SMT Power Inductors – LPS6220 Series
• Very low DCR; excellent current handling
• 6.0 × 6.0 mm footprint, only 2.0 mm high
Core material
Ferrite
Terminations
RoHS compliant silver-palladium-platinum-glass frit.
Other terminations available at additional cost.
Weight
248 – 271 mg
Ambient temperature
–40°C to +85°C with
Irms
current, +85°C to
+125°C with derated current
Storage temperature
Component: –40°C to +125°C.
Packaging: –55°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Mean Time Between Failures (MTBF)
26,315,789 hours
Packaging
1000/7″reel; 3500/13″ reel Plastic tape: 12 mm wide,
0.25 mm thick, 8 mm pocket spacing, 2.03 mm pocket depth
Recommended pick and place nozzle
OD: 6 mm; ID:
≤3
mm
PCB washing
Only pure water or alcohol recommended
DCR
SRF
Inductance
2
max
3
typ
4
± 20% (µH) (Ohms) (MHz)
0.047
0.055
0.075
0.088
0.115
0.120
0.215
0.275
0.400
0.555
0.745
0.875
1.00
1.36
1.86
2.65
3.70
5.15
8.35
11.6
13.8
17.8
24.6
32.5
41.4
45.0
60.0
79.0
114
94
72
53
42
33
28
22
17
14
11
9.0
8.0
7.8
6.0
4.5
3.6
2.4
2.0
1.5
1.4
1.4
1.0
0.86
0.62
0.62
0.60
0.60
Irms
(A)
6
20°C 40°C
rise rise
1.4
1.3
1.4
0.80
0.95
1.2
0.88
0.77
0.68
0.56
0.52
0.42
0.38
0.34
0.29
0.25
0.21
0.16
0.14
0.12
0.10
0.093
0.083
0.073
0.067
0.063
0.062
0.052
1.7
1.7
1.8
1.2
1.3
1.6
1.1
1.0
0.85
0.66
0.67
0.56
0.51
0.45
0.39
0.34
0.29
0.24
0.19
0.15
0.14
0.12
0.11
0.095
0.087
0.080
0.080
0.068
Part number
1
Isat
5
(A)
4.0
3.6
3.1
2.7
2.3
1.9
1.5
1.3
1.0
0.90
0.74
0.45
0.39
0.37
0.32
0.24
0.21
0.17
0.14
0.12
0.11
0.10
0.095
0.082
0.080
0.078
0.076
0.074
LPS6220-152ML_
1.5
LPS6220-222ML_
2.2
LPS6220-332ML_
3.3
LPS6220-472ML_
4.7
LPS6220-682ML_
6.8
LPS6220-103ML_
10.0
LPS6220-153ML_
15.0
LPS6220-223ML_
22.0
LPS6220-333ML_
33.0
LPS6220-473ML_
47.0
LPS6220-683ML_
68.0
LPS6220-104ML_
100.0
LPS6220-124ML_
120.0
LPS6220-154ML_
150.0
LPS6220-224ML_
220.0
LPS6220-334ML_
330.0
LPS6220-474ML_
470.0
LPS6220-684ML_
680.0
LPS6220-105ML_ 1000.0
LPS6220-155ML_ 1500.0
LPS6220-185ML_ 1800.0
LPS6220-225ML_ 2200.0
LPS6220-335ML_ 3300.0
LPS6220-475ML_ 4700.0
LPS6220-565ML_ 5600.0
LPS6220-685ML_ 6800.0
LPS6220-825ML_ 8200.0
LPS6220-106ML_ 10000.0
1. When ordering, please specify
termination
and
packaging
codes:
LPS6220-106MLC
Termination: L
=RoHS compliant silver-palladium-platinum-glass frit.
Special order:
T
= RoHS tin-silver-copper (95.5/4/0.5)
or
S
= non-RoHS tin-lead (63/37).
Packaging: C
= 7″ machine-ready reel. EIA-481 embossed plastic
tape (1000 parts per full reel).
B
= Less than full reel. In tape, but not machine ready.
To have a leader and trailer added ($25 charge), use
code letter C instead.
D
= 13″ machine-ready reel. EIA-481 embossed plastic
tape. Factory order only, not stocked (3500 parts per
full reel).
Inductance tested at 100 kHz, 0.1 Vrms, 0 Adc.
DCR measured on a micro-ohmmeter.
SRF measured using Agilent/HP 8753ES or equivalent.
For inductance values
≥10
µH, DC current at which the inductance drops
20% (max) from its value without current. For inductance values <10 µH,
DC current at which the inductance drops 30% (max) from its value
without current.
Current that causes the specified temperature rise from 25°C ambient.
Storage and operating temperature range
−40°C
to +85°C.
Electrical specifications at 25°C.
2.
3.
4.
5.
6.
7.
8.
These parts are preproduction products for electrical evaluation only.
Specification subject to change without notice.
Document 562-1
Revised 03/10/08
© Coilcraft, Inc. 2008
Document 562-2
SMT Power Inductors – LPS6220 Series
Typical L vs Frequency
10000
3300 µH
3300 µH
1000 µH
Typical L vs Current
10000
1000
Inductance (µH)
330 µH
100 µH
Inductance (µH)
1000
1000 µH
330 µH
100
33 µH
10 µH
3.3 µH
100
100 µH
33 µH
10
10
10 µH
3.3 µH
1
0.01
0.1
1
10
1
0.01
0.1
1
10
Frequency (MHz)
Current (A)
0.236 ±0.003
*
6,00 ±0,076
Typical Current Derating
120
110
Percent of rated current
100
90
80
70
60
50
40
Dash
number
Internal
code
XXX X
0.236 ±0.003
*
6,00 ±0,076
Winding
direction
25°C
30
20
10
0
-40
-20
Isat
Irms
0
20
0.075 ±0.004
1,90 ± 0,10
Recommended
Land Pattern
0.165
4,20
40
60
80
100
120 140
0.260 0.167
6,60 4,25
0.165
4,20
0.071
1,80
Ambient temperature (°C)
0.079
2,00
*
Dimensions are of the case not
including the termination. For maximum
overall dimensions including the
termination, add 0.005 in / 0,13 mm.
0.079
2,00
0.167
4,25
0.260
6,60
Dimensions are in
inches
mm
These parts are preproduction products for electrical evaluation only.
Specification subject to change without notice.
Document 562-2
Revised 03/10/08
© Coilcraft, Inc. 2008
