EC46
Vishay Aztronic
Conformal Coated Inductors, Axial Leads,
Commercial Use
FEATURES
• Uniform epoxy coating for humidity
• Copper winding on magnetic core structure
• Tinned copper axial leads
DIMENSIONS
in millimeters
28
±3
6
4 max. 4 max.
28
±3
Ø 5 max.
0.65
±0.05
First significant figure
Second significant figure
Tolerance
Multiplier
ELECTRICAL SPECIFICATIONS
Inductance Range
Tolerance
Limiting Voltage
1mH to 39mH
± 10%
250VRMS
MECHANICAL SPECIFICATIONS
Coating
Terminations
Weight
epoxy resin
tinned copper
1g
ENVIRONMENTAL SPECIFICATIONS
Operating Temperature
Temperature Limits
+ 80°C
- 20°C + 100°C
www.vishay.com
18
For technical questions, contact sfer@vishay.com
Document Number: 59006
Revision 16-Jul-02
EC46
Conformal Coated Inductors, Axial Leads,
Commercial Use
EC46 INDUCTORS - STANDARD VALUES
INDUCTANCE
VALUE
µH 1KHz
TOLERANCE
%
Q
MIN.
TEST
FREQUENCY
MHz
DCR
MAX.
Ω
Vishay Aztronic
1
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
30
33
39
± 10%
80
252
80
60
259
79.6
60
40
± 10%
40
79.6
8
9
10
11
14
18
22
26
30
34
48
62
74
88
102
150
180
210
240
250
270
PACKAGING
2000 pieces tape in box “ammopack”
5000 pieces tape and reel
On request : 2000 pieces tape and reel radial style available (consult VISHAY AZTRONIC for dimensions).
MARKING
4 color band.
ORDERING INFORMATION
EC
SERIES
46
STYLE
15mH
INDUCTANCE
VALUE
± 10%
TOLERANCE
B
PACKAGING
R: tape and reel
B: tape in box ”Ammopack“
E: radial style
Document Number: 59006
Revision 16-Jul-02
For technical questions, contact sfer@vishay.com
www.vishay.com
