Cannon Crimp, Size 20
Military/High Reliability
D*MA Standard Density Crimp Contact Cable Connector
Plug
Shell Size
DE
DA
DB
DC
DD
Layout
9
14
25
37
50
Through Hole
DEMA9P
DAMA15P
DBMA25P
DCMA37P
DDMA50P
Dual
Float Mount
DEMAY9P
DAMAY15P
DBMAY25P
DCMAY37P
DDMAY50P
•
For contact cavity arrangements, see pages C-44.
•
For panel cutouts, see page C-49.
Engaging Face
A
C
10°
B
Ø 3,05 (.120)
Note: For residual magnetism level of 200 Gamma and shells and contacts with 50
micro inches (1,27m) gold plating, add NMBK52. Example: DEMA15PNMBK52.
For connectors without contacts, add F0. Example: DEMA15PF0 (F0 not marked on
connector). For crimp (Size 22) contacts and tooling, see page C-13.
E
D
8,76 (.345) MAX
L
K
F
W
Dimensions
Shell
size
A
± 0,38 (.015)
B
± 0,13 (.005)
C
± 0,13 (.005)
D
± 0,13 (.005)
E
± 0,38 (.015)
F
± 0,25 (.010)
W
K
L
± 0,368 (.0145) ± 0,317 (.0125) ± 0,25 (.010)
DE
DA
DB
DC
DD
30,81 (1.213)
39,14 (1.541)
53,04 (2.088)
69,32 (2.729)
66,93 (2.635)
16,92 (.666)
25,25 (.994)
38,96 (1.534)
55,42 (2.182)
52,81 (2.079)
24,99 (8,36)
33,32 (1.312)
47,04 (1.852)
63,50 (2.500)
61,11 (2.406)
8,36 (.329)
8,36 (.329)
8,36 (.329)
8,36 (.329)
11,07 (.436)
12,55 (.494)
12,55 (.494)
12,55 (.494)
12,55 (.494)
15,37 (.605)
10,90 (.429)
10,90 (.429)
10,90 (.429)
10,90 (.429)
10,90 (.429)
6,94 (.273)
6,94 (.273)
6,94 (.273)
6,94 (.273)
6,94 (.273)
1,206 (.0475)
1,206 (.0475)
1,206 (.0475)
1,206 (.0475)
1,206 (.0475)
0,76 (.030)
0,76 (.030)
0,76 (.030)
0,76 (.030)
0,76 (.030)
C
D Sub
Receptacle
•
For contact cavity arrangements, see pages C-44.
•
For panel cutouts, see page C-49.
Engaging Face
A
C
B
Ø 3,05 (.120)
Shell Size
DE
DA
DB
DC
DD
Layout
9
15
25
37
50
Through Hole
DEMA9S
DAMA15S
DBMA25S
DCMA37S
DDMA50S
Dual Float Mount
DEMAY9S
DAMAY15S
DBMAY25S
DCMAY37S
DDMAY50S
Note: For residual magnetism level of 200 Gamma and shells and contacts with
50 micro inches (1,27m) gold plating, add NMBK52. Example DEMA9SNMBK52 with
50 microinches gold. For connectors without contacts, add F0.
Example: DEMA9SF0 (F0 not marked on the connector).
For crimp (Size 20) contacts and tooling, see page C-13.
E
D
8,76 (.345) MAX
L
K
W
F
10°
Dimensions
Shell
size
A
± 0,38 (.015)
B
± 0,13 (.005)
C
± 0,13 (.005)
D
± 0,13 (.005)
E
± 0,38 (.015)
F
± 0,25 (.010)
W
K
L
± 0,368 (.0145) ± 0,317 (.0125) ± 0,25 (.010)
DE
DA
DB
DC
DD
30,81 (1.213)
39,14 (1.541)
53,04 (2.088)
69,32 (2.729)
66,93 (2.635)
16,33 (.643)
24,66 (.971)
38,38 (1.511)
54,84 (2.159)
52,42 (2.064)
24,99 (.984)
33,32 (1.312)
47,04 (1.852)
63,50 (2.500)
61,11 (2.406)
7,90 (.311)
7,90 (.311)
7,90 (.311)
7,90 (.311)
10,74 (.423)
12,55 (.494)
12,55 (.494)
12,55 (.494)
12,55 (.494)
15,37 (.605)
10,90 (.429)
10,90 (.429)
10,90 (.429)
10,90 (.429)
10,90 (.429)
6,94 (.273)
6,94 (.273)
6,94 (.273)
6,94 (.273)
6,94 (.273)
1,206 (.0475)
1,206 (.0475)
1,206 (.0475)
1,206 (.0475)
1,206 (.0475)
0,76 (.030)
0,76 (.030)
0,76 (.030)
0,76 (.030)
0,76 (.030)
Dimensions shown in inches (mm)
Specifications and dimensions subject to change
www.ittcannon.com
C-11
