KBU8005 THRU KBU810
SINGLE-PHASE SILICON BRIDGE RECTIFIER
REVERSE VOLTAGE:
FORWARD CURRENT:
FEATURES
· Reliable low cost construction utilizing molded
plastic technique
· Ideal for printed circuit board
· Low forward voltage drop
· Low reverse leakage current
· High surge current capability
KBU
50 to 1000 VOLTS
8.0 AMPERE
MECHANICAL DATA
Case: Molded plastic, KBU
Epoxy: UL 94V-O rate flame retardant
Terminals: Leads solderable per MIL-STD-202,
method 208 guaranteed
Mounting position: Any
Weight: 0.3ounce, 8.0gram
Dimensions in inches and (millimeters)
Maximum Ratings and Electrical Characteristics
Ratings at 25
ambient temperature unless otherwise specified.
Single phase, half wave, 60H
Z
, resistive or inductive load.
For capacitive load, derate current by 20%.
Symbols
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
.375"(9.5mm) Lead Length at T
A
=55
Peak Forward Surge Current,
8.3ms single half-sine-wave
superimposed on rated load (JEDEC method)
Maximum Forward Voltage
at 8.0A DC and 25
Maximum Reverse Current
at Rated DC Blocking Voltage
Typical Thermal Resistance (Note 2)
Typical Thermal Resistance (Note 3)
Operating and Storage Temperature Range
at T
A
=25
T
A
=100
I
R
R
R
T
J
JA
JC
KBU8005
KBU801
KBU802
KBU804
KBU806
KBU808
KBU810
Units
Volts
Volts
Volts
Amp
V
RRM
V
RMS
V
DC
I
(AV)
50
35
50
100
70
100
200
140
200
400
280
400
8.0
600
420
600
800
560
800
1000
700
1000
I
FSM
300
Amp
V
F
1.1
10.0
500
18
3
-55 to +125
Volts
uAmp
/W
/W
Tstg
NOTES:
1- Units mounted in free air, no heatsink, P.C.B. at 0.375" (9.5mm) lead length with 0.5 x 0.5” (12 x 12mm) copper pads
2- Units mounted on a 3.0 x 3.0” x 0.11" thick (7.5 x 7.5 x 0.3cm) Al. Plate heatsink
