Diode Modules
Preliminary Data Sheet
V
RSM
V
DSM
900
1300
1500
1700
1900
PSWD 120
PSYD 120
Type
Type
PSYD 120/08
PSYD 120/12
PSYD 120/14
PSYD 120/16
PSYD 120/18
I
FRMS
V
RRM
= 3x 70 A
= 800 - 1800 V
V
RRM
V
DRM
800
1200
1400
1600
1800
PSWD 120/08
PSWD 120/12
PSWD 120/14
PSWD 120/16
PSWD 120/18
Base
PSWD
PSYD
Symbol
I
FAVM
I
FSM
Test Conditions
T
C
= 85°C
T
VJ
= 45°C
V
R
= 0
T
VJ
= T
VJM
V
R
= 0
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
Maximum Ratings
70
1800
1950
1600
1800
16200
16200
12800
13400
-40 ... + 150
150
-40 ... + 125
A
A
A
A
A
A
2
s
A
2
s
A
2
s
A
2
s
°C
°C
°C
V
∼
V
∼
Nm
Nm
g
∫
i
2
dt
T
VJ
= 45°C
V
R
= 0
T
VJ
= T
VJM
V
R
= 0
Features
•
•
•
•
•
•
Package with screw terminals
Isolation voltage 3000 V∼
Planar glasspassivated chips
Blocking voltage up to 1800 V
Low forward voltage drop
UL registered, E148688
T
VJ
T
VJM
T
stg
V
ISOL
M
d
Weight
50/60 HZ, RMS
I
ISOL
≤
1 mA
t = 1 min
t=1s
(M6)
(M6)
2500
3000
5
5
270
Applications
•
•
•
•
Supplies for DC power equipment
Input rectifiers for PWM inverter
Battery DC power supplies
Field supply for DC motors
Mounting torque
Terminal connection torque
typ.
Advantages
Symbol
I
R
V
F
V
TO
r
T
R
thJC
R
thJK
d
S
d
A
a
Test Conditions
V
R
= V
RRM
V
R
= V
RRM
I
F
= 300 A
T
VJ
= 25°C
T
VJ
= T
VJM
T
VJ
= 25°C
Characteristic Value
≤
≤
≤
0.3
5
1.55
0.8
3
0.65
0.108
0.83
0.138
10.0
9.4
50
mA
mA
V
V
mΩ
K/W
K/W
K/W
K/W
mm
mm
m/s
2
•
•
•
Easy to mount with two screw
Space and weight savings
Improved temperature and power
cycling capability
For power-loss calculations only
T
VJ
= T
VJM
per diode; DC current
per module
per diode; DC current
per module
Creeping distance on surface
Creeping distance in air
Max. allowable acceleration
Package, style and outline
Dimensions in mm (1 mm=0.0394”)
POWERSEM GmbH, Walpersdorfer Str. 53
91126 D- Schwabach
Phone: 09122 - 9764-0 Fax.: 09122 - 9764-20
2004 POWERSEM reserves the right to change limits, test conditions and dimensions
