Document 188-1
SMT Power Inductors - DS5022 Series
The DS5022 Series is a family of magnetically shielded
power inductors designed for the higher current require-
ments of portable computers, video recorders and other
DC-DC conversion applications.
They feature saturation current ratings as high as 8 Amps
and rms current ratings up to 3.9 Amps. Low DC resis-
tance (as low as 0.040 Ohms) keeps power losses to a
minimum.
Designed specifically for surface mounting, the DS5022
has a flat top for reliable pick and place operations. The
terminals wrap around the end of the base to ensure a
sound solder fillet and simplify inspection.
Coilcraft
Designer’s Kit C117
contains samples of each
of the standard parts shown. To order, contact Coilcraft
or visit
http://order.coilcraft.com.
L ± 20%
2
DCR max SRF typ
Part Number
(µH)
(Ohms)
(MHz)
1
Isat
3
Irms
4
(A)
(A)
8.0
7.0
6.0
5.0
4.0
3.0
2.4
2.1
1.9
1.1
1.1
0.96
0.80
3.9
3.4
3.1
2.8
2.4
2.0
1.7
1.3
1.1
0.86
0.73
0.64
0.53
DS5022P-103
DS5022P-153
DS5022P-223
DS5022P-333
DS5022P-473
DS5022P-683
DS5022P-104
DS5022P-154
DS5022P-224
DS5022P-334
DS5022P-474
DS5022P-684
DS5022P-105
10
15
22
33
47
68
100
150
220
330
470
680
1000
0.040
0.048
0.059
0.075
0.097
0.138
0.207
0.293
0.47
0.78
1.08
1.40
2.01
30
20
18
14
10
9
7
6
5
4
3
2.5
2.0
Weight:
2.6 – 3.0 g
Terminations:
Nickel/gold over phos bronze
Tape and reel:
250/13″ reel 32 mm tape width
For packaging data see Tape and Reel Specifications section.
1. Part number on reel label may have a B suffix to indicate that the
reel is not machine ready.
2. Inductance tested at 0.1 Vrms, 100 kHz, 0 Adc.
3. DC current at which the inductance drops 10% (typ) from its
value without current.
4. Average current for a 40°C rise above 25°C ambient.
5. Operating temperature range -40°C to +85°C.
6. Electrical specifications at 25°C.
See Qualification Standards section for environmental and test data.
Specifications subject to change without notice.
Please check our website for latest information. Document 188-1
Revised 12/20/04
