Rx5RW Series
Voltage Regulator
The Rx5RW Series are chip enable pin-equipped CMOS-based voltage regulators featuring 35mA to 80mA output.
The polarity of the CE pin can be selected.
FEATURES
•
Supply Current (I
SS
) ························Typ. 1.5μA (V
IN
=SET V
OUT
+2V)
•
Standby Current (I
standby
) ·················Typ. 0.1μA (in standby, except for C Version)
•
Dropout Voltage (V
DIF
) ····················Typ. 0.04V (I
OUT
=1mA, V
OUT
=2.8V)
•
Input Voltage Range (V
IN
) ···············Max. 8.0V
•
Output Voltage Range (V
OUT
)··········1.5V to 6.0V (internally fixed)
•
Output Voltage Accuracy ················± 2%
•
Temp. coeff. of Output Voltage ·······Typ.
±
100ppm/°C
•
Line Regulation·······························Typ. 0.05%/V
•
Fold-back Protection Circuit ···········Current Limit Typ. 40mA
•
Packages········································SON1612-6, SC-82AB
BLOCK DIAGRAMS
Rx5RWxxA
(
CE
pin "L" active)
V
DD
V
OUT
V
DD
Rx5RWxxB
(CE pin "H" active)
V
OUT
V
DD
Rx5RWxxC
(Without CE pin)
V
OUT
+
-
Vref
CE
Current Limit
GND
CE
Vref
+
-
Current Limit
GND
NC
Vref
+
-
Current Limit
GND
SELECTION GUIDES
Package
SON1612-6
SC-82AB
Quantity per Reel
Part No.
4,000 pcs
RD5RW
.xx∗
A-TR-F
3,000 pcs
RQ5RW
.xx∗
A-TR-F
.xx.
: Specify the output voltage within the range 1.5V (.15.) to 6.0V (.60.)
in 0.1V steps.
.∗
: Select the polarity of the CE pin from
(.A.) "L" active or (.B.) "H" active, (.C.) without chip enable.
PACKAGES (Top View)
SON1612-6
6
5
4
TYPICAL CHARACTERISTIC
SC-82AB
4
3
Rx5RW30B
2.0
1.8
1.6
1.4
1.2
1.0
0.8
0.6
0.4
0.2
0
Dropout Voltage V
DIF
(V)
Dropout Voltage vs. Output Current
85°C
25°C
-40°C
1
2
3
1
2
1
2
3
4
5
6
CE
or CE or NC
V
DD
V
OUT
NC
V
DD
GND
1
2
3
4
GND
V
DD
V
OUT
CE
or CE or NC
0
10
20
30
40
50
Output Current I
OUT
(mA)
APPLICATIONS
•
Power source for hand-held communication equipment, cameras, and VCRs
•
Very stable voltage reference
•
Power source for battery-powered equipment
