Silicon Power Diode
PSM/PSMR 40L
PSM/PSMR 40K
I
F(AV)
=
40 A
V
RRM
= 100 - 1600 V
Preliminary Data Sheet
max.repetitive
peak voltage
V
RRM
(V)
100
200
400
600
800
1000
1200
1400
1600
recommended
max.RMS
max. DC
RMS working
reverse voltage blocking voltage
voltage
V
R(RMS)
(V)
70
140
280
420
560
700
840
980
1120
V
R
Type
without terminal lead
with terminal lead
(V)
100
200
400
600
800
1000
1200
1400
1600
(V)
40
80
160
240
320
400
480
560
640
PSM/PSMR 40/01L
PSM/PSMR 40/02L
PSM/PSMR 40/04L
PSM/PSMR 40/06L
PSM/PSMR 40/08L
PSM/PSMR 40/10L
PSM/PSMR 40/12L
PSM/PSMR 40/14L
PSM/PSMR 40/16L
PSM/PSMR 40/01K
PSM/PSMR 40/02K
PSM/PSMR 40/04K
PSM/PSMR 40/06K
PSM/PSMR 40/08K
PSM/PSMR 40/10K
PSM/PSMR 40/12K
PSM/PSMR 40/14K
PSM/PSMR 40/16K
Symbol Conditions
I
F(AV)
I
FSM
I
FRM
I
2
t
I
R(AV)
V
FM
R
thJC
T
VJ
T
VJM
T
stg
M
d
T
C
= 140°C
T
VJ
= 45°C
t = 10 ms
max. peak cycle repetitive surge current
max. I
2
t rating (non-rep.) for 5 to 10 ms
Maximum Ratings
40
500
200
1200
A
A
A
2
As
µA
V
K/W
°C
°C
°C
mkg
mkg
g
g
DO - 5
PSM/PSMR 40L
max. average reverse leakage current at V
RRM
; T
C
= 25°C 200
max. peak forward voltage drop @ rated 1F(AV)
1.3
max. thermal resistance junction to case
0.65
operating junction temperature
-65... + 150
max. virtual junction temperature
150
storage temperature
-65... + 200
mounting torque
min.
0.4
(non-lubricated threads)
max.
0.6
Weight
PSM/PSMR 40L
typ.
13.5
Weight
PSM/PSMR 40K
typ.
30
PSM/PSMR 40K
Features
•
All Diffused Series
•
Available in Normal & Reverse Polarity
•
Industrial Grade
•
Available in Avalanche Characteristic
