PD Series
SMT Power Choke Core
* Test Measurement Frequency
Values < 10µH tested @ 7.96MHz;
Values
≥10uH
@ 0.100 MHz (1.0 KHz)
Mechanical Configuration
Units designed for Surface Mounting
Terminals
Solder Coated with SN63 solder
Core Construction
High Resistivity Ferrite
Operating Temperature Range
–55°C to +125°C
POWER INDUCTORS
Current Rating at 25°C Ambient
The maximum DC
Current that will cause a 40°C maximum temperature
rise and where the inductance will not decrease by more
than 10% from the zero DC value.
** Inductance Tolerance
Tolerance is indicated by the
suffix to API part number. Standard tolerance per part
number is as shown in table. M = ±20%; K = ±10%.
Additional Information
on Next Page
Physical Parameters
Dimensions
Inches
PD43
A
0.165 ±0.024
0.137 MAX.
B
0.153 ±0.012
C
0.060 REF.
D
Millimeters
A
B
C
D
PD43
4.2 ±0.6
3.5 MAX.
3.9 ±0.3
1.52 REF.
PD54
0.224 ±0.008
0.177 MAX.
0.201 ±0.008
0.051 REF.
PD54
5.7 ±0.2
4.5 MAX.
5.1 ±0.2
1.30 REF.
PD73
0.303 ±0.008
0.138 MAX.
0.272 ±0.008
0.063 REF.
PD73
7.7 ±0.2
3.5 MAX.
6.9 ±0.2
1.60 REF.
PD75
0.303 ±0.008
0.197 MAX.
0.272 ±0.008
0.063 REF.
PD75
7.7 ±0.2
5.0 MAX.
6.9 ±0.2
1.60 REF.
PD104
0.386 ±0.016
0.157 MAX.
0.346 ±0.016
0.083 REF.
PD104
9.8 ±0.4
4.0 MAX.
8.8 ±0.4
2.10 REF.
PD105
0.386 ±0.016
0.213 MAX.
0.346 ±0.016
0.083 REF.
PD105
9.8 ±0.4
5.4 MAX.
8.8 ±0.4
2.10 REF.
Packaging
Tape & reel. 7" reel not available; maximum pieces per 13" reel as follows
PD43
PD54
PD73
PD75
mm
12
16
16
16
Pieces
1500
1000
1000
500
PD104
24
1000
PD105
24
500
PAGE
72
www
.
delevan
.
com
E-mail: apisales@delevan.com
270 Quaker Rd., East Aurora NY 14052 • Phone 716-652-3600 • Fax 716-652-4814
7/2001
IN
D
@ UCT
1 K AN
Hz CE
* (µ
DC
H)
MA RES
XI IST
MU A
CU M ( NCE
OH
R
MA RE
MS
X. NT
)
(A RA
MP T
S) ING
IN
D
@ UCT
1 K AN
Hz CE
* (µ
DC
H)
MA RES
XI IST
MU A
CU M ( NCE
OH
R
MA RE
MS
X. NT
)
(A RA
MP T
S) ING
PA
RT
PA
RT
SERIES PD43
PD43-102M
PD43-152M
PD43-182M
PD43-222M
PD43-272M
PD43-332M
PD43-392M
PD43-472M
PD43-562M
PD43-682M
PD43-822M
PD43-103M
PD43-123M
PD43-153M
PD43-183M
PD43-223M
PD43-273M
PD43-333K
PD43-393K
PD43-473K
PD43-563K
PD43-683K
PD54-102M
PD54-152M
PD54-182M
PD54-222M
PD54-272M
PD54-332M
PD54-392M
PD54-472M
PD54-562M
PD54-682M
PD54-822M
PD54-103K
PD54-123K
PD54-153K
PD54-183K
PD54-223K
PD54-273K
PD54-333K
PD54-393K
PD54-473K
PD54-563K
PD54-683K
PD54-823K
PD54-104K
PD54-124K
PD54-154K
PD54-184K
PD54-224K
1.0**
1.5**
1.8**
2.2**
2.7**
3.3**
3.9**
4.7**
5.6**
6.8**
8.2**
10
12
15
18
22
27
33
39
47
56
68
1.0**
1.5**
1.8**
2.2**
2.7**
3.3**
3.9**
4.7**
5.6**
6.8**
8.2**
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
0.049
0.056
0.064
0.071
0.079
0.086
0.094
0.109
0.126
0.131
0.146
0.182
0.210
0.235
0.338
0.378
0.522
0.540
0.587
0.844
0.937
1.120
0.050
0.055
0.060
0.064
0.067
0.070
0.075
0.080
0.085
0.090
0.095
0.100
0.130
