CD4052BE datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> The signal circuit> CD4052BE

CD4052BE: Description4-CHANNEL, DIFFERENTIAL MULTIPLEXER, PDIP16, PACKAGE-16; CategoryAnalog mixed-signal IC The signal circuit; File Size1MB，16 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/; Environmental Compliance; Related ProductsFound13parts with similar functions to CD4052BE

Download Datasheet Parametric Compare View All

CD4052BE Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	CD4052BE	-	-	View	Buy Now

CD4052BE Overview

4-CHANNEL, DIFFERENTIAL MULTIPLEXER, PDIP16, PACKAGE-16

CD4052BE Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Rochester Electronics
Parts packaging code	DIP
package instruction	DIP,
Contacts	16
Reach Compliance Code	unknown
Analog Integrated Circuits - Other Types	DIFFERENTIAL MULTIPLEXER
JESD-30 code	R-PDIP-T16
JESD-609 code	e4
Humidity sensitivity level	NOT APPLICABLE
Number of channels	4
Number of functions	1
Number of terminals	16
Maximum on-state resistance (Ron)	240 Ω
Package body material	PLASTIC/EPOXY
encapsulated code	DIP
Package shape	RECTANGULAR
Package form	IN-LINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Nominal supply voltage (Vsup)	15 V
surface mount	NO
technology	CMOS
Terminal surface	NICKEL PALLADIUM GOLD
Terminal form	THROUGH-HOLE
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
