HD74LS05RP-EL datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > logic> logic> HD74LS05RP-EL

HD74LS05RP-EL: DescriptionLS SERIES, HEX 1-INPUT INVERT GATE, PDSO14, FP-14DN; Categorylogic logic; File Size51KB，5 Pages; ManufacturerRenesas Electronics Corporation; Websitehttps://www.renesas.com/

Download Datasheet Parametric Compare View All

HD74LS05RP-EL Overview

LS SERIES, HEX 1-INPUT INVERT GATE, PDSO14, FP-14DN

HD74LS05RP-EL Parametric

Parameter Name	Attribute value
Maker	Renesas Electronics Corporation
Parts packaging code	SOIC
package instruction	SOP,
Contacts	14
Reach Compliance Code	unknown
series	LS
JESD-30 code	R-PDSO-G14
length	8.65 mm
Logic integrated circuit type	INVERTER
Number of functions	6
Number of entries	1
Number of terminals	14
Maximum operating temperature	75 °C
Minimum operating temperature	-20 °C
Output characteristics	OPEN-COLLECTOR
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
propagation delay (tpd)	32 ns
Certification status	Not Qualified
Maximum seat height	1.75 mm
Nominal supply voltage (Vsup)	5 V
surface mount	YES
technology	TTL
Temperature level	COMMERCIAL EXTENDED
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
width	3.9 mm
