D SERIES
Piconics D series is a molded inductor. It has flexible ribbon leads which may be welded or soldered into circuits or thin film or
thick substrates. The leads can be either silver plated copper or gold. This product is designated for use in microcircuits
where dense packaging and high reliability are essential. A special lead anchorage is used for inductance values using fine
wire for higher reliability. Two heights are available, depending on electrical value.
Piconics
Part
Number
D100K8I
D200K8I
D560K8I
D101K8I
D121K8I
D151K8I
D181K8I
D221K8I
D271K8I
D331K8I
D391K8I
D471K8I
D561K8I
D681K8I
D761K8I
D821K8I
D102K6I
D122K6I
D152K6I
D182K6I
D222K6I
D272K6I
D332K6I
D392K6I
D472K6I
D562K6I
D682K6I
D822K6I
D103K3F
D123K3F
D153K3F
D183K3F
D223K3F
D273K3F
D333K3F
D473K3F
D563K3F
D683K3F
D823K3F
D104K3F
D124K3F
D154K3F
D184K3F
D224K3F
D274K3F
D334K3F
D394K3F
D474K3F
D564K1F
D684K1F
D824K1F
D105K1F
L uH +/-
10%
.01
.02
.056
.10
.12
.15
.18
.22
.27
.33
.39
.47
.56
.68
.76
.82
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
Q Min
35
35
35
32
32
32
32
32
32
32
32
32
32
32
32
32
30
30
30
30
30
30
30
30
30
30
30
30
28
28
28
28
28
28
28
28
28
28
28
24
24
24
24
24
24
24
24
24
24
24
24
20
Test
Freq
MHz
200
200
100
25
25
25
25
25
25
25
25
25
25
25
25
25
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.25
SRF
Min
MHz
1200
1000
800
750
700
650
600
570
500
400
380
350
325
300
280
250
220
175
135
120
95
85
70
60
50
40
30
22
20
15
13
12
10
9
9
6
6
6
5.5
4.0
4.0
3.9
3.5
3.2
3.1
2.8
2.5
2.3
2.2
2.1
2.1
1.1
DCR
Max
Ohms
.03
.04
.15
.22
.30
.35
.45
.60
.65
.75
.90
1.2
1.5
1.9
2.1
2.2
2.7
2.7
2.9
3.0
3.8
4.0
4.0
4.2
4.2
4.2
4.2
4.2
4.7
5.0
5.0
5.0
5.0
6.0
6.0
6.3
6.3
7.0
7.5
12
14
16
18
21
23
37
39
45
47
62
80
96
Idc
Max
ma
250
250
250
250
250
250
250
250
250
250
250
250
250
250
240
230
210
200
190
185
180
175
170
165
165
165
150
120
105
91
87
81
77
73
69
63
60
57
55
50
40
36
33
28
25
20
17
15
13
12
11
10
FEATURES:
•
High Packing Density
•
Molded Case
•
Welded Leads
ABSOLUTE MAXIMUM RATINGS:
•
Operating temperature range: -55° C to +125° C
•
Storage temperature range: -55° C to + 125° C
•
Temperature rise (at 90° C): 35°C
•
Maximum operating temperature: 125° C
PHYSICAL CHARACTERISTICS:
•
Leads: Silver Plated Copper or Gold Ribbon
•
Case: Epoxy Molded
Piconics Inc.
www.Piconics.com
26 Cummings Rd Tyngsboro, MA 01879
E-Mail:
Sales@Piconics.com
Tel: 978-649-7501
Fax: 978-649-9643
