MAX6444US29T-T: DescriptionPower Supply Support Circuit, Adjustable, 1 Channel, BICMOS, PDSO4, SOT-143, 4 PIN; CategoryPower/power management The power supply circuit; File Size158KB，13 Pages; ManufacturerMaxim; Websitehttps://www.maximintegrated.com/en.html

Download Datasheet Parametric View All

MAX6444US29T-T Overview

Power Supply Support Circuit, Adjustable, 1 Channel, BICMOS, PDSO4, SOT-143, 4 PIN

MAX6444US29T-T Parametric

Parameter Name	Attribute value
Maker	Maxim
Parts packaging code	SOT-143
package instruction	SOT-143, 4 PIN
Contacts	4
Reach Compliance Code	compliant
ECCN code	EAR99
Other features	RESET THRESHOLD VOLTAGE IS 2.925V
Adjustable threshold	YES
Analog Integrated Circuits - Other Types	POWER SUPPLY SUPPORT CIRCUIT
JESD-30 code	R-PDSO-G4
length	2.92 mm
Number of channels	1
Number of functions	1
Number of terminals	4
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
encapsulated code	LSOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, LOW PROFILE
Certification status	Not Qualified
Maximum seat height	1.22 mm
Maximum supply voltage (Vsup)	5.5 V
Minimum supply voltage (Vsup)	1 V
Nominal supply voltage (Vsup)	3.6 V
surface mount	YES
technology	BICMOS
Temperature level	INDUSTRIAL
Terminal form	GULL WING
Terminal pitch	1.92 mm
Terminal location	DUAL
width	1.3 mm

Preview

Download Datasheet

View All

19-2656; Rev 3; 6/10

µP Reset Circuits with Long Manual Reset

Setup Period

General Description

The MAX6443–MAX6452 low-current microprocessor

reset circuits feature single or dual manual reset inputs

with an extended setup period. Because of the extend-

ed setup period, short switch closures (nuisance resets)

are ignored.

On all devices, the reset output asserts when any of the

monitored supply voltages drops below its specified

threshold. The reset output remains asserted for the

reset timeout period (210ms typ) after all monitored

supplies exceed their reset thresholds. The reset output

is one-shot pulse asserted for the reset timeout period

(140ms min) when selected manual reset input(s) are

held low for an extended setup timeout period. These

devices ignore manual reset transitions of less than the

extended setup timeout period.

The MAX6443–MAX6448 are single fixed-voltage µP

supervisors. The MAX6443/MAX6444 have a single

extended manual reset input. The MAX6445/MAX6446

have two extended manual reset inputs. The MAX6447/

MAX6448 have one extended and one immediate manual

reset input.

The MAX6449–MAX6452 have one fixed-threshold µP

supervisor and one adjustable-threshold µP supervisor.

The MAX6449/MAX6450 have two delayed manual

reset inputs. The MAX6451/MAX6452 have one delayed

and one immediate manual reset input.

The MAX6443–MAX6452 have an active-low

RESET

with push-pull or open-drain output logic options. These

devices, offered in small SOT packages, are fully guar-

anteed over the extended temperature range (-40°C to

+85°C).

Features

Single- or Dual-Supply Voltage Monitors

Precision Factory-Set Reset Thresholds from

1.6V to 4.6V

Adjustable Threshold to Monitor Voltages Down

to 0.63V (MAX6449–MAX6452)

Single or Dual Manual Reset Inputs with Extended

Setup Period

Optional Short Setup Time Manual Reset Input

(MAX6447/MAX6448 and MAX6451/MAX6452)

Immune to Short Voltage Transients

Low 6µA Supply Current

Guaranteed Valid Reset Down to V

= 1.0V

Active-Low

RESET

(Push-Pull or Open-Drain)

Outputs

140ms (min) Reset Timeout Period

Small SOT143 and SOT23 Packages

MAX6443–MAX6452

Ordering Information

PART

MAX6443US_

_ _-T

MAX6444US_

_ _-T

TEMP RANGE

-40°C to +85°C

PIN-PACKAGE

4 SOT143

Applications

Set-Top Boxes

Consumer Electronics

DVD Players

Cable/DSL Modems

MP3 Players

Industrial Equipment

Automotive

Medical Devices

Note:

The first “_ _ ” is a placeholder for the threshold voltage

level of the devices. A desired threshold level is set by the two-

number suffix found in Table 1. The third "_" is a placeholder

for the manual reset setup period of the devices. A desired

setup period is set by the letter suffix found in Table 2. All

devices are available in tape-and-reel only. There is a 2500-

piece minimum order increment for standard versions (Table

2). Sample stock is typically held on standard versions only.

Nonstandard versions require a minimum order increment of

10,000 pieces. Contact factory for availability.

Devices are available in both leaded and lead-free packaging.

Specify lead-free by replacing “-T” with “+T” when ordering.

Pin Configurations

TOP VIEW

GND

MAX6443

MAX6444

RESET

MR1

SOT143

Pin Configurations continued at end of data sheet.

________________________________________________________________

Maxim Integrated Products

For pricing, delivery, and ordering information, please contact Maxim Direct at 1-888-629-4642,

or visit Maxim’s website at www.maxim-ic.com.
