in tinted version.
Features
• Well defined spatial radiation pattern
• Viewing angles:
Major axis 70°
Minor axis 35°
• High luminous output
• Red and Amber intensity are available for:
AlInGaP (Bright)
AlInGaP II (Brightest)
• Colors:
472 nm blue
526 nm green
626 nm red
630 nm red
590 nm amber
592 nm amber
• Superior resistance to moisture
• UV resistant epoxy
Benefits
• Viewing angle designed for wide field of view
application
• Red, green, and blue radiation patterns matched for full
color sign
• Superior performance in outdoor environments
Applications
• Full color/video signs
CAUTION: The blue and green LEDs are Class 1 ESD sensitive. Please observe appropriate
precautions during handling and processing. Refer to Avago Application Note AN-1142 for
additional details.
Part Numbering System
HLMP-X X X X - X X X XX
Mechanical Options
00: Bulk Packaging
DD: Ammo Pack
YY: Flexi-Bin; Bulk Packaging
ZZ: Flexi-Bin; Ammo Pack
Color Bin
0: No Color Bin Limitation
B: Color bin 2 and 3 only
K: Color bins 2 and 4 only
R: Color Bins 1, 2, 4, and 6 with V
F
max of 2.6 V
S: Color bins 2 and 4 with VF max of 2.6 V
T: Red Color with V
F
max of 2.6 V
Maximum Intensity Bin
0: No Iv Bin Limitation
Minimum Intensity Bin
Tint Option
1 or 6: Matching Color Tints
Standoff Option
0: Without
1: With
Color
B: 472 nm Blue
D: 630 nm Red
G: 626 nm Red
L: 590 or 592 nm Amber
M: 526 nm Green
Package
A: 5 mm Mini Oval, Parallel
B: 5 mm Mini Oval, Perpendicular
4
Package Dimensions
8.71 ± 0.20
(0.343 ± 0.008)
5.00 ± 0.20
(0.197 ± 0.008)
0.70 (0.028)
MAX.
0.50 ± 0.10 SQ. TYP.
(0.020 ± 0.004)
2.54 ± 0.38
(0.100 ± 0.015)
A
CATHODE
LEAD
31.60 MIN.
(1.244)
1.00 MIN.
(0.039)
8.71 ± 0.20
(0.343 ± 0.008)
5.00 ± 0.20
(0.197 ± 0.008)
1.50 ±0.15
(0.059 ± 0.006)
0.50 ± 0.10 SQ. TYP.
(0.020 ± 0.004)
0.70 (0.028)
MAX.
2.54 ± 0.38
(0.100 ± 0.015)
B
+ 0.13
11.70 – 0.08
CATHODE
LEAD
31.60
MIN.
(1.244)
8.71 ± 0.20
(0.343 ± 0.008)
5.00 ± 0.20
(0.197 ± 0.008)
0.70 (0.028)
MAX.
0.50 ± 0.10 SQ. TYP.
(0.020 ± 0.004)
2.54 ± 0.38
(0.100 ± 0.015)
1.00 MIN.
(0.039)
(
+ 0.005
0.461 – 0.003
)
C
CATHODE
LEAD
31.60 MIN.
(1.244)
1.00 MIN.
(0.039)
8.71 ± 0.20
(0.343 ± 0.008)
5.00 ± 0.20
(0.197 ± 0.008)
1.50 ±0.15
(0.059 ± 0.006)
0.50 ± 0.10 SQ. TYP.
(0.020 ± 0.004)
0.70 (0.028)
MAX.
2.54 ± 0.38
(0.100 ± 0.015)
D
CATHODE
LEAD
31.60 MIN.
(1.244)
1.00 MIN.
(0.039)
NOTES:
1. ALL DIMENSIONS ARE IN MILLIMETERS (INCHES).
2. LEADS ARE MILD STEEL, SOLDER DIPPED.
3. TAPERS SHOWN AT TOP OF LEADS (BOTTOM OF LAMP PACKAGE) INDICATE AN
EPOXY MENISCUS THAT MAY EXTEND ABOUT 1 mm (0.040 IN.) DOWN THE LEADS.
4. RECOMMENDED PC BOARD HOLE DIAMETERS:
– LAMP PACKAGES A AND C WITHOUT STAND-OFFS: FLUSH MOUNTING AT BASE
OF LAMP PACKAGE = 1.143/1.067 mm (0.044/0.042 IN.).
– LAMP PACKAGES B AND D WITH STAND-OFFS: MOUNTING AT LEAD STAND-OFFS.