0.160
0.180
0.210
0.240
0.280
0.320
0.370
0.420
0.500
0.600
0.700
0.850
1.100
1.330
1.570
2.56
2.52
1.95
1.75
1.58
1.44
1.33
1.15
0.99
0.95
0.84
0.83
0.80
0.77
0.74
0.66
0.62
0.56
0.52
0.44
0.42
0.37
2.90
2.70
2.60
2.40
2.20
2.00
1.90
1.80
1.70
1.60
1.50
1.44
1.35
1.27
1.19
1.11
1.00
0.90
0.80
0.72
0.68
0.63
0.58
0.52
0.46
0.40
0.37
0.35
PD73-332M
PD73-392M
PD73-472M
PD73-562M
PD73-682M
PD73-822M
PD73-103K
PD73-123K
PD73-153K
PD73-183K
PD73-223K
PD73-273K
PD73-333K
PD73-393K
PD73-473K
PD73-563K
PD73-683K
PD73-823K
PD73-104K
PD73-124K
PD73-154K
PD73-184K
PD73-224K
PD75-103K
PD75-123K
PD75-153K
PD75-183K
PD75-223K
PD75-273K
PD75-333K
PD75-393K
PD75-473K
PD75-563K
PD75-683K
PD75-823K
PD75-104K
PD75-124K
PD75-154K
PD75-184K
PD75-224K
SERIES PD73
3.3**
3.9**
4.7**
5.6**
6.8**
8.2**
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
0.050
0.055
0.060
0.065
0.070
0.075
0.080
0.090
0.100
0.115
0.130
0.170
0.205
0.230
0.250
0.280
0.350
0.410
0.480
0.570
0.750
1.000
1.200
0.080
0.085
0.085
0.090
0.090
0.120
0.150
0.180
0.210
0.240
0.300
0.370
0.500
0.570
0.640
0.680
0.720
2.50
2.30
2.10
1.90
1.75
1.60
1.44
1.35
1.30
1.20
1.07
0.98
0.90
0.80
0.68
0.64
0.59
0.54
0.51
0.45
0.40
0.35
0.31
2.00
1.90
1.75
1.60
1.50
1.40
1.30
1.20
1.10
0.94
0.85
0.78
0.74
0.68
0.58
0.54
0.49
PA
RT
SERIES PD104
PD104-472M
PD104-562M
PD104-682M
PD104-822M
PD104-103K
PD104-123K
PD104-153K
PD104-183K
PD104-223K
PD104-273K
PD104-333K
PD104-393K
PD104-473K
PD104-563K
PD104-683K
PD104-823K
PD104-104K
PD104-124K
PD104-154K
PD104-183K
PD104-224K
PD104-274K
PD104-334K
PD104-394K
PD104-474K
PD104-564K
PD104-684K
PD105-103K
PD105-123K
PD105-153K
PD105-183K
PD105-223K
PD105-273K
PD105-333K
PD105-393K
PD105-473K
PD105-563K
PD105-683K
PD105-823K
PD105-104K
PD105-124K
PD105-154K
PD105-184K
PD105-224K
PD105-274K
PD105-334K
PD105-394K
PD105-474K
PD105-564K
PD105-684K
PD105-824K
4.7**
5.6**
6.8**
8.2**
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
0.040
0.045
0.045
0.050
0.050
0.060
0.070
0.080
0.090
0.110
0.130
0.150
0.170
0.200
0.220
0.250
0.340
0.450
0.540
0.630
0.720
0.900
1.100
1.300
1.530
1.900
2.300
0.060
0.070
0.080
0.090
0.100
0.115
0.125
0.145
0.170
0.190
0.230
0.250
0.350
0.420
0.470
0.560
0.730
0.950
1.150
1.350
1.480
1.900
2.250
2.550
3.00
2.85
2.70
2.55
2.38
2.20
2.00
1.80
1.60
1.45
1.30
1.20
1.10
1.01
0.94
0.85
0.74
0.67
0.61
0.57
0.53
0.48
0.42
0.39
0.35
0.32
0.28
2.60
2.45
2.30
2.15
1.95
1.80
1.65
1.40
1.28
1.17
1.08
1.00
0.97
0.88
0.80
0.72
0.66
0.60
0.52
0.48
0.42
0.33
0.28
0.24
IN
D
@ UCT
1 K AN
Hz CE
* (µ
DC
H)
MA RES
XI IST
MU A
CU M ( NCE
OH
R
MA RE
MS
X. NT
)
(A RA
MP T
S) ING
NU
MB
ER
NU
MB
ER
NU
MB
ER
POWER INDUCTORS
SERIES PD54
SERIES PD75
SERIES PD105
www
.
delevan
.
com
E-mail: apisales@delevan.com
7/ 2000
PAGE
270 Quaker Rd., East Aurora NY 14052 • Phone 716-652-3600 • Fax 716-652-4814
73
