F-215 SUPPLEMENT
FCF–120–03–L–D–01–RA–SL
EMF–140–01–S–D
(1,27 mm) .050"
FCF, EMF SERIES
FLEXCARD TERMINAL & SOCKET STRIPS
SPECIFICATIONS
For complete specifications and
recommended PCB layouts see
www.samtec.com?FCF or
www.samtec.com?EMF
Insulator Material:
Black Liquid Crystal
Polymer
Terminal Material (FCF):
Phosphor Bronze
Contact Material (EMF):
BeCu
Plating:
Sn or Au over
50µ" (1,27 µm) Ni
Operating Temp Range:
FCF = -55°C to +105°C Tin
FCF = -55°C to +125°C Gold
EMF = -55°C to +125°C
Contact Resistance (EMF):
10 mΩ
Insertion Depth (EMF):
(3,05 mm) .120" to
(4,06 mm) .160"
Insertion Force (EMF):
(Single contact only)
3.0 oz (0,83 N) avg.
Withdrawal Force (EMF):
(Single contact only)
2.0 oz (0,56 N) avg.
Lead–Free Solderable:
Yes
SMT Lead Coplanarity (EMF):
(0,10 mm) .004" max (20)
(0,15 mm) .006" max (30-50)
RoHS Compliant:
Yes
™
FCF
1
NO. PINS
PER ROW
LEAD
STYLE
Specify
LEAD
STYLE
from
chart
PLATING
OPTION
D
CARD
SLOT
TAIL
OPTION
SL
Mates with:
EMF
–L
= 10µ" (0,25 µm)
Gold on post,
Matte Tin on tail
–01
= Accepts
(0,80 mm)
.031"
thick
card
20, 30, 40 & 50
(Standard sizes)
–RA
= Right Angle
(Leave blank for
vertical version.
Style –02 only)
No. of Positions x (1,27) .050 + (18,14) .714
No. of Positions x (1,27) .050
+ (13,82) .544
–S
= 30µ" (0,76 µm)
Gold on post,
Matte Tin on tail
LEAD
CARD-TO-BOARD
Y
STYLE
SPACE (X)
(2,60) .1025
– 02
(6,35) .250
– 03
(9,53) .375
(9,53) .375
(1,14)
.045
(1,27)
.050
(38,10)
1.500
(44,45)
1.750
(2,29)
.090
(2,29)
.090
(38,10) 1.500
(1,40)
.055
TYP
(3,81) .150
(1,27) .050
(2,54)
.100
DIA
TYP
–RA OPTION
Y
X
Style –02
Y
X
Style –03
APPLICATIONS
Reflowed solder
forced into lock notch
EMF
Plastic
Plated
Through-hole Solder Lock
1
NO. PINS
PER ROW
CARD
THICKNESS
PLATING
OPTION
D
Mates with:
FCF
– 01
20, 30, 40 & 50
(Standard sizes)
= (0,80 mm) .031"
thick board
–L
= 10µ" (0,25 µm)
Gold on contact,
Matte Tin on tail
RECOGNITIONS
For complete scope of
recognitions see
www.samtec.com/quality
–S
™
(3,05)
.120
No. of Positions x (1,27) .050
+ (3,76) .148
No. of Positions x (1,27) .050
+ (0,20) .008
(1,27)
.050
TYP
= 30µ" (0,76 µm)
Gold on contact,
Matte Tin on tail
(2,08) (0,56) .022
SQ
TYP
.082
(1,27)
.050
TYP
(3,12)
.123
(0,38)
.015
(0,81)
.032
(6,48) (4,57)
.180
.255
Note:
Some lengths,
styles and options are
non-standard, non-returnable.
(0,51) .020
WWW.SAMTEC.COM
Due to technical progress, all designs, specifications and components are subject to change without notice.
