SPD5186 Thru SPD5192
Solid State Devices, Inc.
14701 Firestone Blvd * La Mirada, Ca 90638
Phone: (562) 404-4474 * Fax: (562) 404-1773
ssdi@ssdi-power.com * www.ssdi-power.com
and
SPD5186SMS Thru SPD5192SMS
3 Amps
150-200 nsec
100-1000 V
Fast Recovery Rectifier
Features:
•
Fast Recovery: 150-200 nsec maximum
•
Low Reverse Leakage Current
•
PIV to 1000 Volts
•
Hermetically Sealed
•
High Surge Rating
•
Low Thermal Resistance
•
Faster Recovery Devices Available – Contact
Factory
•
TX, TXV, and Space Level Screening Available
2/
•
Replacement for 1N5186, 1N5187, 1N5188, and
1N5190
Designer’s Data Sheet
Part Number/Ordering Information
1/
SPD
__ __ __
│
│
│
│
│
│
│
│
│
└
│
└
Screening
2/
__
= Not Screened
│
TX = TX Level
│
TXV = TXV
│
S = S Level
│
└
Package Type
__
= Axial Leaded
B = Axial w/ .040” lead diameter
SMS = Surface Mount Square Tab
Voltage
5186=100V
5190=600V
5187=200V
5191=800V
5188=400V
5192=1000V
Maximum Ratings
Peak Repetitive Reverse Voltage and
DC Blocking Voltage
Average Rectified Forward Current
(Resistive Load, 60 Hz, Sine Wave, T
A
= 25 °C)
SPD5186…SMS
SPD5187…SMS
SPD5188…SMS
SPD5190…SMS
SPD5191…SMS
SPD5192…SMS
Symbol
V
RRM
V
RWM
V
R
Io
I
FSM
T
OP
& T
STG
R
θJL
R
θJL
R
θJE
Value
100
200
400
600
800
1000
3
100
Units
Volts
Amps
Amps
ºC
ºC/W
Peak Surge Current
(8.3 ms Pulse, Half Sine Wave Superimposed on I
O
, allow junction to reach
equilibrium between pulses, T
A
= 25 °C)
Operating & Storage Temperature
Maximum Thermal Resistance
Junction to Leads, L=3/8”
B Variant
Junction to End Tab (Surface Mount)
NOTES:
1/ For Ordering Information, Price, and Availability – Contact Factory.
2/ Screening Based on MIL-PRF-19500. Screening Flows Available on Request.
-65 to +175
20
25
14
Axial
Surface Mount Square Tab
NOTE:
All specifications are subject to change without notification.
SCD's for these devices should be reviewed by SSDI prior to release.
DATA SHEET #: RF0009D
DOC
Solid State Devices, Inc.
14701 Firestone Blvd * La Mirada, CA 90638
Phone: (562) 404-4474 * Fax: (562) 404-1773
ssdi@ssdi-power.com * www.ssdi-power.com
SPD5186 Thru SPD5192
and
SPD5186SMS Thru SPD5192SMS
Electrical Characteristics
Instantaneous Forward Voltage Drop
(
I
F
=3Adc,
T
A
= 25 ºC
, 300
μ
s Pulse)
Instantaneous Forward Voltage Drop
(
I
F
=3Adc,
T
A
= -55 ºC
, 300
μ
s Pulse)
Symbol
V
F
Value
1.3
Units
V
DC
V
F
1.45
V
DC
Reverse Leakage Current
(Rated V
R,
T
A
= 25 ºC , 300μs minimum pulse)
Reverse Leakage Current
(Rated V
R,
T
A
= 100 ºC , 300μs minimum pulse)
Reverse Recovery Time
SPD5186…SMS-SPD5188…SMS
(I
F
= 500 mA, I
R
= 1 Amp, I
RR
= 250 mA, T
A
= 25
SPD5190…SMS-SPD5192…SMS
ºC)
Junction Capacitance
(V
R
= 10V
DC
, T
A
= 25ºC, f = 1MHz)
I
R
I
R
t
RR
C
J
5
200
150
200
40
μA
μA
nsec
pF
CASE OUTLINE: Axial
CASE OUTLINE: Surface Mount Square Tab
Dimensions
DIM
MIN
A
---
B
---
C
.047”
C (B Variant)
.038”
D
1.00”
MAX
.200”
.230”
.053”
.042”
---
DIM
A
B
C
D
Dimensions
MIN
.172”
.180”
.022”
.002”
MAX
.180”
.280”
.028”
---
NOTE:
All specifications are subject to change without notification.
SCD's for these devices should be reviewed by SSDI prior to release.
DATA SHEET #: RF0009D
DOC
