RG240160-B
…….
OUTLINE DIMENSION & BLOCK DIAGRAM
MECHNICAL SPECIFICATION
Overall Size
View Area
Dot Size
Dot Pitch
74.6 x 54.9 mm
67.6 x 47.5 mm
0.225 x 0.225 mm
0.24 x 0.24 mm
Module
W/O B/L
EL B/L
LED B/L
H2 / H1
2.9 / 5.0
3.2 / 7.0
-/-
Symbol
V
DD
-V
SS
V
DD
-V
EE
V
IN
Condition
25°C
25°C
25°C
Min.
4.5
N W
-
-
-
-
-
-
-
-
-
20.1
19.6
18.6
-
PIN ASSIGNMENT
Pin No. Symbol
Function
CL2(SCP) Data shift pulse
1
CL1(LP) Data latch pulse
2
FLM
Scan start-up signal
3
M
Frame reverse signal(Alternate signal)
4
D0
Data display
5
D1
Data display
6
D2
Data display
7
D3
Data display
8
V
EE
Power supply voltage for LCD(+V)
9
V
DD
Power supply voltage for logic
10
V
SS
Ground
11
BLE
EL enable/disable
12
VELG
Power supply for EL(-)
13
VEL
Power supply for EL(+)
14
ABSOLUTE MAXIMUM RATING
Item
Supply for logic voltage
LCD driving supply voltage
Input Voltage
Item
Power supply voltage
Min.
-0.3
-0.3
-0.3
Typical
5.0
N W
-
-
-
-
-
21.5
20.7
19.6
18.7
17.7
0.3
3.0
40.0
Max. Units
7.0
V
30.0
V
Vdd+0.3 V
Max. Units
5.5
V
N W V
-
-
V
- 21.3
V
- 20.2
V
- 19.3
V
-
-
V
-
mA
-
mA
--
mA
ELECTRICAL CHARACTERISTICS
Symbol Condition
V
DD
-V
SS
25°C
T
OP
-20°C
0°C
V
OP
25°C
50°C
70°C
I
DD
V
DD
=5V
I
EE
V
DD
=5V
EL
V
OP
=5V
LCD operation voltage
LCM current consumption (No B/L)
Backlight current consumption
REMARK
LCD option: STN, FSTN
Backlight Option: EL backlight feature, other specs not available on catalog is under request.
